Swing-N-Slide PB 8327 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Swing-N-Slide Manuals
  4. Play Sets & Playground Equipment
  5. PB 8327
  6. Assembly instructions manual

Swing-N-Slide PB 8327 Assembly Instructions Manual

Hide thumbs Also See for PB 8327:

Advertisement

Quick Links

Download this manual
PB 8327
PB 8331
NOTE:
SLIDE NOT INCLUDED
WITH PB 8327
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
LDR 2-26-2015
© Swing-N-Slide Inc.
Printed in USA
LA 7511

Advertisement

loading
Need help?

Need help?

Do you have a question about the PB 8327 and is the answer not in the manual?

Questions and answers

Related Manuals for Swing-N-Slide PB 8327

Summary of Contents for Swing-N-Slide PB 8327

  • Page 1 Please call our Customer Service Department at the number below. ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 LDR 2-26-2015 © Swing-N-Slide Inc. Printed in USA...
  • Page 4 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
  • Page 5 DIMENSIONS 6’ -0’’ 14’ -0’’ 14’ -4’’ 6’ -0’’ 28’ -0’’ 11’ -0’’ 6’ -0’’ 14’ -0’’ 6’ -0’’ 26’ -4’’ MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”.

  • Page 6: Tools Required

    TOOLS REQUIRED DRILL 1/2” & 7/16’’ SOCKETS & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH PLIERS SCREWDRIVER PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE INCLUDED HARDWARE 3” Deck Screw (x9) 2-1/2” Deck Screw (x200) 3/16” Tarp Washer (x6) 5/16-18 T-Nut (x18) 5/16-18 T-Nut (x6) Small Large...
  • Page 7 HARDWARE HARDWARE (x1) Steering Wheel Spacer Quick Link (x8) Weld-Nut (x12) 5/16” x 1-1/2” Lag Screw (x4)
  • Page 8 SA6007 BOX 1 of 2 BOARD LIST (2) [PF 6106] 3’’ x 3’’ x 94-1/4’’ (4) [PF 6072] 5/8’’ x 3-3/8’’ x 31-3/8’’ (2) [PF 6107] 3’’ x 3’’ x 94-1/4’’ (2) [PF 6169] 5/8’’ x 3-3/8’’ x 31-1/2’’ (4) [PF 6064] 5/8’’ x 3-3/8’’ x 30’’ (1) [PF 6105] 3’’...
  • Page 9 SA6021 BOX 2 of 2 BOARD LIST (2) [PF 6073] 5/8’’ x 3-3/8’’ x 31-1/2’’ (1) [PF 6019] 2-5/8’’ x 5-3/8’’ x 89-1/2’’ SWING BEAM (2) [PF 6070] 5/8’’ x 3-3/8’’ x 31-1/2’’ (6) [PF 6069] 5/8’’ x 3-3/8’’ x 31-1/2’’ (2) [PF 6017] 1-3/8’’...
  • Page 10 Please call our Customer Service Department at the number below. ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 ID Tag (x1) © Swing-N-Slide Inc. Printed in USA...
  • Page 11 Beam Clamp Slotted (x6) Telescope (x1) Climbing Rock (x6) Flag Assembly (x2) Trapeze Bar (x1) Iron Man Ring (x2) 36” Dipped Chain (x2) Anchor It Strap (x4) Anchor It (x4)
  • Page 12 STEP 1 3-5/8’’ BOTH SIDES 2-1/2’’ Screws 2-1/2’’ Screws Check to make sure struc- ture is square NOTE: HOLE ORIENTATION 31-1/2’’ Flush 2-1/2’’ Screws 2-1/2’’ Screws 19-3/4’’ FRAME A 2-1/2” Deck Screw (x12) 1. Assemble Frame A as shown.

