Status Indicators of the Isolators

LEDs are often used on isolators to indicate different statuses (e. g. for power supply,
device failure, status messages, binary switching states). Standard LED colors are assigned
to the status display according to NAMUR NE44.
LED Display function
Green LED Power supply
Red LED Device fault, device
failure
Line fault
No fault
Yellow LED Switching states of
binary inputs and
outputs
Table 2.1 Meaning of status indicators
Figure 2.14 Example status indicators
1 Yellow LED "OUT"
Switching state of the output
2 Red LED "CHK"
Lead breakage and short circuit status indicator
3 Green LED "PWR"
Power supply status indicator
16
Display Meaning
On Power supply OK
Off No power supply or insufficient power supply – device
faulty
On Internal fault signal, failure signal – fault/failure display
of causes detected inside the device, device needs
replacing
Flashing External fault signal, failure signal – fault/failure display
of causes detected outside the device, inspection
and elimination of fault required
Off No malfunction, device is operating properly
On Possible causes of the output:
• The relay is energized.
• The NO contact (also a change-over contact)
is actively closed.
• The open collector is switched through.
• The switching voltage generated inside the device
is applied.
Possible causes of the input:
• A binary switching signal is present.
• An analog limit value is reached.
Off Possible causes of the output:
• The relay is de-energized.
• The NO contact (also a change-over contact)
is actively opened.
• The open collector is not switched through.
• The switching voltage generated inside the device
is not applied.
Possible causes of the input:
• A binary switching signal is present.
• An analog limit value is reached.
1 2 3
OUT CHK PWR
