Boss Loop Station RC-5 Reference Manual page 15

MIDI
Parameter Value
RX CTL CH 1–16
Specifies MIDI omni mode.
OFF
OMNI
ON
RX NOTE CH 1–10–16
TX CH 1–16,
Specifies the input to which the tempo clock is synchronized.
AUTO
SYNC CLOCK
INTERNAL
USB
MIDI
ON
CLOCK OUT OFF,
Specifies what starts in synchronization when a MIDI start message is received.
OFF
SYNC START
ALL
RHYTHM
ON
PC OUT OFF,
Specifies the connector(s) from which MIDI messages received at the MIDI IN connector or the USB port are output.
OFF
MIDI THRU
MIDI OUT
USB THRU
USB OUT
USB/MIDI
STORAGE
Parameter Value
STORAGE OFF, CONNECT
F.RESET
Parameter Value
Specifies the settings that will be returned to their factory-set state.
MEMORY
F.RESET
SYSTEM
MEM+SYS
Explanation
(Bold: default)
Specifies the receive channel for messages (control changes) that switch memories or
control the RC-5.
Messages will be received only on the channel specified by the RX CTL CH setting.
Messages are received via all MIDI channels, regardless of the RX CTL CH settings.
Specifies the receive channel for note messages that play the RC-5's drum sounds.
Specifies the MIDI transmit channel.
RX CTL
If this is "RX CTL, " the channel will be the same as the RX CTL CH.
The RC-5 will normally operate using its internal tempo, but will synchronize the tempo
to MIDI clock if MIDI clock data is being input via the MIDI IN connector or the USB port.
Choose the "AUTO" setting if using the RC-5 as a slave device.
The priority order is MIDI>USB>internal clock.
The clock uses the tempo specified by the memory.
Choose the "INTERNAL" setting if you don't want to synchronize the RC-5 to an external
device.
Synchronize to the tempo from the USB port.
Synchronize to the tempo from the MIDI IN connector.
Specifies whether MIDI clock is transmitted (ON) or not transmitted (OFF).
Synchronized start does not occur.
Track + rhythm
Rhythm
Specifies whether program change messages are transmitted (ON) or not transmitted
(OFF).
MIDI messages are not output.
Output from the MIDI OUT connector.
Output from the USB port.
Output from the USB port and the MIDI OUT connector.
Explanation
(Bold: default)
Change this from the OFF setting when connecting the RC-5 via USB to your computer.
When a connection with the computer is established, the message "CONNECTING... "
appears.
Explanation
(Bold: default)
Memory 01–99
System settings
Memory 01–99 and system settings
Settings for the Entire RC-5 (SETUP)
15
