PX710
DMX
Controller
MANUAL
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMX Controller and is the answer not in the manual?

Questions and answers

Related Manuals for PXM DMX Controller

Summary of Contents for PXM DMX Controller

  • Page 1 PX710 Controller MANUAL...

  • Page 2: Table Of Contents

    Declaration of conformity................The manufacturer reserves the right to change the operation and handling of the controller in order to improve the product. tel.: (12) 385 83 06 PXM Marek Żupnik spółka komandytowa fax: (12) 626 46 94 Podłęże 654 E-mail: info@pxm.pl 32-003 Podłęże...

  • Page 3: General Description

    2. SAFETY CONDITIONS Controller PX710 DMX Controller s a device powered with safe voltage 12-24 V; however, during its installation and use the following rules must be strictly observed: 1.

  • Page 4: Device Design And Description Of Connectors

    3. DEVICE DESIGN AND DESCRIPTION OF CONNECTORS MAIN CONTROLLER PX710M RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN Designations: Power supply DMX output (512 channels) DMX input (512 channels) KBD - for future applications EXT - connection to an external touch panel...
  • Page 5 EXTENSION MODULE PX710S SYNC Designations: Power supply DMX output (512 channels) DMX input (512 channels) Synchronization - for future use CAN bus Ethernet connector Reset 4 indicator lights...

  • Page 6: Connection Method

    4. CONNECTION METHOD a) power connection for DMX output and DMX input efekts power supply e.g. PxArt lamps controller 12-24 V DC e.g. PX333 RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN...
  • Page 7 b) Connection between a master controller (MASTER) and expansion modules (SLAVE) RX+ RX- TX+ TX- VCK+ SYNC maximum 7 expansion modules 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN (SLAVES) SYNC SYNC NOTE: It is necessary to connect a 120 Ω...
  • Page 8 c) connection of analogue inputs (this applies only to PX710M) REMOTE 0-10V OUT 0-10V IN 0 - 10V IN 0 - 10V IN 0 - 10V IN 0 - 10V IN SOURCES SIGNAL 0 - 10V REMOTE 0-10V OUT 0-10V IN +10V OUT POTENTIOMETERS...
  • Page 9 d) connection of digital inputs (this applies only to PX710M) Sink in type - positive logic input - "joint plus" Ÿ Power Supply 12 - 24 V DC e.g. input buttons controller connectors...
  • Page 10 Source in type - negative logic input - "joint mass" Ÿ Power Supply 12 - 24V DC e.g. input circui controller connectors...

  • Page 11: Network Settings For The Driver

    5. NETWORK SETTINGS OF THE CONTROLLER The controller stores the static network configuration. It is always used when static addressing mode was selected or in automatic addressing mode, when it was not possible to get the configuration settings from the DHCP server. The controller can run in one of the two modes: þ...
  • Page 12 Below are some typical examples of network configuration: a) Automatic addressing Smartphone: smartphone receives Router: configuration on its own np.: 192.168.0.100 Mask: 255.255.255.0 þ DHCP server RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN...
  • Page 13 c) Static addressing Smartphone: 192.168.0.2 Mask: 255.255.255.0 Default gateway: 192.168.0.100 Router: 192.168.0.100 Mask: 255.255.255.0 ¨ DHCP server RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN PX710: 192.168.0.50 Mask:...
  • Page 14 d) External connection To connect via the Internet: Have an external IP address on the router assigned by your ISP, and have the possibility to connect externally (incoming packets are not blocked by the ISP’s firewall), Forward any two ports (must be one after the other) to the IP address of the controller working in the internal network, and to ports 50000 and 50001 UDP/TCP (port forwarding) Unblock the selected ports on the router firewall The address of the controller/controllers on the internal network cannot change (the...
  • Page 15 Router: 192.168.0.100 Mask: 255.255.255.0 ¨ DHCP server Port forwarding external IP address RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN INTERNET PX710: 192.168.0.50 Mask: 255.255.255.0 Gate: 192.168.0.100 ¨...
  • Page 16 Router: 192.168.0.100 Mask: 255.255.255.0 ¨ DHCP server Port forwarding external IP address 188.188.188.188: 50000 for example: 188.188.188.188: 50000 188.188.188.188: 60000 RX+ RX- TX+ TX- VCK+ SYNC 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN PX710: INTERNET...

