ACPL-337J Reference Manual
Infineon EasyPIM™ 1B IGBT Module EB600-337J Evaluation Board
Figure 20: Measurement Results from DESAT Detection, Direct Short Circuit at V
= 300V, CH1 (Yellow) V
, CH3 (Blue) V
,
dc
ce
ge
CH4 (Green) V
, F6 (Red) I
dc
c
Broadcom
ACPL-337J-EB600-RM100
23
