dRIP stuB fIttInG
See
www.irrigationdepot.ca
A
3/4" x 1/2" FPT Blu-Lock Elbow
B
3/4" Blu-Lock Pipe
C
3/4" Blu-Lock Elbow
ORBIT
SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde
®
for drip design options
B
drip system
starts here
A
this part of the
fitting should be
buried below ground
B
C
A22
