Specifications and External Dimensions
General specifications and external dimensions are given below.
General Specifications
Item
Power supply
Ambient operating temperature
Ambient operating humidity
Ambient operating atmosphere
Storage temperature
Display
Weight
External dimensions
External Dimensions (Unit: mm)
Appendix C
+5%
300 mA max. at 5 VDC
0°C to 55°C
10% to 90% RH (no condensation)
No corrosive gasses
–20°C to 75°C
Semi-transmissive liquid crystal display (with LED) 16 characters x 4 rows;
5 x 7 dots/character
400 g
192 x 96 x 48.5 mm (H x W x D)
96
DEC
PAUSE
START
STOP
MON
JOG
MPG
ORIG
PROG
EXT
SRCH
EXEC
7
8
9
4
5
6
1
2
3
0
.
CLR
Specifications
/
, (Supplied from the MC Unit.)
–10%
ERR
CLR
192
CHG
TEACH
TASK
OVER
CHG
RIDE
+
–X
+X
WRITE
–Y
+Y
YES
–Z
+Z
NO
–U
+U
48.5
15.5
29.6
85
