WARNING:
!
Assembly by an adult.
ADVERTENCIA:
!
El ensamblaje lo
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
debe hacer un adulto.
Please make sure all lumber, hardware and accessory parts are accounted for. If you are
missing anything, please DO NOT RETURN to the store where purchased. Please call our
! AVERTISSEMENT:
L'assemblage doit être
exécuté par un adulte.
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
© Swing-N-Slide 2014
No. of children: Up to xx
Est. building Time: x-xx hrs.
Two Adults
IMPORTANT!!
Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
Printed in USA
PB 8129
SLIDE SOLD
SEPARATELY
(NE 4675)
LA 7282

Advertisement

loading
Need help?

Need help?

Do you have a question about the Timber-Bilt PB 8129 and is the answer not in the manual?

Questions and answers

Summary of Contents for Swing-N-Slide Timber-Bilt PB 8129

  • Page 1 Customer Service Department at the number below. L’assemblage doit être exécuté par un adulte. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Swing-N-Slide 2014 Printed in USA LA 7282...
  • Page 2 When the equipment is taken out of service, it must be disassembled and disposed of in such a way that no unreasonable hazards will exist at the time the set is dis- carded. Important! Additional Safety Instructions for all Swing-N-Slide Playground Equipment. Save this instruction sheet in the event the manufacturer needs to be contacted.
  • Page 3 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 1212 Barberry Drive, Janesville, Wisconsin, 53545. Any part(s) returned to Swing-N- Slide®...
  • Page 4 DIMENSIONS 12 - 6 24 - 6 MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING. 10 6 96 Max Fall Height...
  • Page 5: Tools Required

    TOOLS REQUIRED DRILL 1/2” SOCKET & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH SCREWDRIVER PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE INCLUDED HARDWARE 30mm Deck Screw (x82) 5/16” x 1-1/2” Lag Screw (x4) T-20 Bit (x1) 1-1/2” Deck Screw (x116) 1-1/4”...
  • Page 6: Included Components

    INCLUDED HARDWARE 1/4”-20 x 1-1/4” Hex Head Bolt (x8) 3/8’’ DRILL BIT 8mm Washer (x8) Weld-Nut (x8) 8mm Loc Washer (x8) 3/16” Tarp Washer (x22) INCLUDED COMPONENTS 4x4 Wrap Loc (x10) 4x4 Shelf Loc (x2) 2x4 Shelf Loc (x8)
  • Page 7 INCLUDED COMPONENTS Window (x4) 23-1/4’’ Rungs (x3) Anchor It Strap (x4) Anchor It (x4) Play Handle (x2) ID Tag (x1) Plan (x1) Climbing Rock (x4) Step Bracket (R) (x1) Step Bracket (L) (x1) Staple (x6) Bolt Caps (x3) Tarp, Large (x1) Net Climber (x1) Tarp, Small (x1)
  • Page 8: Board List

    (4) [PF 4931] 5/4’’ x 4’’ x 40-1/2’’ (4) [PF 4903] 5/4’’ x 4’’ x 10-1/2’’ (1) [PF 4936] 5/4’’ x 6’’ x 47’’ (7) [PF 4937] 5/4’’ x 6’’ x 47-1/2’’ (8) [PF 4920] 5/8’’ x 6’’ x 40-1/2’’ (1) [PF 4942] 2’’...
  • Page 9 USE THE CORRECT FASTENER Use the guides below to help select the correct length, quantity & location of screws for the board installation. Avoid splitting your lumber by offsetting your screws at least 3/4” from edge. All hardware should be driven until flush with the surface or no deeper than 1/16”. 1x4 to 2x4 &...
  • Page 10: Bracket Installation

