Removing The Server Cover - 3Com CS/2500 Installation Manual

5-6 C 5: M
HAPTER AINTENANCE AND
Removing the Cover
U
PGRADES
Follow these steps to remove the server cover:
1 Shut down the server, as described in "Shutting Down" on page 3-8.
WARNING: Before removing the cover, be sure the unit is turned off
and the power cord is either disengaged from the unit's receptacle or
unplugged from the wall socket.
2 If the server is mounted in a rack, remove it from the rack. Remove the
rack-mounting brackets from the sides of the server.
3 Remove the black screws shown in Figure 5-3 with a #1 Phillips
screwdriver.
Figure 5-3 Removing the Server Cover