  • Page 13: Bottom View

    STEP 2 3-5/8’’ BOTH SIDES 2-1/2’’ Screws 2-1/2’’ Screws NOTE: HOLE ORIENTATION 31-1/2’’ 2-1/2’’ Screws 20-1/2’’ 2-1/2’’ Screws 3/4’’ PF 6155 3/4’’ x 3-3/8’’ x 51-1/4’’ FRAME B Bottom View 2-1/2” Deck Screw (x12) 1. Assemble Frame B as shown.
  • Page 14 STEP 3 Flush Check to make sure struc- ture is square 3-1/2’’ PF 6069 5/8’’ x 3-3/8’’ x 31-1/2’’ 94-1/4’’ T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer PF 6093 1’’ x 3-3/8’’ x 31-1/2’’ 58-5/8’’...
  • Page 15 STEP 4 Check to make sure struc- ture is square 3-1/2’’ 2-1/2’’ Screws 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer FRAME A 2-1/2’’ Screws Flush FRAME B 2-1/2’’ Screws 2-1/2” Deck Screw (x12) 1.
  • Page 16 STEP 5 Check to make sure struc- ture is square 58-5/8’’ 2-1/2’’ Screws NOTE: Flush PRE- DRILL with Deck 2-1/2’’ Screws Support Board FRAME A 2-1/2” Deck Screw (x12) 1. Attach boards as shown.
  • Page 17 STEP 6 5/16-18 X 3-1/2’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer 2-1/2’’ Screws T-Nut PF 6093 1’’ x 3-3/8’’ x 31-1/2’’ Small 46-5/8’’ FRAME B 2-1/2” Deck Screw (x4) 1. Attach Deck Support Board to Frame A.
  • Page 18 STEP 7 NOTE: (2) PF 6067 5/8’’ x 3-3/8’’ x 25-3/8’’ PRE-DRILL 11’’ HOLES GOING PF 6088 1-3/8’’ x 1-3/8’’ x 31-1/2’’ INTO DECK SUPPORTS 1-3/4’’ Screws per board Flush FRAME B 1-3/4” Deck Screw (x12) 1. Attach Deck Boards and Deck Support Board as shown.
  • Page 19 STEP 8 1-3/4’’ Screws per board (7) PF 6072 5/8’’ x 3-3/8’’ x 31-3/8’’ Flush 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 1/8’’.
  • Page 20 STEP 9 2-1/2’’ Screws Flush 2-1/2’’ Screws 2-1/2’’ Screws Flush 2-1/2’’ Screws Flush 62’’ 2-1/2” Deck Screw (x12) 1. Attach Barrier Support Boards as shown.
  • Page 21 STEP 10 NOTE: MAKE SCREW 1-5/8’’ Screws HEADS FLUSH T-Nut Small 5/16’’Loc-Washer 5/16’’ Washer 5/16-18 X 1-3/4’’ Hex Head Bolt 3’’ Screws 1-5/8” Deck Screw (x2 ) PF 6154 1’’ x 3-3/8’’ x 42’’ SUPPORT 3” Deck Screw (x2) 1. Attach Tower Support Board as shown.
  • Page 22 STEP 11 26’’ 2-1/2’’ Screws 2-1/2” Deck Screw (x4) 1. Attach Barrier Board as shown.
  • Page 23 STEP 12 Check to make sure struc- ture is square Flush 2-1/2’’ Screws PF 6084 3/4’’ x 3-3/8’’ x 54-1/2’’ 2-1/2’’ Screws Flush 77-1/4’’ 2-1/2” Deck Screw (x12) 1. Attach Barrier Support Boards as shown.