  • Page 17: Changing The Network Configuration Of The Computer

    5.1. Change of the computer network configuration The procedure for changing the computer network configuration varies depending on the ® operating system. Windows 7 system is an example here. Change of the computer network configuration in the ® Windows operating system is done in the following way: 1.
  • Page 18 ® Change of the computer network configuration in Mac OS X operating system is done in the following way: 1. Click Start menu 2. Select the tab [System Preferences...] 3. Go to the tab [Network] 4. Highlight [Ethernet] 5. Configure IPv4: [Using DHCP] 6.

  • Page 19: Installing Software

    1. Open an installation file, click [Next] to go to the software installation. The installation file is attached to the driver on a CD, or available for download from the http://pxm.pl 2. Select the folder in which the software is to be installed. Confirm your selection by clicking the [Next] button.

  • Page 20: Android™ Platform

    1. Upload *.apk installation file available on the CD supplied with the device or downloaded from the PXM website to your phone, or download an app from the Play Store using QR code: 2. Go to your phone settings and then check “Allow installation of apps from sources other than the Play Store ”...

  • Page 21: Controller Configuration

    8. CONTROLLER CONFIGURATION The controller operates in accordance with the loaded configuration which is created and uploaded using the PxDesigner application. The method of creation of a configuration file is described in the manual for PXDesigner_M. As part of the configuration, you can set the parameters for all inputs and outputs, create users and relevant configuration items: AREA/ZONE A physical area (e.g.
  • Page 22 Once the "turn on scene" action is triggered, the scene will be activated with the rise time, and will last as long as the duration and will turn off automatically with the drop time. If, before the expiry of the duration the "turn off scene" action is triggered, the scene will also be turned off with the drop time.
  • Page 23 MASK A mask is a set of values assigned to output channels, which modifies a value at the DMX output. Masks take precedence over scenes and programs. There are 3 types of masks: proportional - it changes all values in the channel proportionally to the value of the mask Ÿ...
  • Page 24 Mask parameters: name Ÿ rise time Ÿ duration Ÿ drop time Ÿ zone to which it belongs Ÿ value for all DMX channels of the zone Ÿ type: Ÿ - proportional - minimum value - maximum value If several masks are turned on at a time: From all the proportional masks turned on in the zone, the lowest value for each channel is Ÿ...
  • Page 25 STATUS A status is an internal state of the device that allows for a conditional start of selected actions. The status can be switched on and off. The fact whether the selected status is turned on or off determines the execution of another action (e.g. Scene start). GROUP OF ASSOCIATED ITEMS Scenes and programs belonging to the same area can be within one group of associated items.
  • Page 26 An example of a value transition in a channel for non-associated items: value value value start time the beginning the beginning the end of time of fade in time of fade out time transition transition time EVENT An event is the execution of a list of actions as a reaction to a specific signal. Events can be generated in different ways: internal - can be triggered by: Ÿ...
  • Page 27 ACTION LIMITATIONS Each action on the list may have its conditions that must be met to trigger the action. All conditions for a given action must be met at a given time. a) Daily limitation only during the day - from sunrise to sunset Ÿ...

  • Page 28: Controller Operation

    9. CONTROLLER CONFIGURATION The controller works in accordance with a preloaded configuration: in response to relevant events it executes the programmed actions that can turn on or off the selected configuration items. Triggering events and starting configuration elements is done in the master controller. Expansion modules only have additional DMX outputs.

