- Page 1 AARIA PRO P SERIES R32 INSTALLATION AND TECHNICAL SERVICE INSTRUCTIONS...
- Page 2 While your technical skills and knowledge will certainly be more than sufficient, this booklet contains all the information that we have deemed necessary for the device's correct and easy installation. Thank you again, and keep up the good work. RIELLO COMPLIANCE R AARIA PRO P heat pumps are compliant with the following European Directives: —...
-
Page 3: Table Of Contents
AARIA PRO P TAbLE OF CONTENTS GENERAL INFORMATION ....p. 4 General Notices ......p. 4 Safety precautions . -
Page 4: General Information
GENERAl INfORMAtION GENERAL INFORMATION According to EU Regulation no. 517/2014 regarding certain General Notices fluorinated greenhouse gases, the total amount of refrige- rant contained within the installed system must be indi- cated. This information can be found on the unit technical When you get the product, check immediately that the con- data plate. -
Page 5: Unit Description
Unit description R AARIA PRO P is a heat pump outdoor unit that can be cou- pled to indoor units of the same series for the air-conditioning RIELLO Spa - Via Ing. Pilade Riello, 37045 LEGNAGO (VR) - Italy Model AARIA MONO 25 PLUS of middle-sized rooms. -
Page 6: Layout
GENERAl INfORMAtION Layout MODEl 1070 M Terminal blocks cover Four-way valve Compressor Filter Intake separator Heat exchanger Connections cover Electric fan 10 Upper panel Refrigerant connections Fan protection grille... - Page 7 GENERAl INfORMAtION MODEl 1100 M Terminal blocks cover Refrigerant connections Four-way valve Compressor Filter Intake separator Heat exchanger Upper panel Electric fan 10 Fan protection grille...
- Page 8 GENERAl INfORMAtION MODEl 1125 M - 1125 t Compressor Electric fan Intake separator Refrigerant connections Intake separator Electrical box Four-way valve Upper panel Heat exchanger 10 Fan protection grille...
- Page 9 GENERAl INfORMAtION MODEl 1140 t Intake separator Compressor Electric fan Intake separator Refrigerant connections Muffler Electrical box Four-way valve 10 Upper panel Heat exchanger Fan protection grille...
-
Page 10: Technical Specifications
GENERAl INfORMAtION Technical specifications Performance combined with AMW P Model AMW 70 P Cooling performance [A35 / A27] Capacity at rated air flow 7,00 Absorbed power at rated air flow 2,17 kW/kW 3,23 Capacity at maximum air flow 7,50 Absorbed power at maximum air flow 2,50 Capacity at minimum air flow 2,20... - Page 11 GENERAl INfORMAtION Performance combined with AMK P Model AMK 70 P AMK 100 P AMK 125 P AMK 140 P Cooling performance [A35 / A27] Capacity at rated air flow 7,10 9,20 12,00 12,20 Absorbed power at rated air flow 2,30 3,07 4,30...
- Page 12 GENERAl INfORMAtION Performance combined with AMD P AMD 70 AMD 70 AMD 100 AMD 125 AMD 140 AMD 125 AMD 140 Model Cooling performance [A35 / A27] Capacity at rated air flow 7,10 7,10 9,50 11,90 12,50 12,00 13,50 Absorbed power at rated air flow 3,21 2,30 3,16...
- Page 13 GENERAl INfORMAtION Performance combined with AMS P Model AMS 70 P AMS 100 P AMS 125 P AMS 140 P Cooling performance [A35 / A27] Capacity at rated air flow 7,10 9,50 12,00 12,90 Absorbed power at rated air flow 2,20 3,13 4,30...
- Page 14 GENERAl INfORMAtION Outdoor unit Model 1070 M 1100 M 1125 M 1125 t 1140 t Cooling performance [A35 / A27] Nominal capacity 7,10 9,20 12,00 12,10 12,50 Nominal power input 2,30 3,07 4,30 4,20 3,90 Rated frequency Maximum frequency Minimum frequency Nominal current consumption 10,00 13,30...
