- Page 1 Instruction Sheet WELCOME TO THE CLUB BrewZilla 35L All-in-one Brewery with integrated Pump Generation 3.1.1 http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 1 of 29...
- Page 2 (p.20-22). Using chemicals not tested or recommended on the BrewZilla can result in permanent damage and void warranty. If you require further assistance with chemical compatibility please contact http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 2 of 29...
- Page 3 Malt Pipe Overflow Funnel for Upper Tube Malt Pipe Reinforced Bottom Screen - 3/8 female thread (No Seal Required) Malt Pipe Reinforced Cover Screen (No Seal Required) Malt Tube Black Silicone Plug http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 3 of 29...
- Page 4 The bottom of the BrewZilla has been lifted and vent holes multiplied. For this reason you can brew directly on a flat surface without fear of parts overheating with extended boils. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 4 of 29...
- Page 5 Once the screen is in place, fill the boiler with the desired amount of water for mashing in. Set the temperature on the display and wait for the water to heat up. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 5 of 29...
- Page 6 BrewZilla is fairly straight forward to fit. Make sure the silicone seal is on the tap body prior to installation. (see image below). The lock nut can be tightened onto the thread from the inside of the BrewZilla boiler. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 6 of 29...
- Page 7 This plug will prevent grain for pouring into the middle of the pi pe and ending up in the boiler. If you lose this piece, you can simply place foil over the top. bottom screen. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 7 of 29...
- Page 8 Once the handle has been fitted you can lift/maneuver the malt pipe easily. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 8 of 29...
- Page 9 Using the powerful 1900w element with malt pipe inserted may scorch the bottom of your BrewZilla and result in some pretty nasty sweet flavours. NOTE: The wattage buttons on 110-120v BrewZilla units is less. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 9 of 29...
- Page 10 If you need to rotate the racking arm to fill your fermenter, please switch off the pump and readjust the camlock to the position you need then reengage the camlock. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 10 of 29...
- Page 11 7.1 - Ultra Low Watt Density Elements - ULWD Meaning brighter beer can be brewed without the fear of scorching and burnt off-flavours; From 9.4w+ per/cm² to just 6w per/cm² http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 11 of 29...
- Page 12 Once the BrewZilla has started to boil normally the single 1900 watt element is sufficient to maintain a constant rolling boil. Then make your hop additions as per your recipe. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 12 of 29...
- Page 13 / bladder and then simply leave it at ambient temperature for 24hrs to cool down. (Preferably out of direct sunlight) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 13 of 29...
- Page 14 So use this adjustment to achieve your desired wort temperature so the wort is at a suitable temperature to put into your fermenter. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 14 of 29...
- Page 15 Once the time has cycled out from one stage it will jump to the next stage. Once all the stages are complete the alarm will sound. If you set 00:00 in the time for a particular stage that stage will be skipped. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 15 of 29...
- Page 16 7. Play/Pause – This button will play or pause the brewing process. When the pause button is pressed the elements are turned off and the timer will stop. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 16 of 29...
- Page 17 4. Press the time button again to return to the home screen. Note: The calibration figure must be set in Celsius but it will affect the displayed temperature in both Celsius and Fahrenheit. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 17 of 29...
- Page 18 5. You do not need to use all stages if you do not want to. If you set a stage to 00:00 time this stage will be ignored. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 18 of 29...
- Page 19 8. When a particular stage is being played the icon for that particular stage will flash on the display. 9. When all stages are complete the BrewZilla will sound an alarm and it will hold the last set temperature in the stage settings. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 19 of 29...
- Page 20 It is also a great brewery sanitizer for any of your equipment that comes into contact with fermented beer. E.G mash paddle if you’re adding gelatin / dextrose for clarifying / priming and stirring the vessel. (Part No. KL05494) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 20 of 29...
- Page 21 Hydrometer. The refractometer will not be as accurate now that it has alcohol in solution. We advise this to be used in conjunction with a measuring cylinder. (Part No. KL04312) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 21 of 29...
- Page 22 (Part No. KL5289) BrewZilla 35L 3.1.1 – Neoprene Thermal Jacket This jacket makes a significant difference when comparing the efficiency of the BrewZilla units and it’s a jacket that will pay itself off in energy saving so it's a good option to any new BrewZilla User conscious of their power bill or heat up time.
- Page 23 We picture it like washing your hands that are covered in toffee, yes you’ll get it off with cold water. But it will come off faster and use less water if it was warm. #showerthought (Part No. KL07252) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 23 of 29...
- Page 24 Adjusting your pH in conjunction with the pH Meter and perhaps BrewFather / Brewing Calculators to know how much to add. Phosphoric acid is our preferred means of acidifying pH in the brewing process. (Part No. KL05364) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 24 of 29...
- Page 25 There are three alternatives to the stock cooling coil. From left to right The Braided Counterflow Chiller, The Chillout Plate Chiller and the very chemically resistant Coolossus CounterFlow Chiller. KL02035 KL10977 KL08747 http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 25 of 29...
- Page 26 Distillation Lid for BrewZilla 35L (47mm hole) Make beer and spirits! with this handy attachment you will be able to fit an AlcoEngine Pot or Reflux still to your BrewZilla 35L or DigiBoil 35L. (Part No. KL03483) AlcoEngine Pot Still A pure pot still is used when you want the flavour of the wash to come through.
- Page 27 All you need to do is make sure you have adequate water/coolant flowing through the head and just about everything else will look after itself. (Part No. KL04640) http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 27 of 29...
- Page 28 Temperature overheated. This can occur for similar reasons as the E3 error. Also need to make sure that the vents on the side of the boiler are free and are not covered. The vents need to have good ventilation. http://www.KegLand.com.au Last Updated 12/01/2021 09:01 AM Page 28 of 29...
- Page 29 BrewZilla, recipes or tips and tricks.. If you need hardware support please contact your nearest BrewZilla distributor. Warranty (Australia) The BrewZilla 35L & 65L Generation 3.1.1 comes with a 3 Year Warranty when sold in Australia. To lodge a warranty claim in Australia please forward as many visual pieces of...