  • Page 24 STEP 13 PF 6073 5/8’’ x 3-3/8’’ x 31-1/2’’ 1-3/4’’ Screws ROTATE FRAME 1-3/4’’ Screws COUNTERBORE PF 6093 1’’ x 3-3/8’’ x 31-1/2’’ 2’’ Screws PF 6082 3/4’’ x 3-3/8’’ x 31-1/2’’ 46-5/8’’ 2’’ Screws 5/16-18 X 2’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’...
  • Page 25 STEP 14 Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws FRAME C 2-1/2’’ Screws 2-1/2” Deck Screw (x6) 1. Attach Frame C to Tower as shown.
  • Page 26 STEP 15 Flush 1-3/4’’ Screws per board (2) PF 6068 5/8’’ x 3-3/8’’ x 21-1/2’’ 1-3/4’’ Screws per board Flush 1-3/4” Deck Screw (x8) 1. Attach Deck Boards as shown.
  • Page 27 STEP 16 Flush (7) PF 6151 5/8’’ x 3-3/8’’ x 23’’ 1-3/4” Deck Screw (x28) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 1/8’’.
  • Page 28 STEP 17 2’’ Screw per side PF 6070 5/8’’ x 3-3/8’’ x 31-1/2’’ PF 6069 5/8’’ x 3-3/8’’ x 31-1/2’’ 2-1/2’’ Screws 2-1/2’’ Screws 58-5/8’’ 53’’ 2” Deck Screw (x2) 2-1/2” Deck Screw (x12) 1. Attach Spacer Boards as shown.
  • Page 29 STEP 18 PF 6105 3’’ x 3’’ x 31-1/2’’ TOWER BEAM SUPPORT 5/16-18 X 6’’ Carriage Bolt Wood Loc-Washer 5/16’’ Washer Loc Nut 1. Attach Tower Beam Support Board as shown.
  • Page 30 STEP 19 PF 6019 2 5/8’’x5-3/8’’x89-1/2’’ Swing Beam 5/16’’ T-Nut 5-1/2’’ Swing Large Hanger Beam Clamp (4) 1-1/4’’ Deck Screws Correct Orientation 1-1/4” Deck Screw (x24) 1. Attach Swing Hanger(s) to swing beam as shown.
  • Page 31 STEP 20 PF 6018 2 5/8’’x3’’x62’’ 5/16”-18 x 7” A-Frame SB Sup- Hex Head Bolt port 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16”...
  • Page 32 STEP 21 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 33 STEP 22 5/16”-18 x 3 1/4” Hex Head Bolt Beam Brace 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 34 STEP 23 5/16”-18 x 8-1/2” Hex Head Bolt 5/16”-18 x 6” Carriage Bolt 5/16” Loc Washer 5/16” Wood Loc Washer 5/16” Washer 5/16-18 T-Nut 5/16” Washer Small 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 35 STEP 24 1-1/2’’ 2-1/2’’ Screws 30mm Screws per board per board Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions. (5) PF 6075 5/8’’ x 3-3/8’’ x 35’’ 1-3/16’’ 30mm Deck Screw (x20) 2-1/2” Deck Screw (x10) 1. Install Barrier Boards as shown. NOTE: Standard gap between barrier boards is 1-1/2’’.
  • Page 36 STEP 25 2-3/8’’ (4) PF 6076 5/8’’ x 3-3/8’’ x 35’’ 30mm Screws per board 1-1/4’’ Screws per board 1-3/16’’ 30mm Deck Screw (x16) 1-1/4” Deck Screw (x8) 1. Install Barrier Boards as shown. NOTE: Standard gap between barrier boards is 2-3/8’’.

