Connection options of optional accessories

5
The accessories at this point we just cover briefly the connection to the machine to the controller
and if necessary to the additional hardware interface (depending on the software).
For more detailed information please refer to the individual manuals.
5.1 Overview Connection and power supply via Zero -3 control
Milling motors
Granitograv
