Letterbox plate template

Advertisement

Quick Links

LETTER BOX PLATE
LETTER BOX PLATE
Clear plastic.
Sight marks.
Three sizes of letterbox
plate.
To suit letter plate sizes:
220 x 50mm.
210 x 60mm.
200 x 60mm.
Requires:
1/2" collet plunge router.
12mm x 50mm straight
cutter Ref. 3/73D or
C200D.
30mm guide bush
Ref. GB30*.
Size: 326mm x 290mm x 8mm.
*A Unibase may be required for
certain makes and models of
routers.
TEMPLATE
FOR GUIDING THE ROUTER
Clear plastic template for use with
any 1/2" shank plunge router to
accurately rout apertures for three
sizes of letter plate.
TEMP/LB/A