  • Page 37: Inside View

    STEP 26 (6) PF 6066 5/8’’ x 3-3/8’’ x 17’’ 3/4’’ 1’’ 1-1/4’’ Screws per board 30mm Screws per board 1-3/16’’ Inside View 30mm Deck Screw (x12) 1-1/4” Deck Screw (x12) 1. Install Barrier Boards as shown. NOTE: Standard gap between barrier boards is 3/4’’.
  • Page 38 STEP 27 (2) PF 6079 5/8’’ x 3-3/8’’ x 8-3/8’’ (12) 2-1/2’’ Screws (2) PF 6074 5/8’’ x 3-3/8’’ x 31-1/2’’ WINDOW CUTOUT 2-1/2” Deck Screw (x12) 1. Attach Window Barrier Boards as shown.
  • Page 39 STEP 28 (10) 3/4’’ Flat HeadScrews 3/4” Flat Head Screw (x10 ) 1. Attach Window Frame as shown.
  • Page 40 STEP 29 PF 6081 5/8’’ x 5-3/8’’ x 31-1/2’’ ARCH 1-3/4’’ Screws 1-3/4’’ Screws 1-3/4’’ Screws (2) PF 6077 5/8’’ x 3-3/8’’ x 6-3/8’’ 1-3/4’’ Screws PF 6073 5/8’’ x 3-3/8’’ x 31-1/2’’ 1-3/4’’ Screws 1-3/4’’ Screws Flush 1-3/4” Deck Screw (x18) 1.
  • Page 41 STEP 30 (2) PF 6131 5/8’’ x 3-3/8’’ x 30’’ FENCE ARCH 30mm Screws per board (2) PF 6131 5/8’’ x 3-3/8’’ x 30’’ FENCE ARCH (3) PF 6064 5/8’’ x 3-3/8’’ x 30’’ 30mm Screws per board Flush 1-1/2’’ 30mm Screws per board 30mm Screws...
  • Page 42 STEP 31 (3) 1-1/4’’ Deck (1) 3’’ Screws Screws 3/4’’ 3/4’’ (3) 30mm Screws PF 6098 5/8’’ x 2’’ x 28’’ (1) PF 6096 5/8’’ x 2’’ x 12’’ (2) 1-1/4’’ Deck (2) 1-1/4’’ Deck (2) PF 6097 5/8’’ x 2’’ x 8’’ Screws Screws PF 6102 1’’...
  • Page 43 STEP 32 Flush Flush (4) 1-1/4’’ Deck Screws (1) 1-1/4’’ Deck per board Screw per board (4) 1-1/4’’ Deck Screws per board Flush 34-3/4’’ (8) PF 6163 1/2’’ x 3-3/8’’ x 36-3/4’’ SHINGLE 34-3/4’’ (2) PF 6162 1-3/8’’ x 1-3/8’’ x 28-1/2’’ Flush (5) 1-1/4’’...
  • Page 44 STEP 33 (3) 1-1/4’’ Deck Screws (4) 2’’ Deck Screws (4) 2’’ Deck Screws 2” Deck Screw (x8) 1-1/4” Deck Screw (x12) 1. Attach roof and End Cap Boards as shown.
  • Page 45 STEP 34 Flush (3) 2-1/2’’ Deck Screws (4) 2’’ Deck Per side Screws per board Side View Top ALL GAPS 2’’ 1-1/2’’ (6) PF 6085 5/8’’ x 5-3/8’’ x 19-1/2’’ Flush (3) 1-5/8’’ Deck Screws 2-1/2” Deck Screw (x6) 2” Deck Screw (x24) 3/4’’...
  • Page 46 STEP 35 2’’ (1) PF 6085 5/8’’ x 5-3/8’’ x 19-1/2’’ (4) 2’’ Deck Screws 2” Deck Screw (x4) 1. Attach Rock Wall Board as shown.
  • Page 47 STEP 36 (2) Weld Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Mark locations of Climbing Rocks on the Climbing Wall in a pattern that will easily allow your child to climb to the deck. Make sure the bolt hole locations are clear of wall supports before drilling.
  • Page 48 STEP 37 PF 6064 5/8’’ x 3-3/8’’ x 30’’ Flush 23’’ 1-3/4’’ Screws per board 2-5/8’’ 2-5/8’’ 30mm Screws 1-1/4’’ Screws (6) PF 6156 5/8’’ x 3-3/8’’ x 23’’ Inside View 1-3/16’’ 1-3/4” Deck Screw (x6) 30mm Deck Screw (x12) 1-1/4”...
  • Page 49 STEP 38 (2) PF 6159 1’’ x 3-3/8’’ x 4-5/8’’ TABLE SUPPORT Flush 1-5/8’’ Screws per board Underdeck View NOTE: 1-3/4’’ Screws OVERHANG PF 6086 FRONT EDGE PF 6086 5/8’’ x 5-3/8’’ x 21-1/2’’ 1/2’’ PAST FACE OF PF 6064 1-5/8’’...