- Page 15 GENERAl INfORMAtION Minimum floor area Minimum floor area for indoor unit (m²) Gas charge Indoor unit installation floor Window Wall Ceiling 1,10 No requirements 1,224 1,225 12,88 4,64 1,43 0,96 1,30 14,50 5,22 1,61 1,08 1,90 30,98 11,15 3,44 2,30 2,00 34,32 12,36...
-
Page 16: Operating Limits
GENERAl INfORMAtION Operating limits Operating mode temperature Indoor air (W.b.) °C Cooling Outdoor air (D.b.) °C Indoor air (D.b.) °C Heating Outdoor air (W.b.) °C The values are based on the following condition: — pipe length: 5 m — air flow: maximum —... -
Page 17: Installation
The Instruction book comes with the equipment and it should be taken, read and kept carefully. The document envelope must be kept in a safe place. Any duplicate must be requested from Riello S.p.A. which reser- ves to charge the cost. Model... -
Page 18: Storage
INStAllAtION Handles Strapping bands Model 1070 M 1100 M 1125 M 1125 t 1140 t Document envelope and material supplied as kit Product dimensions 1350 Follow the below instructions for packing removal and product handling: — transport the equipment in the installation place —... -
Page 19: Recommended Distances
INStAllAtION — confined locations in which the device's sound levels mi- If the unit is installed in a windy location, fit an anti-wind ght be compounded by reverberations or resonances grille to protect the fan and check the correct functioning of the unit. -
Page 20: Positioning
INStAllAtION MUltIPlE INStAllAtIONS > 300 > 300 > 150 > 200 > 1000 > 200 > 200 > 2000 > 1500 > 300 > 1000 Model 1070 M 1100 M 1125 M 1125 t 1140 t Positioning R AARIA PRO P devices must: —... - Page 21 INStAllAtION Positioning on floor Lifting from the top Condensate discharge connector Fastening screw M4 Anti-vibration element (supplied) 1070 1100 1125 1125 1140 Model Spirit level Refrigeration characteristics Condensate discharge — screw the unit to the ground 4 x 17 attachment Ø —...
-
Page 22: Installation On Old Systems Or Systems In Need Of Upgrading
INStAllAtION Installation on old systems or systems in need MODEl 1125 - 1140 of upgrading When R AARIA PRO P is installed on old systems or systems in need of upgrading, it is recommended to ensure that: — the electrical system is compliant with the applicable re- gulations and has been installed by qualified professionals In the event of a replacement, the system must be inspected by the designer or by another competent person, and must... - Page 23 INStAllAtION 1070 1100 1125 1125 1140 Model Additional charge Use pipes with the thickness indicated in the following table: Pipe Ø thickness inches 6,35 9,52 Plug the pipe ends in order to prevent water or debris from 12,70 flowing in. 15,88 before threading the lines through the hole in the wall, clo- se the lines ends.
- Page 24 INStAllAtION After connecting the cooling pipes: — create a vacuum inside the pipes — check for refrigerant leaks — apply thermal insulating material on the joints — Pipe insulation Connection pipes must be thermally insulated to prevent di- spersions of heat or formation of condensate. Torque wrench Flare nut Pipe Ø...
- Page 25 INStAllAtION to check tightness: — keep the outdoor unit shut-off valves closed High pressure Low pressure Pressure regulator Opening Nitrogen cylinder Closing Pressure gauge unit Service connection blanking plug 3-way valve service connection On-off valve shaft Refrigerating pipe attachment On-off valve cover plug Hex wrench If required: —...
- Page 26 INStAllAtION Having verified the absence of leakages: If the pressure has risen again: — create a pneumatic vacuum inside the circuit — Pneumatic vacuum to create vacuum in the circuit: — keep the outdoor unit shut-off valves closed 2-way shut-off valve On-off valve cover plug Hex wrench Opening by 1/4 of a turn...
