- Page 1 PX801-C PxArt+ 06 Mono Ceiling PxArt+ 12 Mono Ceiling PxArt+ 18 Mono Ceiling User manual...
-
Page 2: Table Of Contents
8 DMX signal connecting................14 9 Connection scheme.................15 10 Dimensions.....................16 11 Technical data..................17 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description PX801-C is a professional LED illuminator designed for illumination of museum exhibitions or displays. Thanks to the application of the most modern semiconductor SSL LED light sources and advanced control electronics, a high class illuminator was created which meets very high requirements for museum and exhibition lighting. -
Page 4: Safety Conditions
Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard LED light emission,... - Page 5 The PX801-C device is powered directly from 230V power grid. Failure to comply with the safety rules may result in electric shock and may endanger the user’s life. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual.
-
Page 6: Connectors And Control Elements
Connectors and control elements Brightness adjustment PX277 parameter programming connector... -
Page 7: Information On Version
Information on version Below is a description of the PX 801-C model designations with their explanation PX801-C – AA – XX – YYY – Z AA – version: XX – beam angle: YYY – CRI and Z – housing 06 – 6 LEDs 10 –... - Page 8 Depending on a situation, the diode signals the following: start of the lamp – quick flickering of the diode for 2 seconds • DMX signal receiving – slow flickering of the brightness adjustment • button (1Hz frequency) in the first minute after receiving the DMX signal •...
-
Page 9: Dmx Signal
5.2 DMX signal The PX801-C lamp can be controlled via DMX channel: • Channel 1 – brightness Setting the lamp parameters: Value of the lamp parameter Value of the DMX signal 100% Brightness adjustment Cooperating with the PX277 configurator Lamp settings can be changed by connecting the PX277 configurator (PxArt+ Settings Controller) to it. - Page 10 On – switching the lamp on at 100%, • Off – complete shutdown of the lamp, • Hold – maintaining the last value of DMX signal, • No Signal Time – device reaction time after the disappearance of the DMX signal (0.0 –...
-
Page 11: Scheme Of The Px801-C Menu In Px277
6.2 Scheme of the PX801-C menu in PX277 PX801-06 PX801-12 PX801-18 PxArt+ 06 PxArt+ 12 PxArt+ 18 NEXT ENTER DMX Addr. DMX Addr. 001 (1ch) 001 (1ch) * NEXT NEXT DMX Addr. 512 (1ch) * ENTER No Signal No Signal Channel: 1 Off * Value: 0 *... -
Page 12: Rdm - Available Parameters
RDM – available parameters The PX801-C supports the DMX-RDM protocol. DMX protocol allows only of a one-way data transmission, while extension the RDM protocol can transmit information in two directions. This makes possibility of monitoring activities of the compatible devices. Thanks to RDM some available settings of compatible devices may be programmed using this protocol. - Page 13 Parameter name Description FACTORY_DEFAULTS 0x0090 device default settings PERSONALITY * 0x00E0 DMX operational mode PERSONALITY_ description of individual 0x00E1 DESCRIPTION operational modes information on the selected SENSOR_DEFINITION 0x0200 temperature sensor SENSOR_VALUE 0x0201 information about sensors SMOOTH_OFF/1/2/3/4 * 0x801A selection of smoothing options NO_SIGNAL_OFF/ON/HLD/S behavior of the device when the 0x801C...
-
Page 14: Dmx Signal Connecting
DMX signal connecting PX801-C must be connected to the DMX line in series, without branching on the control cable. This means that the control cable should be connected to the DMX pins in the PX801-C, and then from the DMX pins to the next DMX receivers (diagram below). -
Page 15: Connection Scheme
Connection scheme DMX controller 230V AC PX801-C PX801-C Max. 32 devices on the line PX801-C Terminator (120 Ohm resistor) -
Page 16: Dimensions
10 Dimensions PxArt+ 06 Mono Ceiling PxArt+ 12 Mono Ceiling Ø122 Ø92 Ř149... -
Page 17: Technical Data
PxArt+ 18 Mono Ceiling Ø149 11 Technical data type PX801-C power supply 230V AC number of diodes 6 / 12 / 18 wersja DW PX801-C-06: 10W power consumption PX801-C-12: 17,5W PX801-C-18: 25W max. temperature rise housing +30°C LEDs lifespan 50000h wersja MONO 10°, 20°, 30°, 40°, EL* (10 x 45°), WW** beam angle... - Page 18 color temperature 2700K, 3000K, 3500K, 4500K range of brightness adjustment 0 – 100% CRI index min. 90 control DMX, RDM programmable scenes mounting to the ceiling available housing colors gray, black, white PX801-C-06: 1.3kg weight PX801-C-12: 1.7kg PX801-C-18: 2.4kg height PX801-C-06: 252mm diameter PX801-C-06: 92mm height PX801-C-12: 262mm dimensions...
- Page 19 Podłęże, 01.10.2020 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxArt+ 06/12/18 Mono Ceiling Product code: PX801-C meets the requirements of the following standards, as well as harmonised standards:...
