Summary of Contents for HYDRO-RAIN ORBIT SPRINKLER SYSTEM DESIGNER
- Page 1 INSTALLATION GUIDE 53251-27 rA...
-
Page 2: Legal Notice
IntelleCtual PRoPeRtY notICe expert prior to installation. Although every effort has been OrbIT SPrInkler SySTem DeSIgner™ is a trademark made to ensure that the application and output produce of Orbit . Orbit’s trademarks may not be used in ®... - Page 3 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® WelCoMe Thank you for using OrbIT SPrInkler SySTem DeSIgner™. In the following pages you will find: ® Step-by-Step Installation Guidelines • Personalized Sprinkler Plan - www.irrigationdepot.ca • Assembly and Installation Drawings • Personalized Parts List - www.irrigationdepot.ca •...
-
Page 4: Before You Begin
ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® BefoRe You BeGIn 1. BeCoMe faMIlIaR WItH tHe InstallatIon GuIde We recommend that you read through the entire Installation guide before you begin. keep track of the items not provided and make a list of those things you will need to purchase. This will help keep the number of trips back to the store to a minimum. - Page 5 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® BefoRe You BeGIn 4. PuRCHase addItIonal MateRIals Check that you received all the materials listed on the packing list that came with your delivery. Check the packing list against the Installation guide Parts list to determine what you need to buy at your local Home hardware.
- Page 6 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® BefoRe You BeGIn 5. Install BaCKfloW PReventIon devICe and sHut-off valve (Cont’d) We recommend that you install a 3/4" or 1" PVC Ball this design plan Valve immediately following does not apply to anything before the backflow prevention this point;...
- Page 7 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 6. MaRK sPRInKleR, tRenCH and ManIfold loCatIons before you begin this step you should study the maps carefully and make adjustments to head placement, sprinkler zones, piping, and manifold placement as necessary. Please note that the maps provided are for guidance only and can and should be adjusted based on actual conditions (i.e.
- Page 8 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 8. Install valve ManIfolds For each valve box dig a 26" x 20" hole to the recommended 20" depth (shown below). For best installation the valve box should run parallel to the pipe trench as shown to the right. 26"...
-
Page 9: Valve Manifold
ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 1 valve ManIfold A 3/4" or 1" Poly Adapter - 57188 or 57189 B Swivel Double Union - 57184 3/4" or 1" Blu-Lock Pipe C 1 Port Manifold - 57181 D 1" Swivel Adapter - 57199 E 1"... - Page 10 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 2 valve ManIfold A 3/4" or 1" Poly Adapter - 57188 or 57189 B Swivel Double Union - 57184 3/4" or 1" Blu-Lock Pipe C 2 Port Manifold - 57182 D 1" Swivel Adapter - 57199 E 1"...
- Page 11 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 3 valve ManIfold A 3/4" or 1" Poly Adapter - 57188 or 57189 B Swivel Double Union - 57184 C 2 Port Manifold - 57182 D 1" Swivel Adapter - 57199 E 1" Jar Top Valve - 57461 F 3/4"...
- Page 12 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 4 valve ManIfold A 3/4" or 1" Poly Adapter - 57188 or 57189 3/4" or 1" Blu-Lock Pipe B Swivel Double Union - 57184 C 2 Port Manifold - 57182 D 1" Swivel Adapter - 57199 E 1"...
- Page 13 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® dRIP zone asseMBlY step 1: Remove valve from manifold step 2: Remove adapter from valve step 3: Put 5 complete turns of tape around the step 4: thread the filter Pressure threads of each end of the filter Pressure Regulator Regulator into the valve until snug step 6: Reattach valve to manifold Step 5: Thread 1"...
- Page 14 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 9. InSTAll PVC MAInlInE PIPE Starting from the Water Source Connection lay and connect the PVC pipe going to the manifolds (see Starting from the Water Source Connection lay and “Working with PVC” in the appendix of this guide for connect the Blu-Lock Pipe or Poly Pipe going to additional information).
- Page 15 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 10. Install PIPe and fIttInGs foR sPRInKleR zones We will now step you through the process of installing the Blu-Lock pipe from the heads to the valve for each sprinkler zone (see "Working with Blu-Lock" in the appendix of this guide for additional helpful information).
- Page 16 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 10. Install PIPe and fIttInGs foR sPRInKleR zones (Cont'd) Cut the pipe at the repeat for all Lay 3/4" Blu-Lock next head location remaining head pipe in the trench and install the locations on and install end head fittings as shown.
