1 Connectors and cables on the machine

1.1

Connection Panel Machine

D-Sub 9pol. ST
D-Sub 15pol. C
Neutrik 4pol. X
Neutrik 4pol. Y
Neutrik 4pol. Z
Hirschmann 7pol.
230V Plug
CNC-STEP e.K. ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
Control line ST
Tangential Tools (to Connection Panel Z-axis)
Motor connection cable X-axis
Motor connection cable Y-axis
Motor connection cable Z-axis
HF-Spindle (to Connection Panel Z-axis)
230V Socket Connection Panel Z-axis
Quick Start Guide
T-Rex Series
Touchprobe
Length Sensor
Connection Panel Machine
Page 5
15.01.2015
