PB 9242N
SLIDE SOLD
SEPARATELY
NOTE: UNIT IS
NOT COMPLETE
WITHOUT SLIDE
INSTALLED
AS SHOWN
WARNING:
!
Assembly by an adult.
4'' x 4'' LUMBER SOLD SEPARATELY. STAIN LUMBER TO MATCH UNIT
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
© Swing-N-Slide Inc.
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB 9242N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swing-N-Slide PB 9242N

Summary of Contents for Swing-N-Slide PB 9242N

  • Page 1 PB 9242N SLIDE SOLD SEPARATELY NOTE: UNIT IS NOT COMPLETE WITHOUT SLIDE INSTALLED AS SHOWN WARNING: Assembly by an adult. 4’’ x 4’’ LUMBER SOLD SEPARATELY. STAIN LUMBER TO MATCH UNIT IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for.
  • Page 4 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
  • Page 5 PLAYSET SAFETY ZONE 6’ -0’’ 18’ -0’’ 14’ -0’’ 6’ -0’’ 28’ -0’’ 26’ -9’’ 15’ -5’’ 6’ -0’’ 14’ -0’’ 6’ -0’’ 30’ -0’’ OF THE PLAY STRUCTURE. 84-3/4 TO SWING HANGER PIVOT 8 Minimum...
  • Page 6 Note: Swing-N-Slide has included all hardware necessary to build multiple versions of this playset. As a result, you may have left over hardware once your project is completely assembled. Please discard all excess items in a safe manner before...
  • Page 7 TOWER COMPONENTS HARDWARE (62) Loc Nut (12) (12) 1/4’’ Loc nut (44) 1-1/2’’ Lag Screw - Gold Coating (261) (22) (2) T- nuts (71) (26) (6) Fence Staple (122) (12) (12) (41) (12) (12) (4) 1’’ Truss Screw (11)
  • Page 8 (3) Step Brackets (1) LH Split Beam bracket Bracket (6) Slotted Beam Clamp (2) EZ Frame Brackets Monkey Bar (1) ID Tag (2) Boomerang Bracket PB 9242N SLIDE SOLD SEPARATELY NOTE: UNIT IS NOT COMPLETE WITHOUT SLIDE INSTALLED AS SHOWN WARNING: Assembly by an adult.
  • Page 9 (2) Safety Handle (4) Anchor-It Straps (6) Swing Hangers (6) Climbing Rocks (3) Bolt Cover (4) Anchor-It 3/8” DRILL BIT (5’’ Min.) (4) Quick Links (4) Quick Links Belt Swing weight limit: weight limit:...
  • Page 10 Board List (1) [PF 4354] 3-1/2’’ x 3-1/2’’ x 47-1/2’’ (1) [PF 4976] 3/4’’ x 3’’ x 47-1/2’’ (11) [PF 4353] 1-1/2’’ x 3-1/2’’ x 47-1/2’’ (2) [PF 4983] 5/8’’ x 3-1/4’’ x 40-1/2’’ (2) [PF 4999] 1-1/2’’ x 3-1/2’’ x 46-1/2’’ (2) [PF 4986] 5/8’’...
  • Page 11 How to select the correct fastener lumber attachment you are making. Each diagram will highlight the correct number of fasteners to use, and where to attach them. 5/4’’ Boards to 4’’ x 4’’ Pre-Drill To Minimimize Splitting 2-1/2’’ screws Apply 2 1/2” screws to the 2”x4” boards when attaching to 4”x4”...
  • Page 12 Example of a Shelf-Loc bracket connection. Shelf-Loc Bracket CORRECT! WRONG! Brackets ‘’clipped’’ brackets NOT interlocked! Example of a Shelf-Loc bracket connection. Look for ‘’TOP’’ stamp on bracket for correct orientation. Top of bracket Introduction to the Bracket system 1. ALWAYS NEVER position in a non-interlocking position.
  • Page 13 DO NOT USE LAG SCREWS HERE Brackets Attach DO NOT USE LAG SCREW HERE Screws per joint Frame 1 Construction NOTE: Lag Screws. Per Bracket Fig. 1 Fig. 2 FLUSH screws per joint FLIP Per Bracket FRAME OVER screws per joint Double check to make sure structure is square 1-1/2’’...
