17.1.2 Parameter list
ID Index Name/Setting Unit Description
97 PARA_
DataSetLdCfg
0 Opt
OFF (0)
ON(1)
1
FS:
0 = OFF
1 = TERM
2 = PARA
2 Mask
3 ActID
4 Para_ID
5 Para_SubID
6 Para_Scale
7 Para_Offset
98 PARA_
DataSetLdID
0 -99 PARA_
DataSetLdID
99 PARA_
DataSetLdVal
0 -99 PARA_
DataSetLdVal
Table 16.5: Parameter "Reloading individual parameters"
Activation
The function is activated by the setting of the parameter P 97 - PARA_DataSetLdCfg
[0] Opt = 1.
Determining the data set ID
ID No.: 0842.26B.5-01 Date: 09.2020
17 Enhanced/additional functions
DataSet Loader Configuration
Configuration options
Function not active
Activate function
Function selector
No data set ID is determined.
Determination via digital inputs (MPRO_INPUT_STATE
& PARA_DataSetLdCfg[1])
The data set ID is determined from a selectable
parameter. The value of the parameter (Para_
ID/ParaSubID) is used to generate the data set ID.
Bitmask
Currently selected data set ID
Parameter index for generating the data set ID (if
FS=PARA)
Parameter subindex for generating the data set ID (if
FS=PARA)
The parameter value is scaled (multiplication) for the
generation of the data set ID using the value indicated.
Parameter offset for generating the data set ID
List of the possible data set IDs
Associated character strings which describe
parameters and values which are to be changed
The parameter P 97 - PARA_DataSetLdCfg[1] FS is the function selector and
specifies which source is used for determining the data set ID.
The parameter P 97 - PARA_DataSetLdCfg[2] (= PARA_DataSetLd_Mask) functions
in this case as the bitmask for selecting (e.g. the desired digital inputs).
off (0) Manual switchover via ActID
1 Switchover via digital inputs
2 Switchover via separate parameter
The currently determined data set ID is displayed in parameter P 97 - PARA_
DataSetLdCfg[3] (= ActID).
Manual allocation of the data set ID
If parameter P 97 - PARA_DataSetLd_FS = OFF(0), then the data set ID can be
allocated "manually."
Every imaginable data set ID should be entered in parameter P 98 - PARA_
DataSetLdID[x] at least once under any subindex desired.
Automatic data set ID determination
Parameter P 97 = Para(2) allows switching between the data set IDs via any
parameter desired (for example, a fieldbus parameter). To do so, the parameter must
be entered in P 97.4 and the associated subindex in P 97.5. The value of the
parameter entered is overwritten in P 97.3.
Using parameter P 97 - PARA_DataSetLd_FS = PARA(2), the data set ID is
determined automatically from the current value of the parameter specified by P 97 -
PARA_DataSetLdCfg[4] and P 97 - PARA_DataSetLdCfg[5] and is entered in P 97
- PARA_DataSetLd [3] = ActId.
