Assembly
WARNING
Do not plug in your deep cleaner until you are familiar with all instructions and operating procedures.
In step 3, you will need to use a Phillips-head screwdriver.
1
First, insert the Upper
Handle at the top of the
base until you hear a "click".
3
Using a Phillips-head
screwdriver, secure the
Carry Handle with the
screw that's taped to the
Upper Handle.
2
click
Next, align the Carry Handle with the slots on either
side of the base (behind the Power Switch and Cleaning
Mode Switch). The Carry Handle will "click" into place.
IMPORTANT: Do NOT put the Clean Water Tank on the
machine until step 5.
4
Wrap the cable around
the Carry Handle and
Cable Quick Release.
Side
View
5
Side
View
At the bottom of the
Upper Handle, align the
Clean Water Tank with
the grooves and slide
the tank into place.