  • Page 14 DO NOT USE LAG Avoid splitting your SCREW HERE lumber by offsetting your edge. NOTE: Fig. 3 Fig. 4 screws Per Bracket per joint Per Bracket Double check to make sure structure is square screws per joint 1-1/2’’ Lag screw 2’’...
  • Page 15 Fig. 5 DO NOT USE LAG SCREW HERE screws per joint NOTE: Lag Screws. FLIP FRAME 1 OVER BEFORE COMPLETING THIS STEP. screws per joint Per Bracket Per Bracket Double check to make sure structure is square 1-1/2’’ Lag screw 2’’...
  • Page 16 DO NOT USE LAG SCREW HERE Fig. 6 NOTE: Lag Screws. screws per joint Tip: Flex brackets to make installation of screws screws screws Per Bracket Per Bracket screws screws per joint Double check to make sure structure is square 1-1/2’’...
  • Page 17 Fig. 7a Fig. 7 screws FLUSH per joint screws per joint FLUSH FLUSH screws per joint Fig. 7b 2’’ screw screws per joint screws 2-1/2’’ screw per joint SPACING BETWEEN BOARDS: 1/2’’ 1. Install barrier support board as shown in (Fig. 7). 2.
  • Page 18 Fig. 8 location indicated in (Fig. 8). 110-3/4'' NOTE: Use circled measurements ONLY lumber to construct the Swing Beam A-Frame. 92-3/4'' A-FRAME 83-1/2'' ATTACHES HERE 78'' NOTE: USE CIRCLED MEASUREMENTS ONLY IF USING WOODGUARD FOR THE A-FRAME 64'' 46'' 32'' Hole 14''...
  • Page 19 Fig. 9 Hammer Slotted Beam Clamp Swing Hanger 3/8'' hole T-nut t-nut Swing Beam CORRECT! (4) 1-1/4'' screws Slotted Beam Clamp Use Screwdriver to aid in tightening 30mm Wood Screw Swing Hanger (Step 1). 2. Place a Slotted beam clamp over the swing hanger as shown in (Step 2). 3.
  • Page 20 Fig. 10 Fig. XX as shown in (Fig. 10) and (Fig. 11). 2. Align EZ Frame Bracket with (Fig. 10). 3. Secure EZ Frame Bracket with making sure they are flush with each other as shown in (Fig. 10). shown in (Fig. 11). with the edges of EZ Frame Bracket.
  • Page 21 Fig. 12 T-nut Washer 2-1/2’’ screws 3-1/4’’ Hex Head Bolt 2-1/2’’ screw (Fig. 12). 2. Repeat on other bracket. Tighten both hex bolts to flush with top of T-nuts.
  • Page 22 Fig. 13 1. Position Split-Brackets on (Fig 13). and Swing Beam Assembly and center onto unit as shown in (Fig. 13). 3. Secure as shown in (Fig 13a). Fig. 13a View from Deck x 8 (each bracket) 2’’ Lag screw...
  • Page 23 Fig. 14 Pre-Drill To Minimimize Splitting 1. Install barrier support boards as shown in (Fig. 14). 2-1/2’’ screw...
  • Page 24 Fig. 15 Fig. 15a per board FLUSH per board GAP BETWEEN BOARDS IS: 2-1/8’’ per board 1. Install barrier support boards, as shown in (Fig. 15). 1-1/2’’ screw spaced in the opening. See (Fig. 15a). 2-1/2’’ screw...
  • Page 25 Fig. 16 per joint per joint FLUSH per joint per joint FLUSH 1. Install window barrier boards as shown in (Fig. 16). 1-1/2’’ screw...
  • Page 26 Fig. 17 (Fig. 17). 3/4’’ screw...
  • Page 27 Fig. 18 per joint NO GAP (Fig. 18). 1-1/2’’ screw...
  • Page 28 Fig. 19 Fig. 19a FLUSH FLUSH FLUSH per joint Fig. 19b Fig. 19c per joint FLUSH FLUSH per joint FLUSH per joint 30mm 2-1/2’’ screw (Fig. 19). NOTE: Screw is intended to secure A-Frame together until next step. (Fig. 19a). 3.
  • Page 29 Fig. 19d Fig. 19e per joint per joint per joint Secure roof to uprights per joint by inserting hardware through gap in brackets 2-1/2’’ screw 3/4’’ screw Tarp Washer 1. Attach Tarp to Roof Frame as shown in (Fig. 19d). 2.
