You can select appropriate SFP optical modules for the 1000 Mbps SFP optical
ports on the
3C17533
optical modules available for the SFP optical ports and their matching cable types,
see Table 66 on page 46.
This section provides specifications for the 24-port 10/100/1000BASE-T IPv6
module (3C17534).
The 3C17534 module provides 24 10/100/1000BASE-T (RJ45) ports.
Table 52 3C17534 module specifications
Item
CPU
Boot ROM
SDRAM
Physical dimensions (W x D)
Max power consumption
Number of ports
Connector
Rate
The 3C17534 module has one LED for each port on its panel.
Figure 25 3C17534 module panel
Table 53 Port LEDs on the 3C17534 module
LED Status
LINK/ACT ON
OFF
Blinking
This section provides specifications for the 4-port 10GBASE-X (XFP) QUAD IPv6
module (3C17536).
The 3C17536 module provides four 10GBASE-X (XFP) ports.
Table 54 3C17536 module specifications
Item
CPU
module according to your needs. For a description of SFP the
Specification
MPC8245
512 KB
128 MB/256 MB
366.7 x 340 mm (14.4 x 13.4 in.)
110 W
24
RJ-45
10/100/1000 Mbps
Meaning
No link is present.
A link is present.
Packets are being transmitted/received on the port.
Specification
MPC8245
