10 Creating a method
10.1 The Method Editor
10.1.1 Introduction to the Method Editor
Opening the Method Editor
Open the Method Editor window from the UNICORN Manager module by clicling Method
Editor it in the task bar at the bottom of the screen.
Step
1
2
3
144
Action
Click the Customize panes icon in the
Method Editor toolbar.
Select the Text and Instruction box
checkboxes in the Customize panes
dialog box shown.
Click OK.
The upper part of the Method Editor
window now shows the Text pane
and the lower part the Instructions
box. It is possible to also show an op-
tional flow diagram, or a block dia-
gram in the Method Editor, by select-
ing the appropriate items in the Cus-
tomize panes dialog box. These dia-
grams can help when programming
advanced methods, but are not re-
quired for building or editing a
method. They are therefore not includ-
ed in the following discussion.