  • Page 29: Modbus

    9.2. Modbus The controller supports the Modbus protocol. A PX340/PX345/PX710 controller operates as a server (slave) to which an application / a device operating as a client (master) connects. The master establishes a connection through TCP port 502 (a standard Modbus port) using the current IP address of the controller.
  • Page 30 EXAMPLE 1: A query about 10 first DMX channels in hexadecimal notation reads as follows: 00 00 00 00 00 06 00 20 00 00 0A PDU explained: – Modbus function code: 03 or “Read Holding Registers” 20 00 – address of the register being read - 0x2000 = 8192 – corresponds to DMX output channels 00 0A –...
  • Page 31 EXAMPLE 3: Hexadecimal notation for a TCP frame that triggers scene No 1: 00 00 00 00 00 0B 00 00 00 00 01 00 00 00 00 00 00 00 00 00 07 00 00 00 00 01 PDU explained: –...
  • Page 32 Below there are presented Modbus commands supported by the controller: a) Commands Modbus command Controller reaction standard Read Coils not supported Read Holding registers returns the state of digital inputs in bits Read Input Registers returns the status of the controller not supported Write Single Coil Write Single Register...
  • Page 33 b) Returned states Element Size Description state master Scene status time left [ms] data reserved state master speed Program status data repeat count current step step time left [ms] reserved state master Mask status data time left [ms] reserved state current step Sequence status data time left [ms]...
  • Page 34 c) Action Number Action Parameters no action scene number scene number scene number SOLO scene number TOGGLE scene number Scene PAUSE scene number RESUME scene number SET MASTER scene number master value INCREASE MASTER scene number DECREASE MASTER scene number mask number mask number SOLO...
  • Page 35 Number Action Parameters sequence number Sequence sequence number OFF ALL sequence number delay number Delay delay number RESTART delay number status number Status DELETE status number TOGGLE status number DMX INPUT ON Transmission DMX INPUT OFF Send a signal to the panel address panel signal number SET MASTER...

  • Page 36: Live Mode

    d) Register addresses Addressing Size Data Read / Write 0x0000 - 0x01FF 1 kB Modbus input channels R / W 0x0400 - 0x05FF 1 kB DMX input channels 0x0800 - 0x09FF 1 kB analogue input channels 0x0C00 - 0x0FFF 2 kB digital inputs 0x1400 - 0x15FF 1 kB...

  • Page 37: Indication Lights

    9.4. Indication lights The controller is equipped with 4 indicator lights: Indicator light Function data collection; DATA when data packets are collected from the PC or Ÿ smartphone application - the indicator light flashes digital inputs state; INPUTS each short-circuit of one of the inputs causes the light Ÿ...

  • Page 38: Reset Button Operation, Restoring Default Settings

    9.5. RESET button operation, restoring default settings Action Reaction Holding down the button when the Switching the device to the core mode power supply is turned on Holding down the button for 2 seconds Switching the device to the normal operating when the device is in the core mode mode Holding down the button for 5 seconds...

  • Page 39: Core Mode, Ftp Support

    9.6. Core mode, FTP support After switching to the core mode (stop in the bootloader), you can connect to the controller using the FTP protocol. In this mode, you should always connect to the default static address of the controller from the ADMIN account level, by providing the default password (device serial number) –...

  • Page 40: Technical Specifications

    10. TECHNICAL SPECIFICATIONS - power supply: 12 - 24 V DC - max. current consumption: 400 mA - weight: 0,3 kg - dimensions: width: 157,5 mm (9 DIN rail modules) height: 86 mm depth: 60 mm PX710 DMX output channels 1024 (+ 7x 1024) DMX input channels ON/OFF inputs...

  • Page 41: Technical Drawing

    11. TECHNICAL DRAWING RX+ RX- TX+ TX- VCK+ SYNC REMOTE 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN 157,5 mm 60 mm...

  • Page 42: Declaration Of Conformity

    012 385 83 06 http://www.pxm.pl 32-003 Podłęże fax: 012 626 46 94 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże We declare that our product: Product name: DMX Controller Product code: PX710 smeets the requirements of the following standards as well as harmonised...