    BRACKET INSTALLATION 4’’ x 4’’ Shelf-Loc bracket CORRECT INCORRECT 2’’ x 4’’ Shelf-Loc bracket CORRECT INCORRECT Bracket mounting NOTCH 1. Always use lag screws 2. Brackets interlock with each other. NEVER position them in a non-interlocking position. 3. Place lag screws in brackets only where instructed. Do NOT fill in every hole as this will lead to a hardware shortage.
  • Page 11 STEP 1 (2) 1-1/4” Lag Screws per bracket 59’’ 47’’ FRAME 1 1-1/4” Lag Screw (x8) 1. Attach brackets to posts as shown.
  • Page 12 STEP 2 FLUSH (3) 2-1/2’’ Screw Per Joint 108’’ 103-1/2’’ Check to make sure FRAME 1 structure is square 2-1/2” Deck Screw (x12) 1. Assemble Frame 1 as shown. Note the bracket orientation.
  • Page 13 STEP 3 (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket FLUSH FLIP FRAME OVER FRAME 1 Check to make sure 1-1/4” Lag Screw (x6) 2” Lag Screw (x4) structure is square 1. Attach support board to Frame 1 as shown.
  • Page 14 STEP 4 (2) 2” Lag Screws per bracket FLUSH (2) 1-1/4” Lag Screws per bracket 59’’ 1-1/4” Lag Screw (x4) FRAME 2 2” Lag Screw (x4) 1. Attach brackets to posts as shown.
  • Page 15 STEP 5 CENTER HOLES CENTER HOLES 21-7/8’’ 1. Drill (3) 3/8’’ holes in (1) 4’’ x 4’’ x 96’’ as shown. This will be used as the tower accessory arm. 12-1/2’’ 3-1/8’’...
  • Page 16 STEP 6 1’’ TIP: Flex bracket(s) to make FLUSH installation of 4x4 easier (3) 2-1/2’’ 62-1/2’’ Screw Per Joint (4) 2” Lag per 4x4 Shelf Loc bracket FLUSH Check to make sure FRAME 2 structure is square 2-1/2” Deck Screw (x12) 2”...
  • Page 17 STEP 7 (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket FLIP FLUSH FRAME OVER FRAME 2 1-1/4” Lag Screw (x6) 2” Lag Screw (x4) 1. Attach support board to Frame 2 as shown.
  • Page 18 STEP 8 FRAME 1 [PF 4913] 5/8’’ x 4’’ x 47-1/2’’ (3) 2-1/2’’ Screw FLUSH [PF 4913] 5/8’’ x 4’’ x 47-1/2’’ (3) 2-1/2’’ Screw (2) 2-1/2’’ 62-1/2’’ Screw 1-3/4’’ (2) 2-1/2’’ Screw 1-3/4’’ Check to make sure 2-1/2” Deck Screw (x10) structure is square 1.
  • Page 19 STEP 9 FRAME 2 (3) 2-1/2’’ Screw (3) 2-1/2’’ Screw (3) 2-1/2’’ Screw (3) 2-1/2’’ Screw FRAME 1 2-1/2” Deck Screw (x12) 1. Attach Frame 1 to Frame 2 as shown.
  • Page 20 STEP 10 (2) 2-1/2’’ Screw per joint (2) 2-1/2’’ Screw per joint 2-1/2” Deck Screw (x8) 1. Attach boards as shown.
  • Page 21 STEP 11 (2) 1-1/4” Lag Screws per bracket 47’’ 4’’ x 4’’ x96’’ 1-1/4” Lag Screw (x4) 1. Attach brackets to posts as shown.
  • Page 22 STEP 12 FLUSH 78’’ (3) 2-1/2’’ Screw per joint FLUSH Check to make sure FRAME 3 structure is square 2-1/2” Deck Screw (x12) 1. Assemble Frame 3 as shown. Note the bracket orientation.
  • Page 23 STEP 13 [PF 4917] 5/8’’ x 6’’ x 27’’ (3) 2-1/2’’ Screw (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket ALL BOARDS FLUSH WITH FACE OF POST [PF 4917] 5/8’’ x 6’’ x 27’’ (3) 2-1/2’’ Screw [PF 4943] 2’’...
  • Page 24 STEP 14 (3) 1-1/4” Lag & (2) 2” Lag (3) 2-1/2’’ per 2x4 Shelf Loc bracket Screw (3) 2-1/2’’ Screw (2) 2-1/2’’ Screw (2) 2-1/2’’ FRAME 3 Screw 1-1/4” Lag Screw (x6) 2-1/2” Deck Screw (x10) 2” Lag Screw (x4) 1.
  • Page 25 STEP 15 (2) [PF 4931] 5/4’’ x 4’’ x 40-1/2’’ (2) 2-1/2’’ Screw per joint (2) 2-1/2’’ Screw per joint 2-1/2” Deck Screw (x8) 1. Attach boards as shown.
  • Page 26: End View

