2-8
C
2: I
HAPTER
Attaching the Power
Cable
NSTALLATION
Install brackets
Install server in rack
Figure 2-3 Printer Port Cabling
For pin assignments of the printer port, refer to Appendix A, "Pin
Assignments."
A power cable is supplied with your CS/2500 series server. If the power
cable does not match your requirements, contact your network supplier
for assistance.
To attach the power cable, follow these steps:
1 Make sure that the AC power switch is in the O or off position.
2 Attach the power cable to the receptacle on the back panel.
3 Plug the other end of the power cable into an AC power source.
0 0
C S / 2 6
C o m
3
