U S E R ' S G U I D E
9200, 9400, 9500 SERIES 220-240V
Safety Instructions
Consumer Services
ug120-4042_9500E.indd 1
ug120-4042_9500E.indd 1
5/7/08 3:37:36 PM
5/7/08 3:37:36 PM



  Summary of Contents for Bissell 9500

  • Page 1 U S E R ’ S G U I D E 9200, 9400, 9500 SERIES 220-240V Safety Instructions Product View Assembly Special Features 9-18 Operation 18-22 Maintenance and Care 23-24 Troubleshooting Consumer Services 26-27 Replacement Parts Warranty ug120-4042_9500E.indd 1 ug120-4042_9500E.indd 1...
  • Page 2 BISSELL ProHeat 2X We’re glad you purchased a BISSELL ProHeat 2X heated formula deep cleaner. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your ProHeat 2X is well made, and we back it with a limited two-year warranty.
  • Page 3 WARNING: ■ Use only cleaning products formulated by To reduce the BISSELL for use in this appliance to prevent risk of fire, electric shock, or injury: internal component damage ■ Keep openings free of dust, lint, hair, etc. ■ Use indoors only ■...
  • Page 4: Optional Accessories

    roduct view Spray Trigger Power Switch Heater Switch Extra Long Flex Hose Power Cord Upper Handle Easy Carry Handle Heat Indicator Light Tank Carry Handle ™ Ready Tool Detent Pedal Dial 2-in-1 Water Tank Lower Base ™ Dry Aire (select models) Edge Sweep Brushes Easy To Remove Nozzle...
  • Page 5 Crevice Tool Holder Storage (select models) (select models) Lower Hose Rack Lower Handle Keep plenty of genuine BISSELL Detent Pedal deep cleaning formulas on hand so you can clean whenever it fits your schedule. Always use genuine BISSELL deep cleaning Formula Tank formulas.
  • Page 6 Do not plug in your This user’s guide has been designed to help you cleaner until you have get the utmost satisfaction from your BISSELL completely assembled it per ProHeat 2X. You’ll find assembly and operating the following instructions...
  • Page 7 Your BISSELL ProHeat 2X deep cleaner is a home cleaning system that uses the power of heat, brushes and cleaning formula to get the deep down dirt for a maximum clean. Not only does it come with a lot of unique features, it has been designed with you, the customer, in mind.
  • Page 8 To help restore this important protection, only BISSELL offers deep cleaning formulas with Scotchgard protector and a post-applicator to apply Scotchgard protector with the same materials used by carpet mills. This offers extra protection against dirt and tough stains to keep your carpets looking good longer.
  • Page 9: Before You Clean

    A. Spray the BISSELL Tough Stain Precleaner formula onto heavy traffic areas, soiled areas, or stains. B. Allow to penetrate for at least 3 minutes. C. Clean as normal, using the BISSELL ProHeat 2X machine on the high traffic ATTENTION: setting, following the instructions on pages 10-12.
  • Page 10: Carpet Cleaning