- Page 27 INStAllAtION Opening Closing Service connection blanking plug On-off valve shaft Refrigerating pipe attachment On-off valve cover plug Hex wrench — fully open the unit shut-off valves — refit the valve covering plug Carefully check for absence of leakages from the closing point of the plug.
-
Page 28: 2.11 Wiring Diagram
INStAllAtION 2.11 Wiring diagram MODEl 1070... - Page 29 INStAllAtION MODEl 1100 M...
- Page 30 INStAllAtION MODEl 1125 M...
- Page 31 INStAllAtION MODEl 1125 t - 1140 t...
-
Page 32: 2.12 Electrical Connection
INStAllAtION 2.12 Electrical connection MODEl 1070 - 1100 AARIA PRO P It leaves the factory completely wired, and only re- quires a connection to the electrical power grid, the installation of a padlockable disconnecting switch, and a connection to the indoor unit. - Page 33 INStAllAtION MODEl 1070 M - 1100 M - 1125 M MODEl 1070 M - 1100 M - 1125 M 1 (N) 2 (L) 1 (N) 2 (L) 3 (C) 230V 1-N 50HZ Connection terminal board with indoor unit Power supply connection terminal board Wire retainer Earth screw 3(C)
- Page 34 INStAllAtION — make sure that the power supply line impedance is consi- stent with the unit's power consumption, as indicated on the unit's data plate — for any electrical intervention, always refer to the wiring diagrams contained within this booklet —...
-
Page 35: Commissioning And Maintenance
COMMISSIONING AND MAINtENANCE COMMISSIONING AND MAINtENANCE Take anti-static precautions in case of weather conditions Preparation for first commissioning where humidity is less than 40%. Prior to commissioning, it is necessary to check that: Avoid using mobile phones. — all the safety conditions have been met —... -
Page 36: Ordinary Maintenance
COMMISSIONING AND MAINtENANCE Ordinary maintenance Carefully check for absence of leakages from the closing point of the plug. Routine maintenance is fundamental for keeping the equip- Do not force beyond the stop point to prevent damaging the ment efficient, safe and reliable. It can be performed periodi- shaft and causing leakage as a consequence. -
Page 37: Operation Signal And Alarms
COMMISSIONING AND MAINtENANCE — check that the condensate discharge pipe is clean — let the device operate in cooling mode for 10 - 15 minutes — stop the device for about 3 minutes Do not use any means to accelerate the defrosting. —... - Page 38 COMMISSIONING AND MAINtENANCE led 1 Description Remarks The alarm activates 4 minutes after the unit start Communication error between outdoor and indoor unit The unit resets after problem resolution The alarm activates 5 minutes after the unit start Lack of refrigerant After 2 consecutive interventions in 20 minutes, the unit resets after problem resolution The alarm activates 5 minutes after the unit start 4-way valve malfunction...
- Page 39 COMMISSIONING AND MAINtENANCE utdoor unit Malfunction description Malfunction diagnosis Remarks display Fan motor malfunction Damaged fan motor Restorable Wiring fault Defrost probe (Te) fault Electrical circuits damaged Restorable The probe detects a temperature below -55 °C The probe detects a temperature over 90 °C Probe short circuit Suction probe(Ts) fault Restorable...
- Page 40 COMMISSIONING AND MAINtENANCE In the presence of operating abnormalities, the unit is secured and blocked. Safety block can occur randomly. Wait for at least 10 minutes before restarting the unit. To restore operating conditions cut and restore the power supply. If the fault occurs again, an accurate check of the device components is required.
-
Page 41: Disposal
RECYClING AND DISPOSAl DISPOSAl Packaging materials shall be disposed of separately so as to re- cover and recycle them. Refrigerant and oil must be recovered and not dispersed into the environment. At the end of its service life, the device shall be disposed of according to the existing le- gislation. - Page 44 RIELLO S.p.A. - 37045 Legnago (VR) tel. +39 0442 630111 - fax +39 0442 630371 www.riello.it As the manufacturer is constantly improving its products, the aesthetic or dimensional features, the technical data, the equipment and accessories indicated could be subject to variations.
