Changing Port Configuration
4-15
presence of an active pin 25 and automatically switches to RS-422
operation. This option affects all ports.
This setting acts as a toggle. To disable it, type
again.
4
Automatic RS-422 selection requires a different configuration for the
RS-422 connector, in which pin 22 acts as a loopback for pin 25. For
more information, refer to Appendix A, "Pin Assignments."
5 To exit the System Default Configuration Menu, press the Escape key.
