- Page 1 TORCHMATE® 4400 | 4800 | 4510 SITE PREP GUIDE October 16, 2020 Copyright 2020 Lincoln Electric Cutting Systems...
- Page 2 Torchmate 4400/4800/4510 Page ii...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Unpacking the machine Site Preparation Grounding the Machine Power/Water/Air Requirements Power Supply Requirements viii Commissioning, Operations, Software Training Optional Pre-Onsite Training Technical Support Customer Assistance Policy Site Prep Guide Page iii... - Page 4 Verify all items have been shipped without damage before you accept the order from the shipping company. Notify Lincoln Electric® 775-673-2200 to report any shipping damages. Your machine was fully tested at the factory and a cut metal sample can be found in the waterbed of the machine.
-
Page 5: Site Preparation
SITE PREPARATION When installing a Lincoln Electric CNC Cutting System in your shop, there are many factors that will influence the potential productivity, ease of use of the machine and the safety of the operator. The main factors to prepare for include: the physical layout and placement of the machine in the shop, the availability of power, an EMI ground, compressed air and other gasses, and ventilation. -
Page 6: Grounding The Machine
If the work piece is painted or dirty, it may be necessary to expose the bare metal to make a good electrical connection. Torchmate 4400/4800/4510 Page vi... -
Page 7: Power/Water/Air Requirements
Please refer to the FlexCut operators manual for complete installation and operation guidelines. Only a qualified electrician should connect the input leads to the Torchmate 4400/4800/4510 CNC unit and FlexCut Plasma unit. Connections should be made in accordance with all local and national electrical codes. Failure to do so may result in bodily injury or death. - Page 8 TORCHMATE 4400/4800/4510 POWER SUPPLY SPECIFICATIONS POWER CHOOSE YOUR 3/4” 1” CUT CAPACITY CUT CAPACITY FLEXCUT® 80 FLEXCUT® 125 Rated Input Input Power Air Pressure Product Name Current/Voltage/Duty Production Cutting Capacity Voltage/Phase/Hz Required Cycle 208/230/400/460/575 60A/140V /100% 3/4” Mild Steel 3PH 50/60Hz...
-
Page 9: Commissioning, Operations, Software Training
Torchmate is not able to provide third-party CAD training. Any work outside the agreed scope will be billed separately for time and material via an approved Lincoln Electric Cutting Systems extra work order. Lincoln Electric Cutting Systems defines a workday as a typical 8 hour day with a 1-hour lunch break. Overtime hours requires approval. - Page 10 - All required gases onsite with regulators. (Gas regulators are not included) (Optional) • The Lincoln Electric FlexCut 125 requires 3 phase 50 / 60 Hz input, FlexCut 80 requires 1 or 3 phase 50 / 60 Hz input. •...
-
Page 11: Technical Support
TECHNICAL SUPPORT | ON-SITE SERVICE Lincoln Electric Cutting Systems provides a number of technical support opportunities with the purchase of your new 4400, 4800, or 4510 Torchmate CNC cutting machine. The following is a brief outline of available options. Onsite visits are available at an additional cost, call 775-673-2200 for additional information. -
Page 12: Customer Assistance Policy
We respond to our customers based on the best information in our possession at that time. Lincoln Electric Cutting Systems is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s...
