Swing-N-Slide PB 9210 Assembly Instructions Manual

Slide and 4’’ x 4’’ lumber sold separately
Hide thumbs Also See for PB 9210:

Advertisement

Quick Links

Download this manual
PB 9210
SLIDE AND 4'' x 4'' LUMBER SOLD SEPARATELY
ASSEMBLY INSTRUCTIONS
LDR: 05-15-2015
check out http://www.swing-n-slide.com/planupdates.htm
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
Set Dim. 14 '-6"W x 15 '-8"L x 10'H
Est. Building Time: 6-8 hr.
for updates to these instructions.
LA 7513

Advertisement

loading
Need help?

Need help?

Do you have a question about the PB 9210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swing-N-Slide PB 9210

Summary of Contents for Swing-N-Slide PB 9210

  • Page 1 SLIDE AND 4’’ x 4’’ LUMBER SOLD SEPARATELY check out http://www.swing-n-slide.com/planupdates.htm for updates to these instructions. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 LDR: 05-15-2015 LA 7513...
  • Page 2 PB 9210 Assembly Instructions Safety Checklist for Swing-N-Slide Play Sets and Accessories Observing the following statesments and warnings reduces the likelihood of serious or fatal injury. This playset has a weight capacity of 1200 pounds based on a maximum occupancy of eight (8).
  • Page 3 PB 9210 Assembly Instructions PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty.
  • Page 4 PB 9210 Assembly Instructions PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.

  • Page 5: Tools Required

    PB 9210 Assembly Instructions TOOLS REQUIRED HAMMER ELECTRIC DRILL SAFETY GLASSES CARPENTER’S SQUARE TAPE MEASURE & DUST MASK (2) 1/2’’ panhead screws 3/4’’ Pan Head Screw (2) 1-3/4’’ panhead screws Tarp Washers 1-1/4’’ Lag Screw 2” lag screw (4) 5/16’’Hex Head Lag Screws 30mm screws 5/16’’...
  • Page 6 PB 9210 Assembly Instructions (2) Shelf-Loc (2) Split Beam bracket Eye Strap Wrap-Loc (4) 2’’ x 4’’ Shelf-Loc Slotted Beam Clamp (2) EZ Frame Brackets (2) ‘L’ Brackets (2) Boomerang Brackets Step Brackets T20 Torx® Bit PB 9210 Plan T30 Torx® Bit Plan 3/8”...
  • Page 7 PB 9210 Assembly Instructions (4) Climbing Rocks (2) Safety Handles with Hardware Swing Hangers (4) Metal Rungs Climbing Rope 150 lb Weight Limit Name Plate (4) 58" Coated Chain with Hardware (2) 32" Coated Chain (2) Trapeze Rings Quick Links...

  • Page 8: Sold Separately

    PB 9210 Assembly Instructions SOLD SEPARATELY (1) 4'' x 4'' x 120'' (8) 4'' x 4'' x 96'' (1) 4'' x 4'' x 32'' (2) 2'' x 4'' x 35'' (3) 2'' x 4'' x 38'' (13) 2'' x 4'' x 47-1/2''...
  • Page 9 PB 9210 Assembly Instructions Playset Safety Area Min. Use Zone: 28 ’-4” x 27 ’-8” Set Dim. 14 ’-6”W x 15 ’-8”L x 10’H HEIGHT...
  • Page 10 PB 9210 Assembly Instructions How to select the correct fastener Use these 2 pictorial guides to help select the correct fastener(s) for the lumber attachment you are making. Each diagram will highlight the correct number of fasteners to use and where to attach them.
  • Page 11 PB 9210 Assembly Instructions Understanding how the Bracket System Works Example of a Shelf-Loc bracket connection. Shelf-Loc Bracket CORRECT! Wrap-Loc WRONG! Brackets ‘’clipped’’ brackets NOT interlocked! Example of a Shelf-Loc bracket connection. Look for ‘’TOP’’ stamp on bracket for correct orientation.
  • Page 12 PB 9210 Assembly Instructions Look for ‘’TOP’’ stamp on brackets while installing. 2’’ lag screws Per Bracket DO NOT USE LAG SCREWS HERE WRAP WRAP Use Lag Screws Only Where Brackets Attach BRACKET BRACKET 1-1/4’’ lag screws 1-1/4’’ lag screws...
  • Page 13 PB 9210 Assembly Instructions •WARNING• Avoid splitting your lumber by offsetting your screws at Look for ‘’TOP’’ Use a 2’’ lag screw stamp on brackets to hold bracket in while installing. place for later use. Fig. 2a Fig. 2 (2) 1-1/4’’ lag screws (2) 2’’...
  • Page 14 PB 9210 Assembly Instructions 1-1/4’’ Lag DO NOT USE LAG SCREW HERE 2’’ Lag NOTE: Upper screws are (2) 1-1/4’’ Lag Screws, Lower screws are (2) 2’’ Lag Screws. (2) 1-1/4’’ lag screws (2) 2’’ lag screws per bracket 2-1/2’’ screws per joint (2) 1-1/4’’...
  • Page 15 PB 9210 Assembly Instructions 2-1/2’’ screws 2-1/2’’ screws per joint per joint Frame 2 HINT: Pre drill 1/8” hole to help avoid splitting. 2-1/2’’ screw Double check to make Frame Assemblies Cont. Attach 5/8’’ x 3-1/4’’ x 24-1/2’’ board to Frame 1 as shown in...
  • Page 16 PB 9210 Assembly Instructions Fig. 4 Fig. 4a 2-1/2’’ screws per joint NOTE: Space evenly 1-1/2’’ screws UNDERDECK VIEW Deck Assembly 1-1/2’’ screw Attach deck boards as shown in (Fig. 4). 2. Attach slide support board as shown in (Fig. 4a).
  • Page 17 PB 9210 Assembly Instructions FLUSH FLUSH FLUSH 2-1/2’’ screws per joint FLUSH 2-1/2’’ screws per joint Roof and Barrier Supports Attach roof support boards as shown in 2-1/2’’ screw 2. Attach barrier support boards as shown in...