  • Page 30 Fig. 20 90'' beam at each location shown in (Fig. 20). 77-3/4'' 65-1/2'' Hole 3-1/2''...
  • Page 31 Fig. 21 Tip: Flex brackets to make installation of FLUSH Fig. 21a per bracket FLUSH per joint Fig. 21b Note: before mounting (Fig. 21) and (Fig. 21a). 2. Secure brackets (Fig. 21b). 2-1/2’’ screw as shown in (Fig. 21). 2’’ Lag screw...
  • Page 32 Fig. 22 FLUSH Fig. 22a NO MORE THAN A NOTE: per joint per joint 2-1/2’’ screw (Fig. 22). 2. Mount Rocks to wall in a pattern that will allow your child to access the deck easily. Mount rocks per instructions below. (Fig.
  • Page 33 Fig. 23 Pre-Drill To Minimimize FLUSH Splitting Lag screws per bracket screws per bracket DETAIL OF STEP BRACKET Measure From Arrows 1-1/2’’ Lag screw 30mm Wood Screw - Gold Coating (x6) 1. Measure and place Monkey Bar Step Brackets and Boomerang Bracket on upright as shown in (Fig.
  • Page 34 Fig. 24a Fig. 24 screws per rung screws Rungs per bracket Pre-Drill To Minimimize Splitting Fig. 24b per screw FLUSH screws per bracket 1/4’’ Flat washers 1-1/2’’ Lag screw 30mm Wood Screw 2’’ Lag screw (x8) (x12) - Gold Coating (x6) (Fig.
  • Page 35 Fig. 25a Fig. 25 FLUSH Screws per bracket per screw FLUSH per bracket per screw FLUSH Pre-Drill To Minimimize Splitting Fig. 25b 1/4’’ Flat washers (x24) 1-1/2’’ Lag screw - Gold Coating (x12) 1. Attach the Monkey Bar Frame to the Monkey Bar Ladder as shown in (Fig. 25). (Fig.
  • Page 36 Fig. 26 FLUSH per joint FLUSH Sandbox Bench 2-1/2’’ screw 1. Secure Sandbox Bench as shown in (Fig 26).
  • Page 37 Plastic-coated end. Fig. 27 Swing Seat Assembly 1. Take one length of chain and place the outermost link of chain through the Security Link as shown. 3. Tighten the threaded sleeve of the Security Link with a suitably sized wrench so that the seat is securely attached 4.
  • Page 38 Safety Handle Fig. 28 surface (Fig. 28). 2. Reference (Fig. 28a) for Safety Handle placement. Panhead Screw Deck Surface Fig. 28a...
  • Page 39 Pirate’s Ladder Fig. 29 (Fig. 29). Note: Refer to (Fig. 21) for accessory arm placement. Fig. 29a 2. Attach bolt covers over loc nuts at all three as shown in (Fig. 29a). Fig. 29b 3. Using two rope staples to secure the Then thread the rope through both staples.
  • Page 40 Fig. 30 1’’ Truss Screw included with slide Use truss head screws to to secure slide to deck. SLIDE SOLD SEPARATELY Fig. 30a Surfacing Material 30mm Wood Screw Slide Stake NOTE: If you received a Summit Slide with your kit, please follow the slide installation instructions included with your slide.
  • Page 41 1/2’’ Pan Head Screw NIÑOS ENTRE 2 Y 10 AÑOS DE EDAD PARA USO EN EL HOGAR/USO RESIDENCIAL ÚNICAMENTE RÉSERVÉ À L’UTILISATION PAR DES ENFANTS DE 2 À 10 ANS USAGE RÉSIDENTIEL/FAMILIAL SEULEMENT 1212 Barberry Drive Janesville, WI 53545 1-800-888-1232 www.swing-n-slide.com (Fig. 31).
  • Page 42 Fig. 32 Loc-Nut Hex Head Bolt Fig. 32c Fig. 32a Fig. 32b Fig. 32d Quick Link Quick Link Quick Link 1. Insert Seat into Handle as shown in (Fig. 32). Secure in place with hardware shown. Note: Make certain no more than two bolt threads protrude from the Loc-Nut once fully tightened.
  • Page 43 Anchor-It Fig. 33 Activity Centers 1. Determine the final location of your activity center. 2. Place the Anchor-It stakes adjacent to the base and near the corners of your activity lag bolt metal strap the ground until only the loop is exposed. 3.
  • Page 44 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. Printed in USA...