    STEP 16 (2) 2-1/2’’ Screw (1) 2-1/2’’ per joint Screw (2) [PF 4930] 5/4’’ x 4’’ x 40-1/4’’ [PF 4946] 1-1/2’’ x 1-5/8’’ x 27’’ Flush (2) 2-1/2’’ Screw (2) 1-1/2’’ per joint Screw per joint (1) 2-1/2’’ Screw (1) 2-1/2’’ Screw 1-1/2’’...
  • Page 27 STEP 17 (4) 2-1/2’’ Screw per board (2) 1-1/2’’ (1) [PF 4933] 5/4’’ x 4’’ x 47-1/2’’ Screw per board (3) [PF 4937] 5/4’’ x 6’’ x 47-1/2’’ 1-1/2” Deck Screw (x8) 2-1/2” Deck Screw (x16) 1. Attach boards as shown.
  • Page 28 STEP 18 [PF 4930] 5/4’’ x 4’’ x 40-1/4’’ (2) 2-1/2’’ Screw per joint [PF 4930] 5/4’’ x 4’’ x 40-1/4’’ (2) 2-1/2’’ Screw per joint (2) 2-1/2’’ (2) 2-1/2’’ Screw Screw per joint per joint 18’’ TOP VIEW 2-1/2” Deck Screw (x16) 1.
  • Page 29 STEP 19 [PF 4941] 2’’ x 4’’ x 11’’ Step Bracket (R) Step Bracket (L) DETAIL OF STEP BRACKETS: (Left Bracket Shown) [PF 4941] 2’’ x 4’’ x 11’’ 4-1/2’’ (3) 30 mm screws each bracket [PF 4942] 2’’ x 4’’ x 17-1/2’’ (3) 30 mm screws each bracket 30mm Deck Screw (x12)
  • Page 30 STEP 20 10’’ (2) 2-1/2’’ Screw per Joint (2) 2-1/2’’ Screw per Joint 2-1/2” Deck Screw (x8) UNDER DECK VIEW 1. Install step as shown.
  • Page 31 STEP 21 3’’ (3) 2-1/2’’ Screw per Joint UNDER DECK VIEW 2-1/2” Deck Screw (x6) 1. Install Spacer Board as shown.
  • Page 32 STEP 22 (6) 2-1/2’’ Screw per board 1/4’’ Gap Between All Deck Boards 2-1/2” Deck Screw (x42) TOP VIEW 1. Install Deck Boards as shown.
  • Page 33 STEP 23 5/8’’ 5/8’’ 1-1/2’’ TOP VIEW 5/8’’ (4) 2-1/2’’ Screw per board 2-1/2” Deck Screw (x8) 1. Install Boards as shown.
  • Page 34 STEP 24 5/8’’ 5/8’’ 1-1/2’’ TOP VIEW [PF 4938] 1-1/2’’ x 1-5/8’’ x 10-1/4’’ (2) 2-1/2’’ 5/8’’ Screw per board 14’’ [PF 4938] 1-1/2’’ x 1-5/8’’ x 10-1/4’’ (2) 2-1/2’’ Screw per board [PF 4940] 1-1/2’’ x 1-5/8’’ x 35-1/2’’ (4) 2-1/2’’...
  • Page 35 STEP 25 (5) [PF 4919] 5/8’’ x 6’’ x 36’’ 2-1/8’’ Gap Between Barrier Boards (2) 2-1/2’’ Screw per board (2) 30mm Screw per board FLUSH 30mm Deck Screw (x10) 2-1/2” Deck Screw (x10) 1. Install Boards as shown.
  • Page 36: Side View