  • Page 18: Top View

    PB 9210 Assembly Instructions Swing Beam Drill Locations 118'' Use a 3/8’’ drill bit to drill a 3/8’’ hole through the beam at each location shown in 2. Install Swing Hangers onto swing beam at locations shown. Note: Swing Hangers must be installed on the same side dimensions were originally measured and marked.
  • Page 19 PB 9210 Assembly Instructions Hammer 3/8'' hole T-nut t-nut Bottom Beam Clamp (4) 1-1/4'' screws Use Screwdriver to aid in tightening Swing Hanger Swing Beam Drill Locations Tap t-nut into 3/8’’ hole as shown in 2. Step 2: Place a bottom beam clamp over the swing hanger as shown in Insert the swing hanger into the beam and thread it into the T-nut until it is flush or near flush with the top of the T-nut.
  • Page 20 PB 9210 Assembly Instructions A-Frame Assembly (8) 2-1/2’’ Screws layout 4’’ x 4’’s as shown 2. Allign EZ Frame Bracket with face of 4’’ x 4’’s. Secure EZ Frame Bracket with (8) 2-1/2’’ screws to 4’’ x 4’’s making sure they are flush with each other.
  • Page 21 PB 9210 Assembly Instructions Fig. 9 T-nut Washer 2-1/2’’ screws Hex Bolt 2-1/2’’ screw A-Frame Assembly cont. Attach A-Frame beam to Swing Beam using (2) hex bolts and 4 screws as shown in (Fig. 9). 2. Tighten hex bolt to flush with top of T-nut. Repeat steps 1 & 2 on second bracket.
  • Page 22 PB 9210 Assembly Instructions A-Frame Assembly cont. Position Split-Brackets on 4’’ x 4’’ x 47-1/2’’ 2. With the help of others, lift A-Frame and Swing Beam Assembly and center onto unit as shown in (Fig. Secure as shown in View from Deck x 8 (each bracket) 2’’...
  • Page 23 PB 9210 Assembly Instructions 80’’ 2-1/2’’ screws per joint 2-1/2’’ screws per board NOTE: Place flush with top of bracket and level. Barrier support Boards Install barrier support boards as shown in 2-1/2’’ screw...
  • Page 24 PB 9210 Assembly Instructions 2-1/2’’ screws per joint NOTE: 2’’ Gap Between Boards is Typical NOTE: Space evenly 1-1/2’’ screws per joint 1-1/2’’ screws per joint 1-1/4’’ Gap Typ. Barrier Board Installation Install barrier boards as shown in 1-1/2’’ screw Note: There will be a 1-1/4’’...
  • Page 25 PB 9210 Assembly Instructions 1-1/2’’ screws per joint 1-1/2’’ screws per joint in corner post 30mm screws per joint in board 1-1/4’’ Gap Typ. HINT: Pre drill 1/8” hole to help avoid splitting. Barrier Board Installation Install barrier boards as shown in Note: There will be a 1-1/4’’...
  • Page 26 PB 9210 Assembly Instructions FLUSH FLUSH 2-1/2’’ screws per board 2-1/2’’ screws per board 2-1/2’’ screw Roof Trim Block Installation Install (4) 2” x 4” x 11-3/4” boards as shown in...
  • Page 27 PB 9210 Assembly Instructions 5/8’’ x 3-1/4’’ x 23-3/4’’ 2-1/2’’ Screws per joint FLUSH 1-1/2’’ Screws per joint 2-1/2’’ Screws per joint HINT: Pre drill 1/8” hole to help avoid splitting. 2-1/2’’ Screws per joint FLUSH FLUSH 2-1/2’’ Screws per joint 2-1/2’’...
  • Page 28 PB 9210 Assembly Instructions LEVEL FLUSH FLUSH 2-1/2’’ Screws per joint FLUSH FLUSH 2-1/2’’ Screws per joint 2-1/2’’ Screws per joint FLUSH 2-1/2’’ Screws per joint Washer 3/4” Screw 3 Per Side Roof Installation Attach A-Frame as shown in NOTE: Secure boards in place by installing screws from the outside of the A-Frame. .
