HYDRO-RAIN ORBIT SPRINKLER SYSTEM DESIGNER Installation Manual page 20

12. Install tHe tIMeR (Cont'd)
Use the mounting template (included) to mark
the mounting screw location on the wall. See
Figure 1
Install a no. 8 screw (included) into wall in the
upper template location. leave the screw head
protruding 1/8" (3mm) from wall. Use expanding
anchors (included) in plaster or masonry, if
necessary, for a secure hold.
4.17"
(106 mm)
3
dimensions:
proof no:
fl at: w: 9"
date: 10.05.07
fi nished: w 9"
des: spck:
SM SM colors
figure 1: use Mounting template (included)
