- Page 1 KL25164 – Chuck Installation Manual Chuck Installation Manual Fully Automatic Cannular Canning Machine Single Lane KegLand Distribution PTY LTD www.KegLand.com.au www.KegLand.com.au Last Updated 21/12/2022 16:17 PM Page...
- Page 2 KL25164 – Chuck Installation Manual All Fully Automatic Cannular Canning Machines – Single Lane are calibrated and fitted with a B64 Chuck. The reason being is that the B64 can ends have a wider tolerance range compared to VISY/CDLE or Super Can ends. Meaning that you will save money in the long term with maintenance costs being heavily reduced and a greater consistency of cans that are within specification as a result of wider double seam tolerances.
- Page 3 KL25164 – Chuck Installation Manual 1.4 Remove the 1 operation roller. To gain access to the chuck it is best to remove the 1 Operation Roller. To do this, loosen the locking nut with the hook spanner supplied with the machine as shown below and then loosen the roller from the actuation arm until it is removed from the machine.
- Page 4 KL25164 – Chuck Installation Manual 1.5 Remove the Chuck Remove the chuck by holding the drive shaft with the 19mm spanner and hook spanner which was provided with the machine. This is a reverse thread. To loosen the chuck rotate it counter clockwise using the ring spanner as shown below: www.KegLand.com.au...
- Page 5 KL25164 – Chuck Installation Manual 1.6 Install your Replacement or VISY Chuck Install your chuck onto the thread of the drive shaft ensuring that the spring assembly has been installed into the chuck in the orientation below, such that the spring inserts into a bung on either...
- Page 6 KL25164 – Chuck Installation Manual After you install the chuck and reinstall the 1st Op Roller onto the Single Lane Cannular you will then need to adjust the 1st Operation and 2nd Operation Roller Positions relative to the chuck to bring the machine into specification.
- Page 7 KL25164 – Chuck Installation Manual www.KegLand.com.au Last Updated 21/12/2022 16:17 PM Page...
- Page 8 KL25164 – Chuck Installation Manual 3.0 Adjust 1 Op and 2 Op Roller X-Gap Before adjusting the x-axis gap of the roller, you must disconnect the air supply to the unit. With the air disconnected manually push the roller towards the chuck.
- Page 9 KL25164 – Chuck Installation Manual 4.0 Roller Gap Settings for Double Seam Specification The x and y gap settings for the 1 Operation Roller and 2 Operation roller are the same for a B64 and VISY Chuck. Please bring the rollers into the positions below relative to the chuck: Op Roller Y-Gap = 0.05 mm (As close as possible without touching the chuck)
- Page 10 KL25164 – Chuck Installation Manual B64 Chuck 2 Op Roller Gap Measurements When adjusting the roll height and gap settings for the 2 operation roller for a B64 chuck refer to the image below to determine where the feeler gauge should be placed and which surfaces on the chuck and rollers the measurements are taken from www.KegLand.com.au...
- Page 11 KL25164 – Chuck Installation Manual 4.2 VISY Chuck Measurements VISY Chuck 1 Op Roller Gap Measurements When adjusting the roll height and gap settings for the 1st operation roller for a VISY chuck refer to the image below to determine where the feeler gauge should be placed and which surfaces on the chuck and rollers the measurements are taken from.
- Page 12 KL25164 – Chuck Installation Manual VISY Chuck 2 Op Roller Gap Measurements When adjusting the roll height and gap settings for the 2nd operation roller for a VISY chuck refer to the image below to determine where the feeler gauge should be placed and which surfaces on the chuck and rollers the measurements are taken from.
