2-6 C 2: I
HAPTER NSTALLATION
Once the server is turned on, you can change these parameters using the
Firmware Configuration Utility (refer to Chapter 4, "Configuration").
If you configure a port as the console port and then enable the monitor,
that port cannot be used for another type of device.
Attach the cable from the server to the terminal as shown in Figure 2-2.
AC power
connector
Back of
terminal
Attach cable
to port J0
Serial
cable
MODEM port
AUX port
Cable guard
Back of server
