Main Specifications - Boss Loop Station RC-5 Reference Manual

Appendix

Main Specifications

Sampling Frequency
AD/DA Conversion
Processing
Recording/Playback
Rhythm Type
Rhythm Kit
Effect
Memory
Nominal Input Level
Input Impedance
Nominal Output Level
Output Impedance
Recommended Load Impedance OUTPUT A/MONO, B: 10 kΩ or greater
Bypass
Display
Connectors
Power Supply
Current Draw
Expected battery life under
continuous use
Dimensions
Weight
Accessories
Options (sold separately)
* 0 dBu = 0.775 Vrms
* This document explains the specifications of the product at the time that the document was issued. For the latest information, refer to the
Roland website.
22
44.1 kHz
32 bits
32-bit floating point
Number of Tracks: 1
Data Format: WAV (44.1 kHz, 32-bit float, stereo)
Maximum Recording Time: Approx. 1.5 hours (1 track), Approx.13 hours (total of All memories)
57 Patterns x 2 Variations
7 types
Reverb (only for rhythm part)
99
INPUT A/MONO, B: -20 dBu
INPUT A/MONO, B: 1 MΩ
OUTPUT A/MONO, B:-20 dBu
OUTPUT A/MONO, B: 1 kΩ
Buffered bypass
Graphic LCD (96 x 32 dots, RGB backlit LCD)
NPUT A/MONO, B jacks: 1/4-inch phone type
OUTPUT A/MONO, B jacks: 1/4-inch phone type
STOP/MEMORY jack: 1/4-inch TRS phone type
USB port: USB B type
MIDI (IN, OUT) jacks: stereo miniature type
DC IN jack
Alkaline battery (9 V, 6LR61 or 6LF22)
AC adaptor (PSA series: sold separately)
170 mA
These figures will vary depending on the actual conditions of use.
Alkaline: Approx. 2 hours
73 (W) x 129 (D) x 56 (H) mm
2-7/8 (W) x 5-1/8 (D) x 2-1/4 (H) inches
(excluding battery)
405 g/15 oz
Owner's Manual
Leaflet ("USING THE UNIT SAFELY, " "IMPORTANT NOTES, " and "Information")
Alkaline battery (9 V, 6LR61 or 6LF22)
AC adaptor: PSA-S series
Footswitch: FS-5U
Dual Footswitch: FS-6, FS-7
Expression Pedal: FV-500H, FV-500L, EV-30, Roland EV-5
TRS/MIDI connecting cable: BMIDI-5-35
(including battery)
450 g/1 lb