    STEP 26 (2) 1-1/2’’ Screw per joint [PF 4920] 5/8’’ x 6’’ x 40-1/2’’ [PF 4914] [PF 4914] 5/8’’ x 6’’ x 12-7/8’’ 5/8’’ x 6’’ x 12-7/8’’ 1/8’’ GAP [PF 4907] 5/8’’ x 4’’ x 12-7/8’’ 1/8’’ GAP [PF 4914] [PF 4914] 5/8’’...
  • Page 37 STEP 27 (2) 1-1/2’’ Screw per joint [PF 4920] 5/8’’ x 6’’ x 40-1/2’’ [PF 4914] [PF 4914] 5/8’’ x 6’’ x 12-7/8’’ 5/8’’ x 6’’ x 12-7/8’’ 1/8’’ GAP [PF 4907] 5/8’’ x 4’’ x 12-7/8’’ 1/8’’ GAP [PF 4914] [PF 4914] 5/8’’...
  • Page 38 STEP 28 (2) Window Frames (16) 3/4’’ Flat Head Screws (2) Window Frames (16) 3/4’’ Flat Head Screws 3/4” Flat Head Screw (x32) 1. Attach window frame as shown.
  • Page 39 STEP 29 [PF 4904] 5/8’’ x 3’’ x 14-3/4’’ (4) 3/4’’ Flat Head Screws Per Board SECURE BOARD THROUGH WINDOW FRAMES [PF 4904] 5/8’’ x 3’’ x 14-3/4’’ 3/4” Flat Head Screw (x8) 1. Attach Boards as shown.
  • Page 40 STEP 30 (2) [PF 4905] 5/8’’ x 4’’ x 10-1/2’’ (3) 2-1/2’’ Screws Per Board FLUSH (2) 1-1/2’’ Screws Pre-Drill (2) [PF 4918] 5/8’’ x 6’’ x 30’’ (2) 30mm Screws Per Joint FLUSH 30mm Deck Screw (x8) 2-1/2” Deck Screw (x6) 1-1/2”...
  • Page 41 STEP 31 (2) [PF 4906] 5/8’’ x 4’’ x 12-3/8’’ (3) 2-1/2’’ Screws Per Board FLUSH (2) 1-1/2’’ Screws Pre-Drill (2) [PF 4911] 5/8’’ x 4’’ x 42’’ (2) 30mm Screws Per Joint (2) [PF 4921] 5/8’’ x 6’’ x 42’’ (2) 30mm Screws Per Joint FLUSH 30mm Deck Screw (x16)
  • Page 42: End View

    STEP 32 8-3/4’’ [PF 4939] 1-1/2’’ x 1-5/8’’ x 30’’ (2) [PF 4940] (4) 1-1/2’’ Screws 1-1/2’’ x 1-5/8’’ x 35-1/2’’ (4) 1-1/2’’ Screws Per Board Secure boards in place by FLUSH mounting from inside tower. 1-1/2’’ 1-5/8’’ END VIEW [PF 4912] 5/8’’...
  • Page 43 STEP 33 [PF 4915] [PF 4910] 5/8’’ x 6’’ x 17-7/8’’ 5/8’’ x 4’’ x 4-1/4’’ (2) 1-1/2’’ Screws (2) 1-1/2’’ Screws [PF 4910] [PF 4909] 5/8’’ x 4’’ x 4-1/4’’ 5/8’’ x 6’’ x 17-7/8’’ (2) 1-1/2’’ Screws (2) 1-1/2’’ Screws 12-5/8’’...
  • Page 44 STEP 34 (2) 2-1/2’’ Screws (4) 30mm Screws Per Side 1-1/4’’ (2) 2-1/2’’ Screws [PF 4933] 5/4’’ x 4’’ x 47-1/2’’ (2) 2-1/2’’ Screws Per Joint 30mm Deck Screw (x8) 2-1/2” Deck Screw (x12) 1. Attach Boards as shown.
  • Page 45 STEP 35 (2) 30mm Screws (3) 2-1/2’’ Screws Per Joint (2) 30mm Screws [PF 4932] 1’’ x 4’’ x 42-7/8’’ FLUSH (3) 2-1/2’’ Screws Per Joint (2) 2-1/2’’ Screws FLUSH [PF 4932] [PF 4933] 1’’ x 4’’ x 42-7/8’’ 5/4’’ x 4’’ x 47-1/2’’ (2) 2-1/2’’...
  • Page 46 STEP 36 Tarp, Large #12 x 3/4” Pan Screw #12 x 3/4” Pan Screw 3/16” Tarp 3/16” Washer Washer Tarp, Small 3/16” Tarp Washer #12 x 3/4” Pan Screw #12 x 3/4” Pan Screw (x22) 1. Attach Tarps as shown.
  • Page 47 STEP 37 FLAT SIDE CURVED SIDE 11-1/8’’ OUTWARD UNDER DECK 11-1/8’’ 10-3/8’’ 23-1/4’’ Rungs (2) 2’’ Lag Screws SIDE VIEW Per Rung 1-3/8’’ (2) [PF 4908] 5/8’’ x 4’’ x 27’’ (3) 2-1/2’’ Screws Per Joint UNDER DECK VIEW 2” Lag Screw (x6) 2-1/2”...
  • Page 48 STEP 38 20’’ FLUSH (2) PF 4944 2’’x4’’x47-1/2’’ ROCK WALL (8) PF 4916 5/8’’x6’’x20’’ ROCK WALL (2) 2-1/2’’ (2) 2-1/2’’ Screws Screws Per Joint 3-1/2’’ Gap Per Joint Bottom (2) Weld Nuts Underdeck View (2) 1-1/4’’ Hex Head Bolts (1) Climbing Rock (2) 8mm Loc-Washer Per Rock (2) 8mm Flat Washer Per Rock 2-1/2”...
  • Page 49 STEP 39 1-1/2’’ 3’’ (2) PF 4903 5/4’’x4’’x10-1/2’’ PRE-DRILL PF 4922 5/8’’x6’’x47’’ (2) 1-1/2’’ Screws Per Joint 3-1/2’’ PICNIC TABLE 2-5/8’’ PICNIC BENCH 1-1/2’’ TOP VIEW 3-1/2’’ (2) PF 4903 5/4’’x4’’x10-1/2’’ PRE-DRILL PF 4936 5/4’’x6’’x47’’ (2) 1-1/2’’ Screws Per Joint 3’’...
  • Page 50: Picnic Table

