Connection possibility of a 4th axis

4
On the C-terminal of the zero-3 control another step motor can be operated as the fourth axis. In
addition to this port, a 12-24V supply for an oscillation motor and the connection for a further
reference switch are supplied.
Rotation Axis
- Make sure that the control is turned off.
- Connect the supplied power cable to the C-socket of the controller.
- Make sure that you back up all connections with the knurled screws from loosening.
CNC-STEP e.K. ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
TCM-3
Quick Start Guide
Zero-3 Front Side
EOT-2 TCT-1
T-Rex Series
Page 12
