Table 24 Auto Discover Actions on NBX System Components (continued)
Component
3Com Attendant Console
pcXset
Soft Telephone
Initial System
Configuration
Auto Discover Action
Finds and configures any installed 3Com Attendant Consoles. The first 100 existing
telephones, except for the extension that is associated with the Attendant Console,
are mapped to Attendant Console buttons. The lowest extension is automatically
associated with the Attendant Console. Typically, you would wait until you have
installed all your telephones before you enable Auto Discover Attendant Consoles.
Enables the Auto Discover feature on installations of the pcXset PC Telephone Client
when the following conditions are true:
The pcXset PC Soft Telephone program is running on the host PC.
The pcXset PC Soft Telephone host computer is connected to the network.
You have entered the proper license key into the NBX NetSet utility.
Before you use the Auto Discover process to configure telephones and
attendant consoles, you should review the procedures in
Telephones and Attendant
To use the Auto Discover feature for initial system configuration:
1 Log in to the NBX NetSet utility using the administrator username and
password.
2 Click
System-wide Settings > Enable Features System-wide.
3 Verify that the box labeled Extensions Start At is set to what you want,
and then click Apply.
For a 4-digit dial plan, extensions start by default at 1000. For a 3-digit
dial plan, extensions start at 100.
Do not specify a starting extension that begins with zero (0) as that will
cause the Auto Discover process to fail.
4 Click
System-wide Settings > Auto Discovery
5 Select the check box for the device type you are configuring, and then
click Apply. 3Com recommends that you Auto Discover one device type at
a time. For detailed information about each field, click the Help button on
the page.
Auto Discover Usage Notes
If devices are on a different subnet from the NCP, you must enable IP
on the NCP (System-wide Settings > IP Settings), and each device must
have IP configuration information. You can use DHCP to configure the
Using Auto Discover for Initial System Configuration
Consoles.