  • Page 50 STEP 39 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ TABLE SUPPORT (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ BENCH SUPPORT 1-1/4’’ Screws 1-1/4’’ Screws 3’’ 3’’ 11-3/8’’ Flush 2-1/2’’ Screws 6-7/8’’ 6-7/8’’ 13-3/4’’ Flush (2) PF 6038 3/4’’ x 3-3/8’’ x 26-7/8’’ PICNIC TABLE LEG 25’’...
  • Page 51 STEP 40 PF 6175 3/4’’ x 3-3/8’’ x 15-1/2’’ PF 6175 3/4’’ x 3-3/8’’ x 15-1/2’’ 2’’ Screws Flush 2’’ Screws Flush 1-5/8’’ 2’’ Screws per side (2) PF 6173 3/4’’ x 3-3/8’’ x 13’’ ARCH 41’’ 2” Deck Screw (x8) 1.
  • Page 52 STEP 41 2’’ Screw per side 3’’ Screw 3’’ Screw 2” Deck Screw (x4) 3” Deck Screw (x2) 1. Attach Tarp Support Frame to tower as shown.
  • Page 53 STEP 42 3/4’’ Screws PF 6169 5/8’’ x 3-3/8’’ x 31-1/2’’ 3/16’’ Tarp CENTERED Washer FLAP UP 2-1/2’’ Screw per joint FLAP DOWN 3/4’’ Screws 3/16’’ Tarp Washer 2-1/2” Deck Screw (x4) 3/4” Pan Head Screw (x6) 3/16” Tarp Washer (x6) 1.
  • Page 54 PF 6066 5/8’’ x 3-3/8’’ x 17’’ (4) 30mm Deck Screws Underdeck View 2” Grade NOTE: SLIDE NOT INCLUDED WITH PB 8327 (2) 30mm Deck Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 30mm Deck Screw (x8) 1” Truss Screw (x3) Attach slide as shown.
  • Page 55 STEP 44 (2) 1/4” Washer (2) 1/4’’ x 1-3/4” Pan Screw 11” 1-3/4” Pan Screw (x2) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 56 STEP 45 NOTE: Crimp swing hanger tightly closed Ring-Trap Combo Assembly 1. Attach Quick Link to chain oriented as shown. 2. Attach Quick Link to gym ring as shown. Attach second set of Quick Links (3) links up. Attach Trapeze Bar as shown. 3.
  • Page 57 STEP 46 Swing Seat Assembly 1. Take one length of chain and place the outermost link of chain through the Quick Link as shown. 2. Place the Quick Link through the Grommet of the swing seat as shown. 3. Tighten the threaded sleeve of the Quick Link with a suitably sized wrench so that the seat is securely attached and the Quick Link cannot be easily loosened.
  • Page 58 STEP 47 Carriage Bolt Spacer Flat Washer Loc Nut Steering Wheel Cap Steering Wheel Assembly 1. Choose a desired location for the Steering Wheel and drill a 5/16” diameter hole through the lumber. NOTE: If lumber is greater than 2” in depth, you will need to counterbore the hole appropriately. 2.
  • Page 59 STEP 48 Telscope Assembly Mounting Screw Mounting Bracket Telescope Assembly 1. Position Mounting Bracket in desired location. 2. Attach Mounting Bracket to the unit using the Mounting Screw provided. 3. Insert the Telescope into the Mounting Bracket as shown. STEP 49 3/4’’...
  • Page 60 STEP 50 Fold up 5/16” Washer Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 2. Twist the Anchor-It into the ground until only the loop is exposed. 3. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using any of the holes in the strap that work best.
  • Page 63 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or chase, including the date of purchase. This warranty is valid only if the product is used for the purpose for which it was designed and installed at a residential, single family dwelling.
  • Page 64 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2015 Printed in USA...
