18. Install valve Boxes and BaCKfIll tRenCHes
Once you have verified there are no leaks install all the valve boxes for the system and backfill the
trenches.
When backfilling trenches make an effort to ensure there are no large rocks resting on or against the pipes
and fittings. As your soil settles with time large rocks can cause premature failure.
Be careful not to cut or damage the sprinkler wires when backfilling. It is very difficult to find and repair bad
wiring after the system is buried.
19. FInE TUnE noZZlES AnD PATTERnS
After filling in the trenches, manually turn on each sprinkler zone one at a time and fine tune the nozzle
spray patterns. refer to the nozzle adjustment pages as needed.

20. set tHe tIMeR

Using the instructions booklet included with the timer set the desired program.
