- Page 1 Avalue Intelligent Display & System HID-2334 23.8” Ultra-Light Medical Cart Panel PC with Multi-touch Function User Manual Ed- 22 July 2020 Copyright © 2020 Avalue Technology Inc., All Rights Reserved. DMR No: T54268-00 Part No: E2017H340A3R Rev: 4...
- Page 2 Purposes and Applications HID-2334 is intended to be used in healthcare institutions for general purpose as an assisting device for data access – patient information, medical records, media services, and so on. The product is designed for general or special use in the hospital environment.
- Page 3 3. Repair of the device may also only be carried out by Warning! Because of the danger of electric shock, never remove the cover of a device while it is in operation or connected to a power outlet. HID-2334 Quick Reference Guide...
- Page 4 For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. Caution! To prevent overheating, do not cover the openings and place the device in direct sunlight or near radiant heaters. HID-2334 Quick Reference Guide...
- Page 5 9. Improper installation of VESA mounting can result in serious personal injury! VESA mount installation should be operated by professional technician, please contact the service technician or your retail if you need this service. HID-2334 Quick Reference Guide...
- Page 6 IEC 60601-1-1. The unit is for exclusive interconnection with IEC 60601-1 certified equipment in the patient environment and IEC 60601-1 certified equipment outside of the patient environment. If in doubt, consult the technical services department or your local representative. HID-2334 Quick Reference Guide...
- Page 7 Warning! To avoid risk of electric shock, this equipment must only be connected to a supply main with protective earth. Caution! This adapter EDAC EM11011M(18) is a forming part of the medical device. Attention! Ne modifiez pas cet équipement sans l'autorisation du fabricant. HID-2334 Quick Reference Guide...
- Page 8 MANUFACTURER to replace battery packs. Précaution! Do not use the power adapter that isn’t made for the equipment, supplying the equipment with inappropriate voltage may cause harm to the battery (if any) or even worse burn the equipment. HID-2334 Quick Reference Guide...
- Page 9 Caution! Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions." Attention! Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées selon les instructions HID-2334 Quick Reference Guide...
- Page 10 HID-2334 User Manual Explanation of Graphical Symbols Warning: dangerous voltage Caution Note ISO 7000-1641: Follow operating instructions or Consult instructions for use. Direct current. Equipotential Stand-by US Conformance Follow the national requirements for disposal of equipment. HID-2334 Quick Reference Guide...
- Page 11 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. HID-2334 Quick Reference Guide...
- Page 12 Selection of other channels is not possible. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Shielded interface cables must be used in order to comply with emission limits. HID-2334 Quick Reference Guide...
- Page 13 EMI sensitive devices in its surrounding which may malfunction therefore. Environmental protection Follow national requirements to dispose of unit. Manufacturer Avalue Technology Inc. 7F, No.79, Lide St., Zhonghe District, New Taipei City, 235, Taiwan TEL: +886-2-8226-2345 FAX: +886-2-8226-2777 Web: www.avalue.com.tw Information: sales@avalue.com.tw HID-2334 Quick Reference Guide...
-
Page 14: Table Of Contents
HID-2334 User Manual CONTENT 1. HID-2334 Multi Touch Medical Panel PC Features ........ 16 1.1 Packing List ..................16 1.2 Specifications ..................17 1.3 Front view ..................20 1.4 Rear & Bottom view ................21 1.6 System Dimensions ................23 2. - Page 15 4.4.24 Touch Panel connector (JTOUCH) ........50 4.4.25 LVDS connector (LVDS1) ............. 51 4.4.26 Battery mode connector (JBAT_AUX1) ........ 52 4.5 HID-2334 DB-A Connector list ............52 4.6 HID-2334 DB-A Connectors settings ..........53 4.6.1 Battery connector 1 (JBAT1) ........... 53 4.6.2 Battery connector 2 (JBAT2) ...........
