Model: PB 8330
ORBITER SWING SET
Roundabout
Freestanding Swing Set
Model: 2250
IMPORTANT!!
Boxes:
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
1 - Wood Posts, Brackets,
Hardware, Stakes, and Swings
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Copyright © 2018 Gorilla Playsets
Please call our Customer Service Department at the number below.
All Rights Reserved
190 Etowah Industrial Court
ASSEMBLY INSTRUCTIONS
Canton, GA 30114
www.gorillaplaysets.com
Swing-N-Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
*51-0097*
Visit our web sit at: www.swing-n-slide.com or call us at 1-800-888-1232
51-0097
© Swing-N-Slide
Printed in USA
LDR 08-23-2015
LA 9360

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB 8330 and is the answer not in the manual?

Questions and answers

Related Manuals for Swing-N-Slide PB 8330

Summary of Contents for Swing-N-Slide PB 8330

  • Page 1 190 Etowah Industrial Court ASSEMBLY INSTRUCTIONS Canton, GA 30114 www.gorillaplaysets.com Swing-N-Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 *51-0097* Visit our web sit at: www.swing-n-slide.com or call us at 1-800-888-1232 51-0097 © Swing-N-Slide Printed in USA LDR 08-23-2015 LA 9360...
  • Page 2 three 345 pounds. 2 ...
  • Page 3 PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty.

  • Page 4: Select Protective Surfacing

    PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION'S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.

  • Page 5: Swing Beam Loading

    SWING BEAM LOADING Weight Limits for Accessories: The weight limit for a Swing Belt is 225 lbs. (Although 100 lbs is the maximum recommended swinging weight capacity for the swing position.) The weight limit for a Trapeze Bar is 125 lbs. (Although 100 lbs is the maximum recommended swinging weight capacity for the swing position.) Maximum Allowable swinging weight for a three position swing: 1) The maximum allowable swinging weight at each Swing Belt position is 100 lbs.

  • Page 6: Safety Zone

    SAFETY ZONE 13'-4" 6' R 7'-0" Height 8'-0" 26'-8" 13'-4" 9'-5" 21'-5" MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72" FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 160". SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8" ABOVE THE PROTECTIVE SURFACING.

  • Page 7: Tools Required

    TOOLS REQUIRED TAPE MEASURE DRILL PHILLIPS HEAD 1/2” & 9/16’’ SOCKETS HAMMER ADJUSTABLE DRIVE & WRENCH WRENCH SCREWDRIVER LADDER SAFETY GLASSES 1/4" DRILL BIT PLIERS INCLUDED HARDWARE 3/8 x 5-1/2" carriage bolts (x12) 3/8" Flat Washer (x30) 3/8 x 5" carriage bolts (x4) 3/8 x 4"...
  • Page 8 COMPONENTS 4" Dia. x 93" Plastic-coated Post (x1) 99-0715 3-1/4" Dia. x 93" Plastic-coated Post (x4) 99-0714 1" Dia. x 49" A-Frame Brace (x2) 11-5022 2447R 2448L 2449 Swing Beam Bracket Right 2447R (x2) Swing Beam Under Beam 2449 (x2) Gorilla Mini Logo Plate (x1) Swing Beam Bracket Left 2447L (x2) 11-4027...
  • Page 9 1/4 x 2-1/2" Panhead Screw 1/4" lock washer 1/4" flat washer Note: Locate (3) pre-drilled A-Brace holes facing up. Note: Fasteners should be snug at this point. You will assemble two A-frame post assemblies. 1. Move posts apart. 2. Place the holes in the A-brace over the holes in the posts. 3.
  • Page 10 If needed, rotate poles to help with alignment 3/8 x 2-1/2" Lag Screw 1/4 x 2-1/2" 3/8" lock washer Panhead Screw Fig. 1 3/8" flat washer 1/4" lock washer 1/4" flat washer Tighten securely after L-bracket is attached Fig. 2 A-brace (2) Holes this end Support...
  • Page 11 3/8 x 4" Carriage bolt bolt cap 3/8" lock nut 3/8" flat washer 1. Carefully flip the A-frame over. 2. Remove any wood or plastic material in hole openings. Attach two brackets to the post as shown. Tighten fasteners slightly snug at this point. Do NOT fully tighten. 3.
  • Page 12 3/8 x 5-1/2" Carriage Bolts Torque Washer Mini Swing Hanger 3/8" Washer 3/8" Lock Nut Bolt Cap 1. Line up the holes of the Mini Swing Hangers with the holes in the Swing Beam. 2. Fasten the Mini Swing Hangers to the Swing Beam using 5-1/2" carriage bolts with Torque Washers on top of the Swing Beam, and 3/8"...
  • Page 13 3/8" lock nut bolt cap 3/8" flat washer This hole empty. 3/8 x 5" Carriage bolt Loosen these if you have trouble getting the beam to fit in between the swing brackets. 1. Remove any wood or plastic material in hole openings. Locate the swing beam between the brackets and attach as shown. HINT: Loosen bolts in 3-1/4"...
  • Page 14 3/8" lock nut bolt cap 3/8" flat washer 3/8 x 5" Carriage bolt 1. Carefully swing the A-frame assembly up and insert a second bolt. Attach as shown. Tighten fasteners slightly snug at this point. Do NOT fully tighten.
  • Page 15 bolt cap 3/8" lock nut 3/8" flat washer Leave this hole empty 3/8 x 5" Carriage bolt 1. Locate the second A-frame assembly and remove any wood or plastic material in hole openings. Attach to swing beam as shown. HINT: Loosen bolts in 3-1/4" posts to help align holes for 5" bolts if necessary. Tighten fasteners slightly snug at this point.
  • Page 16 3/8" lock nut bolt cap 3/8" flat washer 3/8 x 5" Carriage bolt Tighten ALL Lock nuts 3/8" flat washer until 2 threads minimum 3/8" lock washer extend past nut. 3/8 x 2-1/2" Lag screw Swing A-Frame up 1/4" Pre-drill 1.
  • Page 17 Hanging Swings 1. Hang the Trapeze Swing in the center position only. Place the end of the chain on the hook end of the Mini Swing Hanger. You may adjust the height of the Trapeze up or down by clipping onto other chain links. 2.
  • Page 18 Logo Plate Centered on Swing Beam Logo Plate 1. Bend the Logo Plate over one of the Swing Legs until it matches the Swing Beam curvature closely. 2. Place the Logo Plate centered on the Swing Beam on the front side. 3.
  • Page 19 Safety Warning Label Fold up 5/16” Washer 1-1/2” Anchor-It Lag Screw Strap Anchor-It 1 At locations circled above, twist the Anchor-It into the ground until only the loop is exposed. 2. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using the top pair of holes in the strap.
