Optional Rack
Mount Kit

Specifications

Power cord
receptacle
Figure 1-6 Power Supply Module
An optional rack mount kit is available for CS/2500 series servers
(3Com part number 3C759). This kit allows you to mount the server in a
two- or four-pole 19-inch rack.
For information on how to install the server in a rack, refer to
"Mounting in a Rack" on page 2-2.
This section describes CS/2500 and CS/2600 exterior hardware
specifications, electrical requirements, and environmental requirements.
The following tables list the CS/2500 series physical dimensions,
electrical requirements, and environmental conditions recommended for
safe, reliable operation.
Table 1-4 Physical Dimensions
Attribute
Length
Width
Height
Fuse holder
cartridge
AC switch
Description
12.6 in (32.3
cm)
16.2 in (41.1
cm)
3.8 in (9.6 cm)

Optional Rack Mount Kit

1-11