-
Page 16: Hid-2334 Multi Touch Medical Panel Pc Features
HID-2334 User Manual 1. HID-2334 Multi Touch Medical Panel PC Features ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ In this chapter, you will get to know all features of our HID-2334 Multi Touch Medical Panel PC. 1.1 Packing List 1 x HID-2334 Medical Panel PC ... -
Page 17: Specifications
HID-2334 User Manual 1.2 Specifications Component Mother Board HID-2334 M/B + Battery Charger Board Charger Board HID-2334 Battery Charging Board 7th Generation Intel® Core Kaby Lake i5-7300U Processor CPU Cooler (Type) Heatsink Memory 2 x 260pin SODIMM socket up to 32GB Per Slot DDR4 2400 SDRAM... - Page 18 Sine Vibration Test Reference IEC60068-2-6 Testing procedures Test Fc : Vibration sinusoidal 1 Test Acceleration : 2G 2 Test frequency : 5~500 Hz 3 Sweep：1 Oct/ per one minute. (logarithmic) 4 Test axis : X,Y and Z axis HID-2334 Quick Reference Guide...
- Page 19 0 ~ 40 degree Operating Humidity 0 ~ 90% Relative Humidity, Non-condensing Storage and -20 60 degree, 10%~95%@35°C, non-condensing Transportation Condition Atmospheric Pressure 700~1060hPa Expected Service Life 16363.27hrs Note: Specifications are subject to change without notice. HID-2334 Quick Reference Guide...
-
Page 20: Front View
HID-2334 User Manual 1.3 Front view Camera Power Icon Battery Touchscreen Backlight Icon Brightness Volume Status icon Icon Reading Up/down Icon Up/down Icon Light Icon HID-2334 Quick Reference Guide... -
Page 21: Rear & Bottom View
USB3.0: for USB drive/KB/Mouse/USB HDD…etc USB device LAN: for internet connection LINE OUT: Line-out jack MIC IN: Mic-in jack Note! Equipotential terminal needs to be linked to the hospital ground/earth system before booting the system to protect both operator and system HID-2334 Quick Reference Guide... - Page 22 HID-2334 User Manual 1.5 Side & Rear view Battery 1 Battery 2 Camera Cover On/Off Switch HDD Cover Battery Bays HID-2334 Quick Reference Guide...
-
Page 23: System Dimensions
HID-2334 User Manual 1.6 System Dimensions (Unit: mm) HID-2334 Quick Reference Guide... -
Page 24: Setting Up Hid-2334 Multi Touch Panel Pcs
HID-2334 User Manual 2. Setting Up HID-2334 Multi Touch Panel PCs ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ This chapter gives instructions on how to set up HID-2334 Multi Touch Panel PC and how to connect different cables. 2.1 VESA Mounting 2.2 Cleaning and Disinfecting HID-2334 Quick Reference Guide... -
Page 25: Vesa Mounting
Installation instructions follow: First attach the wall-mounting to the heat-sink of the HID-2334, securing it in place with four of the M4 x 6mm screws provided. Mount the on the wall, stand or other flat surface. - Page 26 Suggested Screw type for mounting Note: 4 pieces of M4 x 8mm~10mm screws Warning! Use suitable mounting apparatus to avoid risk of injury. Attention! Utilisez un appareil de montage approprié pour éviter tout risque de blessure. HID-2334 Quick Reference Guide...
-
Page 27: Cabling
Follow below step Connecting the Ground pin 1. With system ready, find the equipotential terminal on the rear side of the HID-2334. An equipotential terminal is provided to optionally connect to a hospital ground/earth system. 2. Prepare grounding cable and the other terminal links to the hospital ground/ earth system. - Page 28 HID-2334 User Manual Please follow below steps to connect power cable to system. The HID-2334 could only be powered by a DC power adapter (EDAC Model no. EM11011M(18)). Be sure to always handle the power cords by holding the plug ends only.
-
Page 29: Battery Installation (Optional)
A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. HID-2334 has two battery bays for Lithium Ion battery pack installation. To install battery, please follow the steps below. -
Page 30: Barcode Scanner Kit Installation
Step 2: Install the barcode scanner kit bracket with two screws as indicated. Step 3: Re-install the I/O cover. 2.5 Cleaning and Disinfecting During normal use of HID-2334, the device may become dirty and should be regularly cleaned. Cleaning Instructions 1. - Page 31 Glycerine Green tinctured soap Hydrochloric Acid Incidin liquid Incidin plus Isopropyl alcohol Kerosene Lanoline Applied Methanol Mikrozid liquid Nitric Acid Paraffin Oil Propanol Solution of salt Sulfuric Acid Toluene Vaseline Applied Virkon and water (1:100) Windex HID-2334 Quick Reference Guide...
