ACPL-337J Reference Manual
Chapter 3: System Description
This chapter provides the EB600-337J specifications and functional description, interfaces, and mechanical details.
3.1 Key Specifications
Table 1
lists the absolute maximum ratings of the EB600-337J. Note that
from ACPL-337J data sheet as well as specifications of other key components must be considered when the EB600-337J
is used.
Table 1: Absolute Maximum Ratings
Parameter
V
to V
when the DC
dc+
dc–
bus supplied externally
Input rectifier line to line
RMS voltage
Brake chopper current
Inverter IGBT peak
current
Continuous RMS current
V
input voltage
CC
PWM input logic level
Fault output logic level
UVLO output logic level
3.2 Functional Block Diagram
Figure 2
shows the functional block diagram and
gate evaluation board. In the middle of the system is a power integrated module (yellow), and its DC terminals are connected
to a DC bus capacitor bank (blue). The DC bus can be supplied with an AC power source by using an integrated three-phase
diode rectifier, or externally through the DC bus terminals. If a diode rectifier is used, the negative side of the diode rectifier
(N_REC) and the negative side of the DC bus (–DC_BUS) must be shorted. The DC bus terminals as well as other power
terminals are shown in grey in
side of ACPL-337J drivers are presented in green.
Broadcom
Values
Min.
Typ.
—
300
—
208
—
—
—
—
—
—
21.6
24
0
3.3
0
—
0
—
Figure 3
Figure
2. Low-voltage side connectors aimed for signal interface and power supply of digital
Infineon EasyPIM™ 1B IGBT Module EB600-337J Evaluation Board
Table 1
Max.
Units
400
V
Limited by the voltage overshoot during turn-off
transient. DC bus capacitors voltage rating is 450V.
240
V
N_REC terminal should be shorted with -DC_BUS
terminal, and one of the following conditions should be
satisfied if the board is powered through three-phase
AC lines (L1, L2, L3):
—
A
Limited by the power module ratings.
—
A
Limited by the power module ratings.
—
A
Limited by the power module ratings and the heatsink
characteristics.
26.4
V
External DC input power supply for the digital circuitry.
5
V
External PWM inputs for the gate drivers; thresholds
are defined in the ACPL-337J data sheet.
5
V
Logic output signal, refer to the ACPL-337J data
sheet.
5
V
Logic output signal, refer to the ACPL-337J data
sheet.
shows the disposition of the functional blocks of the EB600-337J
contains only key parameters. Constraints
Note
Pre-charge circuit is added externally.
Powering the board through an autotransformer
enables smooth charging of the DC bus.
ACPL-337J-EB600-RM100
9
