- Page 1 Operation Manual - C4IRK01 - IMPORTANT: READ AND UNDERSTAND THIS MANUAL BEFORE USING THIS IR RECEIVER KIT. KEEP THIS MANUAL FOR FUTURE REFERENCE. P5415461...
- Page 3 TABLE OF CONTENTS 1. Safety Summary ..............................1 2. Before Operation ..............................4 ........................4 .......................4 ..............5 .....................5 ........................6 ........................7 ................7 .................7 ..................8 3. Operation .................................9 ............................9 ....10 ............................10 ........................10 ........................... 11 ........................... 11 ....................12 ..........................13 ...........................14 ..................14 ..................14 ......................15 ..........................15 ..............................15 ........................15 ..........................15 .........................16 ..........................16...
- Page 5 Safety Summary Signal Words General Precautions Refer back to these safety instructions as needed. P5415461-rev.2...
- Page 6 Installation Precautions P5415461-rev.2...
- Page 7 Electrical Precautions P5415461-rev.2...
- Page 8 NOTICE Before Operation P5415461-rev.2...
- Page 9 WARNING Label Air Inlet Grille Indoor Unit Air Outlet Louver Decorative Panel Unit Data Tag Location for Indoor Unit Model Indicator Light DIP Switch (Inside of IR Receiver Kit) TIMER FILTER DEF EMERGENCY HEAT COOL IR Receiver Buttons for Emergency Operation P5415461-rev.2...
- Page 10 NOTE ● Reset Button ● Transmitter Point the transmitter towards the indoor unit receiver when sending commands. The transmitting indication on the liquid crystal display (LCD) flashes when sending commands. ● Transmitting Indication: It will turn ON when sending commands with infrared rays. ●...
- Page 11 NOTE to operate. IR Receiver Kit (IR Receiver Component) Suitable Distance for Transmitting Max. 20ft (6m) ( Direct Line between Transmitter and IR Receiver Wireless Controller The distance for transmitting differs depending on the ceiling height. Refer to the table below for details. Ceiling Indoor Unit (Decorative Panel) IR Receiver Kit...
- Page 12 NOTE Beep Instantly Turns ON (yellow) TIMER FILTER DEF IR Receiver EMERGENCY HEAT COOL Wireless Controller P5415461-rev.2...
- Page 13 Operation NOTE Start Operation Stop Operation P5415461-rev.2...
- Page 14 NOTE Function unit. to 82 to 86 P5415461-rev.2...
- Page 15 Auto, Cool, Step LCD Indication Heat, Fan Auto-Swing Recommended Angle Angle Range Angle Range Auto High Recommended Angle High 2 operation. P5415461-rev.2...
- Page 16 Start Operation Function NOTE P5415461-rev.2...
- Page 17 Stop Operation NOTE Function Timer Timer Setting P5415461-rev.2...
- Page 18 Cancel Setting "Identified" Indoor Unit Indoor Indoor Unit A Unit B IR Receiver IR Receiver Kit A Kit B NOTE "A" "B" "Identified" Wireless Controller Function Indoor Unit Wireless Controller TIMER FILTER DEF Control Cable between Indoor Units EMERGENCY HEAT COOL This is an example of Simultaneous Operation of Multiple Units.
- Page 19 Maintenance Wired Controller (CIW01) Wireless Controller (CIR01) Slide the cover in and push the direction of the arrow. AAA Batteries P5415461-rev.2...
- Page 20 Indications of IR Receiver Kit Operation FILTER P5415461-rev.2...
- Page 21 Alarm "FILTER" (yellow lamp) "DEF" (green lamp) "DEF" flashes 3 times (0.5 second ON / 0.5 second OFF) “FILTER" flashes 5 times (0.5 second ON / 0.5 second OFF) These indications are repeated until the alarm is reset. P5415461-rev.2...
- Page 22 Troubleshooting Phenomenon Cause and Action Stopped Operation Issue Checking Point Action Not Operated Not Cooling or Heating Well P5415461-rev.2...
- Page 23 If an abnormality (burnt odor, for example) occurs, stop the operation and turn OFF the main power supply immediately. Otherwise, there may be damage to the product, an electric shock Contact your distributor. Trouble Action before Contact Provide the following information to the distributor. 1) Model Name 2) Description of Problem 3) Alarm Code Number or Details of Flashing Indicator (Refer to Section 5.2.1 “Abnormality”...
- Page 24 © 2015 Hitachi-Johnson Controls Air Conditioning, Inc. P5415461-rev.2 Code No. LIT-12012066 Revised January 2020...