-
Page 32: Using Hid-2334 Multi Touch Panel Pcs
HID-2334 User Manual 3. Using HID-2334 Multi Touch Panel PCs ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ This chapter describes in detail all features of HID-2334 Multi Touch Panel PC. 3.1 Turn ON/OFF the System 3.2 Using LCD Display and Touch Screen HID-2334 Quick Reference Guide... -
Page 33: Turn On/Off The System
1. Press on the Power ON/OFF icon firmly for 4 seconds. 2. The Power ON/OFF LED will turns orange to indicate power is off. 3. Your system is turned OFF. Note: We recommend using operating system shut down procedure to turn the system OFF. HID-2334 Quick Reference Guide... -
Page 34: Using Lcd Display And Touch Screen
3. Press LED reading light icon for 4 secs to turn off the touch function (touch function always on as default) 4. Press LED reading light icon for 4 secs to turn on the touch function HID-2334 Quick Reference Guide... -
Page 35: Hardware Configuration
HID-2334 User Manual 4. Hardware Configuration 4.1 HID-2334 Overviews HID-2334 Quick Reference Guide... -
Page 36: Hid-2334 Db-A Overviews
HID-2334 User Manual 4.2 HID-2334 DB-A Overviews HID-2334 Quick Reference Guide... -
Page 37: Hid-2334 Jumper And Connector List
HID-2334 User Manual 4.3 HID-2334 Jumper and Connector list Jumpers Label Function Note Clear CMOS 3 x 1 header, pitch 2.00mm JCOMS1 LCD backlight brightness 3 x 1 header, pitch 2.54mm JSBKL1 adjustment JSATX1 AT/ATX auto power on select 3 x 1 header, pitch 2.00mm... - Page 38 4 x 2 header, pitch 2.00 mm EDP1 Display Port connector 10 x 2 wafer, pitch 1.25 mm DCIN1 DC power-in connector MIC1 Mic-in audio jack LOUT1 Line-out audio jack FAUD1 Front Audio connector 5 x 2 header, pitch 2.54 mm HID-2334 Quick Reference Guide...
-
Page 39: Hid-2432 Mb Jumpers & Connectors Settings
HID-2334 User Manual 4.4 HID-2432 MB Jumpers & Connectors settings 4.4.1 Clear CMOS (JCOMS1) Protect* Clear CMOS *Default 4.4.2 LCD backlight brightness adjustment (JSBKL1) PWM Mode* DC Mode * Default HID-2334 Quick Reference Guide... -
Page 40: At/Atx Auto Power On Select (Jat1)
4.4.4 Front Audio connector (FAUD1) Signal PIN PIN Signal LINE2_JD LINE2_LIN HD_AGND MIC2_JD LINE2_RIN AUD_FRONT_DET MIC2_RIN MIC2_LIN 4.4.4.1 Signal Description –Front Audio connector (FAUD1) Signal Signal Description LINE2-JD AUDIO IN (LINE_RIN/LIN)sense pin MIC2-JD MIC IN (MIC_RIN/LIN) sense pin HID-2334 Quick Reference Guide... -
Page 41: On-Board Header For Usb2.0 (Jusb3)
HID-2334 User Manual 4.4.5 On-board header for USB2.0 (JUSB3) Signal PIN PIN Signal +5VSB +5VSB USB_DN7 USB_DN8 USB_DP7 USB_DP8 4.4.6 On-board header for USB2.0 (JUSB4) Signal +5VSB USB_DN9 USB_DP9 HID-2334 Quick Reference Guide... -
Page 42: Battery Connector (Bt1)
HID-2334 User Manual 4.4.7 Battery connector (BT1) Signal +RTCBAT 4.4.8 Display Port connector (EDP1) Signal PIN PIN Signal EDP_PanelTXN0 EDP_PanelTXN3 EDP_PanelTXP0 EDP_PanelTXP3 EDP_PanelTXN1 EDP_PanelTXP1 EDP_PanelAUXN EDP_PanelAUXP EDP_PanelTXN2 EDP_PanelTXP2 EDP_Panel_HPD +V3512_EDP +V3512_EDP HID-2334 Quick Reference Guide... -
