Label Carrier

The isolated barriers are fitted with a label carrier ex works for individual identification.
Figure 2.20 Label carrier on the front
1 Label carrier on KC devices for 22 mm x 9 mm labels
2 Label carrier on KF devices for 22 mm x 16.5 mm labels
Label carrier on KF devices (old version) for 18 mm x 8 mm labels
3
2.8

DIN Mounting Rail

The devices are mounted on a 35 mm DIN mounting rail according to EN 60715.
Figure 2.21 Example: DIN mounting rail UPR-MR (35 mm x 15 mm)
1 2 2 3
