PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for. If you are
missing anything, please DO NOT RETURN to the store where purchased. Please call our
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
© Swing-N-Slide Inc. 2014
IMPORTANT!!
Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
Printed in USA
PB 8137
WARNING:
!
Assembly by an adult.
ADVERTENCIA:
!
El ensamblaje lo
debe hacer un adulto.
! AVERTISSEMENT:
L'assemblage doit être
exécuté par un adulte.
LA 7163

Advertisement

loading
Need help?

Need help?

Do you have a question about the PB 8137 and is the answer not in the manual?

Questions and answers

Summary of Contents for Swing-N-Slide PB 8137

  • Page 1 Customer Service Department at the number below. L’assemblage doit être exécuté par un adulte. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Swing-N-Slide Inc. 2014 Printed in USA LA 7163...
  • Page 2 When the equipment is taken out of service, it must be disassembled and disposed of in such a way that no unreasonable hazards will exist at the time the set is dis- carded. Important! Additional Safety Instructions for all Swing-N-Slide Playground Equipment. Save this instruction sheet in the event the manufacturer needs to be contacted.
  • Page 3 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 1212 Barberry Drive, Janesville, Wisconsin, 53545. Any part(s) returned to Swing-N- Slide®...
  • Page 4 DIMENSIONS 10 1-3/8 25 4-1/2 22 1-3/8 MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING. 80 Max Fall Height 8 Minimum...
  • Page 5: Tools Required

    TOOLS REQUIRED DRILL 1/2” SOCKET & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH SCREWDRIVER PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE INCLUDED HARDWARE 8mm Loc Washer (x8) 30mm Deck Screw (x42) 5/16” x 1-1/2” Lag Screw (x4) 8mm Washer (x8) 1-1/2”...
  • Page 6 INCLUDED HARDWARE 5/16”-18 x 7-1/2” Hex Bolt (x1) /2’’ 5/16”-18 x 6” Hex Bolt (x1) 5/16”-18 x 5” Hex Bolt (x1) /4’’ 5/16”-18 x 4-1/2” Hex Bolt (x3) 5/16”-18 x 4” Hex Bolt (x2) 5/16”-18 x 3-1/4” Hex Bolt (x6) /2’’...
  • Page 7: Included Components

    INCLUDED COMPONENTS ID Tag (x1) Beam Clamp Slotted (x4) Beam Brace (x1) Swing Beam Bracket (x2) Play Handle (x1) Anchor It Strap (x4) Anchor It (x4) 5/16’’ x 5-1/4’’ Swing Hanger (x4) STD Swing Seat (x2) Quick Link (x4) Plan (x1) 58”...
  • Page 8: Board List