Page 43: Speaker Connector (Spk1)
HID-2334 User Manual 4.4.9 Speaker connector (SPK1) Signal SPK_R- SPK_R+ SPK_L- SPK_L+ 4.4.10 Power connector (PWR1) Signal PIN PIN Signal +VIN_26V +VIN_26V HID-2334 Quick Reference Guide... -
Page 44: Spi Connector (Jspi1)
HID-2334 User Manual 4.4.11 SPI connector (JSPI1) Signal PIN PIN Signal HOLD# SPI_SI SPI_SO SPI_CLK SPI0_CS0# +3.3VSB 4.4.12 EC Debug connector (JEC_SPI) Signal PIN PIN Signal +3VSPI_EC EC_FSCE# EC_FSCK EC_FMISO EC_FMOSI EC_HOLD# EC_SMCLK EC_SMDAT HID-2334 Quick Reference Guide... -
Page 45: Lcd Inverter Connector (Jbkl1)
HID-2334 User Manual 4.4.13 LCD Inverter connector (JBKL1) Signal LVDS_BKLTCTL LVDS_BKLT_EN +12V 4.4.14 Reading Light connector (JLED_LIGHT) Signal +5VSB READ_LIGHT_EN HID-2334 Quick Reference Guide... -
Page 46: Sata Power Connector (Spwr1)
HID-2334 User Manual 4.4.15 SATA Power connector (SPWR1) Signal +12V 4.4.16 I2C connector (I2C1) Signal +3.3V INT_I2C0# I2C0_CLK I2C0_DATA HID-2334 Quick Reference Guide... -
Page 47: General Purpose I/O Connector (Dio1)
HID-2334 User Manual 4.4.17 General purpose I/O connector (DIO1) Signal PIN PIN Signal SMB_CLK_S SMB_DATA_S 4.4.18 Fan connector (FAN1) Signal +12V CPUFANIN FAN_PWM0 HID-2334 Quick Reference Guide... -
Page 48: Front Panel Connector 1 (Jfpt1)
Signal +HD_LED +PWR_LED -HD_LED -PWR_LED +Reset +PWR_BNT -Reset -PWR_BNT 4.4.20 Front Panel connector 2 (JFPT2) Signal PIN PIN Signal PWR_LED# TOUCH_OFF_LED# 15 SUS_LED# BATTERY_2_B# PWR_BTN_EC# BATTERY_2_O# TOUCH_ON_OFF BATTERY_1_B# VOLUME_DN BATTERY_1_O# VOLUME_UP READ_LIGHT BLK_BRI_DN BKL_ON_OFF BLK_BRI_UP +3.3V HID-2334 Quick Reference Guide... -
Page 49: Serial Port 1 Connector (Com1)
PIN PIN Signal COM_DCD#_1 COM_RXD#_1 _485_422TX1- _422RX1+ COM_TXD_1 COM_DTR#_1 COM_DSR#_1 _485_422TX1+ COM_CTS#_1 COM_RTS#_1 _422RX1- COM_RI#_1 4.4.22 Serial port 2 connector (COM2) Signal PIN PIN Signal COM_DCD#_2 COM_RXD#_2 _485_422TX2- _422RX2+ COM_TXD_2 COM_DTR#_2 COM_DSR#_2 _485_422TX2+ COM_CTS#_2 COM_RTS#_2 _422RX2- COM_RI#_2 HID-2334 Quick Reference Guide... -
Page 50: Lpc Connector (Jlpc)
HID-2334 User Manual 4.4.23 LPC connector (JLPC) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 PCH_PLTRST# LPC_AD2 LPC_FRAME# LPC_AD3 LPC_CLK LPC_SERIRQ 4.4.24 Touch Panel connector (JTOUCH) Signal +5VSB USB_DN10 USB_DP10 HID-2334 Quick Reference Guide... -
Page 51: Lvds Connector (Lvds1)
LVDS_DATA0_P 10 LVDS_DATA1_P LVDS_DATA0_N 12 11 LVDS_DATA1_N LVDS_DATA2_P 16 15 LVDS_DATA3_P LVDS_DATA2_N 18 17 LVDS_DATA3_N LVDS_DATA4_P 22 21 LVDS_DATA5_P LVDS_DATA4_N 24 23 LVDS_DATA5_N LVDS_DATA6_P 28 27 LVDS_DATA7_P LVDS_DATA6_N 30 29 LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_CLK1_N LVDS_CLK2_N +12V +12V HID-2334 Quick Reference Guide... -
