HYDRO-RAIN ORBIT SPRINKLER SYSTEM DESIGNER Installation Manual page 3

WelCoMe
Thank you for using OrbIT
Step-by-Step Installation Guidelines
•
Personalized Sprinkler Plan -
•
Assembly and Installation Drawings
•
Personalized Parts List - www.irrigationdepot.ca
•
Please use the provided Checklist below as you go through the installation process to ensure you have an
irrigation system you will be proud of and enjoy for many years to come.
Please see www.irrigationdepot.ca for all Blu-Lock or Eco-Lock fittings.
If you have any questions or concerns please email us at info@irrigationdepot.ca
CHeCKlIst
r
become Familiar with the Installation guide
1
r
2 Consult a local expert and Check local Codes
r
3 Call Utility Providers to mark Utility lines
r
4 Purchase Additional materials
r
5 Install Backflow Prevention Device and Shut-off Valve
r
6 mark Sprinkler, Trench and manifold locations
r
7 Dig Trenches
r
8 Install Valve manifolds
r
9
Install Poly Mainline Pipe with Insert Fittings
r
Install Pipe and Fittings for Sprinkler Zones
10
r
11 Install Auto-Drains (Freezing Areas only)
r
12 Install Sprinkler Timer
r
13 Install Sprinkler Wires
r
14 Turn Water Source On
r
15
Check Poly Mainline and Manifolds for Leaks
r
Test each Zone
16
r
17 Install Heads and nozzles and Adjust Patterns
r
18 Install Valve Boxes and Backfill Trenches
r
19 Fine Tune nozzles and Patterns
r
20 Set Sprinkler Timer
ORBIT
SPrInkler SySTem DeSIgner™. In the following pages you will find:
®