    (4) [PF 4878] 5/4’’ x 4’’ x 10-1/2’’ BOARD LIST (2) [PF 4865] 5/4’’ x 4’’ x 45’’ (1) [PF 4873] 3’’ x 5-1/2’’ x 63-7/8’’ SWING BEAM (4) [PF 4864] 5/4’’ x 4’’ x 26-3/4’’ (1) [PF 4872] 3’’ x 3’’ x 50’’ SWING BEAM SUPPORT (1) [PF 4863] 5/4’’...
  • Page 9 USE THE CORRECT FASTENER Use the guides below to help select the correct length, quantity & location of screws for the board installation. Avoid splitting your lumber by offsetting your screws at least 3/4” from edge. All hardware should be driven until flush with the surface or no deeper than 1/16”. 1x4 to 2x4 &...
  • Page 10 STEP 1 PRE-DRILL BOARDS TO MINIMIZE PF 4854 SPLITTING 1’’x4’’x24’’ 5/16’’ Washer 5/16’’Loc-Washer T-Nut Small 5/16-18 X 4-1/2’’ Hex Head Bolt 1-1/2’’ Screws Per Joint Flush PF 4866 2’’x4’’x24’’ FLIP PF 4870 PF 4870 FRAME 2’’x4’’x85-1/2’’ 2’’x4’’x85-1/2’’ OVER PF 4867 PF 4867 PF 4868 2’’x4’’x49-5/8’’...
  • Page 11 STEP 2 PF 4854 1’’x4’’x24’’ Flush PRE-DRILL BOARDS TO MINIMIZE 1-1/2’’ Screws SPLITTING Per Joint PF 4869 2’’x4’’x85-1/2’’ PF 4866 2’’x4’’x24’’ T-Nut 5/16’’ Washer Large PF 4869 5/16’’ Loc-Washer 2’’x4’’x85-1/2’’ 5/16-18 X 2-3/4’’ Hex Head Bolt 2-1/2’’ Screws PF 4863 5/4’’x4’’x24’’...
  • Page 12 STEP 3 Flush Flush PF 4864 5/4’’x4’’x26-3/4’’ 2-1/2’’ Screws Per Board PF 4864 5/4’’x4’’x26-3/4’’ 2-1/2’’ Screws Per Board Frame A Check to make sure 2-1/2” Deck Screw (x10) structure is square 1. Assemble Frame A as shown.
  • Page 13 STEP 4 2-1/2’’ Screws Per Board 2-1/2’’ Screws Per Board Frame B Frame A Check to make sure structure is square 2-1/2” Deck Screw (x10) 1. Attach Frame A to Frame B as shown. Note Frame B orientation.
  • Page 14 STEP 5 (2) PF 4854 1’’x4’’x24’’ Space Deck 2-1/2’’ Screws Boards Evenly Per Board (3) PF 4859 1’’x6’’x26-3/4’’ 2-1/2’’ Screws Per Board PF 4853 1’’x4’’x17-1/2’’ 30mm Screws 2-1/2” Deck Screw (x20) 30mm Deck Screw (x4) 1. Attach deck boards as shown. 2.
  • Page 15 STEP 6 PRE-DRILL BOARDS TO MINIMIZE SPLITTING PF 4880 1’’x4’’x42-1/4’’ (2) 1-1/2” Deck Screws per joint 9’’ 26-1/2’’ Check to make sure 1-1/2” Deck Screw (x8) structure is square 1. Attach swing safety board.
  • Page 16 STEP 7 T-Nut Large (2) 2-1/2’’ PF 4877 Screws 3’’x3’’x24’’ 5/16’’ Washer TOWER BEAM 5/16’’ Loc-Washer SUPPORT 5/16-18 X 4’’ Hex Head Bolt Counter Bore Holes Down 2-1/2” Deck Screw (x4) 1. Attach Swing Beam Support Frame A as shown. Note the post orientation.
  • Page 17 STEP 8 (2) PF 4860 1’’x6’’x26-3/4’’ (6) 2-1/2” Deck Screws PRE-DRILL per board BOARDS TO MINIMIZE SPLITTING PF 4854 1’’x4’’x24’’ 7’’ (6) 1-1/2” Deck Screws 25’’ PF 4855 PF 4858 1’’x4’’x26-3/4’’ 1’’x6’’x24’’ (4) 2-1/2” Deck (6) 1-1/2” Deck Screws Screws Check to make sure structure is square 2-1/2”...
  • Page 18 STEP 9 COUNTERBORE HOLES ON TOP PF 4873 3’’x5-1/2’’x63-7/8’’ Swing Beam 5/16’’ T-Nut 5-1/4’’ Swing Large Hanger Beam Clamp (4) 30mm Deck Screws Correct Orientation 30mm Deck Screw (x16) 1. Attach Swing Hanger(s) to swing beam as shown.
  • Page 19 STEP 10 PF 4872 3x3x50 A-Frame SB 5/16”-18 x 6” Support Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 4874 2’’x4’’x69-1/8’’ A-Frame 5/16”-18 x 3-1/4” Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Washer 5/16”-18 x 4-1/2” 5/16”...
  • Page 20 STEP 11 (2) Swing Beam Bracket 5/16”-18 x 3-1/4” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/4” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 21 STEP 12 5/16”-18 x 3” Beam Brace Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16” Washer 5/16”-18 x 7-1/2” Hex Head Bolt 5/16”-18 x 5” Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam to tower as shown.
  • Page 22 STEP 13 (3) PF 4857 (2) PF 4861 1’’x6’’x21’’ 1’’x6’’x33’’ (4) 30 mm Deck (4) 30 mm Deck Screws Screws per board per board Flush PRE-DRILL BOARDS TO MINIMIZE SPLITTING (2) 2-1/2” Deck Screws per board 2-1/8” gap 2” gap typical typical Flush...
  • Page 23 STEP 14 (1) PF 4879 1’’x6’’x26-3/4’’ 3/4’’ 1-3/8’’ (2) PF 4878 5/4’’x4’’x10-1/2’’ (4) 1-1/2’’ Deck Screws PRE-DRILL BOARDS TO MINIMIZE 13’’ SPLITTING (3) 2’’ Deck Screws per side 23-1/8’’ (3) 2’’ Deck Screws per side 2” Deck Screw (x12) 1-1/2” Deck Screw (x8) 1.
  • Page 24 STEP 15 17’’ 1-1/2’’ FLUSH (7) PF 4875 1’’x6’’x20’’ ROCK WALL 1-1/2’’ Gap All Boards PRE-DRILL (2) PF 4876 BOARDS TO 2’’x4’’x50’’ ROCK WALL MINIMIZE SUPPORT SPLITTING (2) 2-1/2’’ Screws (2) 2-1/2’’ Screws per joint per joint (2) Weld Nuts Underdeck View (2) 1-1/4’’...
  • Page 25 STEP 16 (2) PF 4862 5/4’’x4’’x23’’ (8) 2’’ PF 4854 (3) 2’’ Deck Screws 1’’x4’’x24’’ Deck Screws (2) 2’’ Deck Per Joint Screws Per Joint Flush (2) PF 4865 5/4x4x45 Flush (2) PF 4856 1x4x26 PRE-DRILL BOARDS TO MINIMIZE SPLITTING 3/16”...
  • Page 26 STEP 17 1” Truss Screws (2) 30mm Deck Screws 2” Grade PF 4945 2’’x4’’x17-1/4’’ Slide Stake 30mm Deck Screw (x2) 1” Truss Screw (x3) 1. Attach slide as shown.
  • Page 27 STEP 18 5/16” Fold up Washer Anchor-It 1-1/2” Lag Strap Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 1. Place swing set in final location and mount Anchor-It(s) at locations circled above. 2. Twist the Anchor-It into the ground until only the loop is exposed. 3.
  • Page 28 STEP 19 1/4” Washer 1/4’’ x 1-3/4” Pan Screw 11” 1/2” Pan Screw (x2) 1-3/4” Pan Screw (x2) 1. Attach Play Handle and Label as shown...
  • Page 29 STEP 20 Swing Seat Assembly 1. Take one length of chain and place the outermost link of chain through the Quick Link as shown. 2. Place the Quick Link through the Grommet of the swing seat as shown. 3. Tighten the threaded sleeve of the Quick Link with a suitably sized wrench so that the seat is securely attached and the Quick Link cannot be easily loosened.