  • Page 29 PB 9210 Assembly Instructions 3/4’’ GAP (6) 1’’ x 6’’ x 24-3/4’’ Note: 2-3/4’’ GAP TYP. HINT: Pre drill 1/8” hole to help avoid splitting. FLUSH FLUSH 2-1/2’’ Screws per joint 2-1/2’’ Screws per joint FLUSH on ends and bottom (2)”T”...
  • Page 30 PB 9210 Assembly Instructions 2’’ x 4’’ x 47-1/2’’ FLUSH 1-1/4’’ Lag Screws 23’’ per bracket FLUSH 2’’ x 4’’ x 47-1/2’’ 11-3/4’’ 11-3/4’’ 11-3/4’’ FLUSH Center 1-1/4’’ Lag Screws 1-1/4’’ Lag Screws per rung in slot of rung. 1-1/4’’ Screws per bracket (3) 2’’...
  • Page 31 PB 9210 Assembly Instructions HINT: Use slots to fit in between 4x4’s. FLUSH 2’’ Lag Screws per bracket FLUSH 1-1/4’’ Lag screws per bracket 76-1/2” 31-1/2” 20-1/2” 9-1/2” 14” 16” 2’’ Lag screw Monkey Bar Assembly Cont. Attach the Monkey Bar Frame to the Monkey Bar Ladder as shown in 2.
  • Page 32 PB 9210 Assembly Instructions Slide Installation. Position slide to determine proper location for stake. 2. Drive wood stake into ground leaving 2’’ exposed. Secure the slide bottom to the stake using (2) 1-1/4’’ deck screws. 4. Attach slide to unit as shown in...
  • Page 33 PB 9210 Assembly Instructions 2’’ Lag screw Eye Strap 2’’ Lag Screws 1’’ 1’’ Climbing Rope Secure top of Climbing Rope on the bottom center of the 2’’ x 4’’ x 32’’ as shown in 2. Using two rope staples secure the bottom of the climbing rope. Tap two staples in place approximately 1’’ apart. Wrap the rope under the 5/4’’...
  • Page 34 PB 9210 Assembly Instructions Swing Barrier Swing Beam Guard Attach Swing Beam Guard board as shown in 24’’ 2-1/2’’ screws per joint 2-1/2’’ screw Safety Handle Safety Handle. Mount (2) Safety Handles in the Rock Wall opening approximately 11’’ above the deck surface 1 - 3/4’’...
  • Page 35 PB 9210 Assembly Instructions Swings Swing Seat Assembly. Fig. 22 x2 Per Swing Take one length of chain and place the last link of chain through the Quick Link as shown. (Fig. 22). 58" Coated Chain Quick Link Fig. 22a x2 Per Swing 2.
  • Page 36 PB 9210 Assembly Instructions Ring/Trapeze Combo Tools Required PLIERS WRENCH NOTE: Crimp swing hanger tightly closed Hanging Instructions When hanging accessories next to other components, a minimum clearance of at least 8” from adjacent swinging elements or any play equipment support structure is required.
  • Page 37 PB 9210 Assembly Instructions Anchor-It Fig. 24 Flat Washer metal strap 1-1/2” lag bolt Anchor-It Anchor-It Installation. Instructions for Anchoring Swing•N•Slide Activity Centers Determine the final location of your activity center. 2. Place the Anchor-It stakes adjacent to the base and near the corners of your activity center (at the bottom of the legs on swing sets) and twist the auger-style stakes into the ground until only the loop is exposed.
  • Page 38 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 1212 Barberry Drive, Janesville, Wisconsin, 53545.
  • Page 39 Got Questions? We’ve got answers! Call our Customer Service Representatives or email us at service@swing-n-slide.com Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2015...