- Page 17 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 10. Install PIPe and fIttInGs foR sPRInKleR zones (C ONT'D) Cut pipe in line with the Install 3/4" tee or 3/4" x 3/4" x 1" tee and 3/4" edge of the valve to or 1"...
- Page 18 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® dRIP stuB fIttInG www.irrigationdepot.ca for drip design options 3/4" x 1/2" FPT Blu-Lock Elbow 3/4" Blu-Lock Pipe 3/4" Blu-Lock Elbow drip system starts here this part of the fitting should be buried below ground...
-
Page 19: Indoor Installation
ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 11. Install auto-dRaIns (fReezInG aReas onlY) Where freezing is a concern we recommend you install auto-drain valves at the low spots in the system and on the downhill ends of sloping pipes. The auto drains must be at the lowest points in the line. Do Not install auto-drains on the Poly mainline 12. - Page 20 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 12. Install tHe tIMeR (Cont'd) PROGRAM RAIN DELAY RESET Slip the timer over protruding screw (using Use the mounting template (included) to mark keyhole slot in back of timer). See Figure 2 the mounting screw location on the wall. See Figure 1 Drive a no.
- Page 21 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 13. Install sPRInKleR WIRes run the wire from the timer to each manifold using the existing trenches. Use the WIRInG MaP and the diagrams below as a guide. The wire provided is rated for direct burial but you may chose to run the wire inside a conduit to prevent future damage to the wire.
- Page 22 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 14. tuRn tHe WateR souRCe on Bleed Screw make sure the bleed screw on all the valves is in the closed position (turn clockwise to close). Slowly turn the mainline water source on. make sure all shut-off points prior to the valves are in the on position.
- Page 23 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® Match the nozzle called out on the Irrigation Depot Plan to the corresponding head nozzle chart. Nozzle 4', 6', 8', 10', 12', 15' Adjustable EST 5' x 15' A 4" Spray Head SST 5' x 30' B 3/4"...
- Page 24 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® A19 PATTERN ADJUSTMENT INSTRUCTIONS lift stem up Insert grey Hold the base rotate the Hold the noz- using the pull nozzle filter of the nozzle ratcheting zle as shown tab. Hold stem into stem and with your left stem until the in step 3 and...
- Page 25 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® A20 AND A21 PATTERN ADJUSTMENT INSTRUCTIONS set the Pattern Before Installation: Adjustment Video gear drive sprinkler can be set to rotate between 40° and 360° (preset at 180°) Turn the top of the head all the way to the left until it stops and then all the way to the right.
-
Page 26: Set The Timer
ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® 18. Install valve Boxes and BaCKfIll tRenCHes Once you have verified there are no leaks install all the valve boxes for the system and backfill the trenches. When backfilling trenches make an effort to ensure there are no large rocks resting on or against the pipes and fittings. - Page 27 WORKING WITH POLY PIPE Orbit Sprinkler System Designer specifies Poly Pipe for all mainline pipe and connections after the source connection up to and including the valve manifolds (the valves control water flowing to the individual areas or "zones" in your yard).
- Page 28 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® aPPendIx JoInInG PvC tHReaded fIttInGs Tools and Materials Required: Fittings, pipe tape, channel locks The most common way to join PVC threaded fittings is with PTFE or “Teflon” tape. You should never use oil-based pipe dope (typically comes in a tube) to join sprinkler fittings.
- Page 29 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® aPPendIx WoRKInG WItH Tools and Materials Required: Fittings, pipe tape, channel locks Blu-Lock is the fastest way to install an automatic sprinkler system and it offers several other distinct advantages over insert fittings. While Poly pipe, fittings and joints are well-suited to the constant-pressure environment of the mainline - which is typically about 10-20% of the total pipe in your system - Blu-Lock is ideally suited for all sprinkler zone pipes (those going out from the valve manifold) because it is fast to install, flexible, has a very long useful life, is clean to produce, and is recyclable.
- Page 30 ORBIT SPRINKLER SySTEm DESIGNER™ InstallatIon GuIde ® aPPendIx JOINING 3/4" AND 1" BLU-LOCK PIPE AND FITTINGS TO POLY PIPE 3/4" and 1" Blu-Lock pipe have the same internal dimensions (ID) as 3/4" and 1" poly pipe. However, you should never use Blu-Lock fittings with another manufacturers poly pipe. In the event that your store does not carry 3/4"...
- Page 31 Orbit Sprinkler System Designer ® ™ MaPs and PaRts lIst www.irrigationdepot.ca...