Page 52: Battery Mode Connector (Jbat_Aux1)
4.4.26 Battery mode connector (JBAT_AUX1) Signal PIN PIN Signal CHARGER_DISABLE BAT2_PRSNT BAT1_PRSNT EC_SMDAT1 DB_AC_SENCE EC_SMCLK1 4.5 HID-2334 DB-A Connector list Connectors Label Function Note Battery connector 1 5 x 2 header, pitch 2.00mm JBAT1 Battery connector 2 5 x 2 header, pitch 2.00mm... -
Page 53: Hid-2334 Db-A Connectors Settings
HID-2334 User Manual 4.6 HID-2334 DB-A Connectors settings 4.6.1 Battery connector 1 (JBAT1) Signal PIN PIN Signal +V_CHARGER_1 10 +V_CHARGER_1 BAT_SMCLK_A BAT_SMCLK_A BAT_SMDAT_A BAT_SMDAT_A 4.6.2 Battery connector 2 (JBAT2) Signal PIN PIN Signal +V_CHARGER_2 10 +V_CHARGER_2 BAT_SMCLK_B BAT_SMCLK_B BAT_SMDAT_B BAT_SMDAT_B... -
Page 54: Dc-In Connector (Jvin1)
HID-2334 User Manual 4.6.3 DC-in connector (JVIN1) Signal PIN PIN Signal +DC_IN +DC_IN 4.6.4 DC-out connector (JVOUT1) Signal PIN PIN Signal +DCOUT +DCOUT HID-2334 Quick Reference Guide... -
Page 55: Battery Mode Connector (Jaux1)
HID-2334 User Manual 4.6.5 Battery mode connector (JAUX1) Signal PIN PIN Signal CHARGER_DISABLE BAT2_PRSNT BAT1_PRSNT EC_SMB_SDA AC_PRSNT EC_SMB_SCL HID-2334 Quick Reference Guide... -
Page 56: General Safety Guide
You want to remove/install any parts Thermal The HID-2334 is a fanless design system, heat is dispatch through rear metal heatsink which is located at VESA mount area.. When using your HID-2334 systems, it is normal for the metal heatsink to get warm. The rear metal heatsink of the HID-2334 functions as a cooling surface that transfers heat from inside the computer to the cooler air outside. - Page 57 Handle your HID-2334 with care. It is made of metal, glass, and plastic and has sensitive electronic components inside. Don't use a damaged HID-2334, such as one with a cracked screen, as it may cause injury. Setup HID-2334 on a stable work surface.
- Page 58 (Ex: fire or explosion). HID-2334 Quick Reference Guide...
-
Page 59: Touch Button Guide
Brightness Control User Behavior Brightness Status Short press brightness up icon Brightness level being turned up Short press brightness down icon Brightness level being turned down HID-2334 Quick Reference Guide... - Page 60 Long press touchscreen icon 3 seconds Backlight is turned on simultaneously. when backlight is off Brightness level automatically return to the value before backlight was off. HID-2334 Quick Reference Guide...
- Page 61 Touchscreen is locked after 3 seconds long press. Touchscreen icon shows solid blue light To unlock, press touch icon for another 3 seconds. Touchscreen icon shows no light Touchscreen is functional. HID-2334 Quick Reference Guide...
- Page 62 Battery power below 20% Battery status icon shows fast blinking orange light Battery power below 10% (at 0.5 sec interval) Battery status icon shows slow blinking orange light Terminal charging when connected with adapter (at 2.5 sec interval) HID-2334 Quick Reference Guide...