    STEP 40 PICNIC TABLE FLUSH (3) 2-1/2’’ Screws Per Joint 28-1/2’’ FLUSH WITH FACE OF UPRIGHT (4) 2’’ Lag Screws 4’’ x 4’’ x 96’’ 2” Lag Screw (x4) 2-1/2” Deck Screw (x6) 1. Attach Picnic Table and Climber Support Board as shown.
  • Page 51 STEP 41 (3) 5/16’’ Flat Washer (3) 5/16’’ Loc-Nut (1) Net Climber (2) 30mm screw Per Cap (2) Staples 1’’ 1’’ 30mm Deck Screw (x6) 1. Attach Net Climber as shown. 2. Attach bolt covers over loc nuts at all three locations as shown. 3.
  • Page 52 STEP 42 #14 x 1” Truss Screws With hammer pound stake into ground as shown. 2” (2) 30mm Grade Deck Screws PF 4338 2’’x2’’x17’’ Slide Stake 30mm Deck Screw (x2) #14 x 1 ‘‘ Truss Screw (x3) 1. Attach slide as shown.
  • Page 53 STEP 43 (1) Play Handle (1) Play Handle (2) 1-1/4’’ Lag (2) 1-1/4’’ Lag Screw Screw 11” 11” (1) ID TAG (2) 1/2’’ Pan Screw 1-1/4” Lag Screw (x4) 1/2” Pan Screw (x2) 1. Attach Play Handle as shown centered on upright. 2.
  • Page 54 STEP 44 5/16” Fold up Washer Anchor-It 1-1/2” Lag Strap Screw Anchor-It 5/16 x 1-1/2” Lag Screw (x4) 1. Place swing set in final location and mount Anchor-It(s) at locations circled above. 2. Twist the Anchor-It into the ground until only the loop is exposed. 3.
  • Page 55 NO SLIDE 1-1/2’’ Gap Between Barrier FLUSH Boards (4) 30mm FLUSH Screws Per Board (4) 5/4’’ x 6’’ x 30’’ (1) 1’’ x 4’’ x 47-1/2’’ (4) 30mm wood screws (3) 2-1/2’’ per board wood screws APPLY HARDWARE FROM OUTSIDE OF UNIT. 30mm Deck Screw (x16) 2-1/2”...
  • Page 56 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through Labor Day Also available on Memorial Day, Fourth of July & Labor Day Technical Support from experienced Swing-N-Slide Customer Service Representatives who have actually built a swing set themselves. © Swing-N-Slide 2014...
