Figure 41 Connect AC power cord to the Switch 8807
(1) Connector-retention clamp
(3) Output LED
(5) Power switch
Figure 42 Connect AC power cord to the Switch 8810/Switch 8814
(1)
(1) Connector-retention clamp
(3) Output LED
(5) Power switch
(2) Input LED
(4) Fail LED
(2)
(3)
(4)
(2) Input LED
(4) Fail LED
5
( )
(5)