    Remove formula tank from back of machine. 2a. Fill the formula tank by first unscrewing the cap and insert. Always use genuine BISSELL formulas to maximize cleaning and for the safety of your machine. Fill formula up to the line and replace the cap and insert.
  • Page 11 After cleaning, you may want to turn the Keep plenty of genuine BISSELL deep Custom Clean dial to water rinse to give cleaning formula and Scotchgard ™...
  • Page 12 peration Carpet cleaning (continued) 8b. Remove the top of the tank by lifting up on the handle. Note: Be sure to note how the lip on the top tank separates from the groove in the bottom tank. This placement is important when putting the tank back together.
  • Page 13 peration Cleaning with attachments Your ProHeat 2X machine comes equipped with a hose and at least one attachment for cleaning stairs, upholstery, and more. Important! If using to clean upholstery, check upholstery tags. A. Check manufacturer’s tag before cleaning. “W” or “WS” on the tag means you can use your ProHeat 2X.
  • Page 14 Cleaning formula section damage, use only BISSELL deep cleaning formulas Keep plenty of genuine BISSELL advanced deep cleaning intended for use with the formula for full size machines on hand so you can clean deep cleaner. Non-BISSELL and protect whenever it fits your schedule. Always use cleaning solutions may genuine BISSELL deep cleaning formulas.
  • Page 15 If cleaning on Berber carpeting, gently run your machine over a hidden area. If no fuzzing occurs, continue cleaning in soiled area. 6a. Using the BISSELL Tough Stain PreCleaner, spray evenly over soiled area. Do not overwet. Wait 3-5 minutes. Gently work the solution by blotting area with a clean, damp, color safe cloth.
  • Page 16 Move any furniture, if needed. Empty any carpet cleaning formula back into the BISSELL bottle if stored in the formula tank. Fill formula tank with BISSELL Hard Floor Solutions. Fill the 2-in-1 water tank with hand hot tap water and set aside.
  • Page 17 Post-treatment Scotchgard Protector (optional) Some models are equipped with a Scotchgard protector post-treatment applicator and cartridge. Use this, along with one of the BISSELL deep cleaning formulas containing Scotchgard, to help retain the carpet cleanliness achieved with the ProHeat 2X machine. For best results, the post cleaning treatment should be applied while the carpet is still damp.
  • Page 18: Machine Storage

    peration Post-treatment Scotchgard Protector (optional) continued Be careful not to spray the Scotchgard protector onto furniture or fabric that has not been tested for colorfastness. If this does occur, wipe off the Scotchgard protector. 10. When finished remove the cartridge from the applicator tool.
  • Page 19: Machine Care

    aintenance and care Machine care For best results, a few simple steps can assure WARNING: your machine is well maintained after your To reduce the risk of fire, cleaning is complete. electric shock or injury Turn power and heater switches to the OFF unplug from outlet before ( O ) position.
  • Page 20 aintenance and care Machine care (continued) The inside of the end caps by the brush rolls can be wiped out with a clean paper towel or, if a more thorough cleaning is desired, the end caps can be taken off using a Phillips head screwdriver and rinsed clean.
  • Page 21 aintenance and care Small belt removal and replacement Occasional replacement of one or both belts may become necessary. If that is needed, please follow the instructions below. Turn off the machine and unplug it from the outlet. Remove both the 2-in-1 water tank and the formula tank.
  • Page 22 If you have any questions or are having trouble installing or replacing your belt(s) or brushes, please call BISSELL Consumer Services. w w w . b i s s e l l . c o m ug120-4042_9500E.indd 22 ug120-4042_9500E.indd 22...
  • Page 23 1. Fill heavy duty bladder with hand hot tap water. 2. Formula tank may be empty. 2. Fill formula tank with BISSELL deep cleaning formula. 3. 2-in-1 water tank may not be 3. Turn power switch OFF ( O ).
  • Page 24: Please Do Not Return This Product To The Store

    Other maintenance or service not included in the manual should be performed by an authorized service representative. Thank you for selecting a BISSELL product. Please do not return this product to the store. w w w . b i s s e l l . c o m ug120-4042_9500E.indd 24...
  • Page 25 If your BISSELL product should require service: In the UK, Australia or New Zealand, call BISSELL Consumer Services at the numbers below and we will give you the location of a BISSELL Authorized Service Center in your area. For all other countries, contact your local in country distributor for questions, service, or repair.
  • Page 26 - BISSELL ProHeat 2X Below is a list of common replacement parts. While not all of these parts may have come with your specific machine, all are available to you for purchase, if desired. Item Part No. Part Name 203-6651 3”...
  • Page 27 - BISSELL ProHeat 2X (continued) w w w . b i s s e l l . c o m ug120-4042_9500E.indd 27 ug120-4042_9500E.indd 27 5/7/08 3:37:50 PM 5/7/08 3:37:50 PM...
  • Page 28 Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for two years any defective or malfunctioning part do to manufacturers defect.
