HYDRO-RAIN ORBIT SPRINKLER SYSTEM DESIGNER Installation Manual page 17

10. Install PIPe and fIttInGs foR sPRInKleR zones (C
8 Install 3/4" tee or 3/4" x 3/4" x 1" tee and 3/4"
or 1" pipe at the location of the trench that
leads from this zone back to the manifold.
Do not install heads at this time. We will install heads in another section.
Install 3/4" elbow and cut and install pipe. Stagger the pipes from the valves so there is room for all the
10
zones (see below).
2.5" length of 3/4"
Blu-Lock Pipe
ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde
®
Cut pipe in line with the
9
edge of the valve to
which it will connect.
ONT'D)
