Mini XLR Jack
The miniXLR jack provides the option of connecting extensions without additional hardware.
Mini-XLR-jack
Note:
Concomitant use of this socket and a 4th axis, such as a rotation axis or tangential knife, the
connectivity is limited because both the miniXLR socket and the reference switch the 4th axis are
found via the PIN15 of the LPT port.
For this combination, we have a solution. To do so, please contact our customer service.
CNC-STEP e.K. ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
For example:
Tool length control, Security housings with door switch
3D Buttons
Quick Start Guide
