- Page 1 HDTV Digital QAM PHDQ 8008 TSR CLASS Phone: +49 (0) 911 / 703 8877 Fax: +49 (0) 911 / 703 9210 Grundig SAT Systems GmbH E-mail: info@gss.de Beuthener Strasse 43 Internet: http://www.gss.de D-90471 Nuremberg...
-
Page 2: Table Of Contents
Contents 1 Safety regulations and notes ................4 2 General information ..................5 2.1 Packing contents ................... 5 2.2 Meaning of the symbols used ..............5 2.3 Technical data ..................5 2.4 Description................... 6 2.4.1 Input signal path ................. 6 2.4.2 Output signal path "OUTROUTE"... - Page 3 Setting the LNB oscillator frequency ............20 Setting the input symbol rate ..............21 Setting the DVB mode ................21 Setting the input frequency ..............21 Testing the signal to noise ratio ............. 22 Setting the PSI ..................23 Setting the QAM modulation ..............24 Inverting the user signal ...............
-
Page 4: Safety Regulations And Notes
• Test the software versions of the head-end station and the cassette and update them if necessary. The current software versions can be found at "www.gss.de". Take action to prevent static discharge when working on the device! Electronic devices should never be disposed of in the household rubbish. In... -
Page 5: General Information
General information Packing contents 1 Cassette PHDQ 8008 TSR 2 HF cables 1 CD (assembly instructions) 1 Brief assembly instructions 1 Measuring log Meaning of the symbols used Important note —> General note • Performing works Technical data The devices meet the following EU directives: 2006/95/EC, 2004/108/EC The product fulfils the guidelines and standards for CE labelling. -
Page 6: Description
Connections SAT inputs: ................2 F sockets HF output: ................1 IEC socket ASI input: ..............1 BNC socket, 75 Ω ASI output: ..............1 BNC socket, 75 Ω Connection strip (10-pin): ....for supply voltages and control circuits RS 232 socket: ........serial interface for software update Description The twin transmodulator cassette is a QPSK-converter, which converts all sta- tions transmitted according to DVB-S / DVB-S2 standard into two QAM-modu- lated cable signals. -
Page 7: 2.4.2 Output Signal Path "Outroute
2.4.2 Output signal path "OUTROUTE" Menu setting "ASI => ASI" Transport stream 1 is made available via modulator "A", transport stream 2 via modulator "B" and the transport stream ASI from the ASI input via the ASI output. Modulator Transport stream 1 "A" Combiner HF output Modulator... -
Page 8: 2.4.3 General
To operate this cassette the software version of the control unit must be "V 41" or higher. You can find the current operating software for the control unit and the cassette, the software "BE-Flash" and the current assembly instructions on the website "www.gss.de". The cassette is designed for use in the following head-end stations: PSU 12, PSU 8, PGT 8 and PST 19-1. -
Page 9: Assembly
Assembly Installing the cassette – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way. – Before installing or changing a cassette unplug the power cable from the mains power socket. -
Page 10: Connecting The Cassette
The operating software of the cassette can be updated via the 9-Pin D- SUB socket "RS 232" using a PC or laptop and the software "BE-Flash". You can find the current operating software and the software "BE-Flash" on the website "www.gss.de". The LAN socket and the slot for a CA module are without function. -
Page 11: The Control Panel At A Glance
The control panel at a glance Menu items Program the cassette using the buttons on the control unit of the head-end sta- tion. The two-line display of the control unit then shows the menus. The parameters and functions to be set are underlined. Use the key to select the following main menu items: –... -
Page 12: Programming
Programming Preparation • Connect the test receiver to the HF output or the test output of the head-end station. • Set the output channel / output frequency of the cassette (see page 19) and adjust the TV test receiver to this channel. • Switch on the channel strip (modulator) if necessary (see page 19). For each channel strip, there is a status LED which indicates if the channel strip is switched on. -
Page 13: Programming Procedure
Programming procedure BE–Remote V 41 Ein / On PROFESSIONAL t > 10 s Box 1 .......... Bx 1A TWIN-SAT Böx 4 TWIN-SAT Box 4 DVBS2-TSR Box 5 ....C5-12,S3-24 C5-12,S3-24 V 12 – – – ......Page 14 Bx 4 OUTROUTE Bx 4... - Page 14 10600 MHz Bx 4A SYMBOL ◀ ◀ ▶ ▶ 27500 DVB-S DVB-S / DVB-S 2 … Bx 4A FREQ Bx 4A ◀ ▶ Anzeige: Signalqualität Display: Signal quality 11835 -0.6 CN 15 15.0 dB (+ 11.0) OK Bx 4A OFF … MIX+TABLES+EIT Bx 4A ◀...
-
Page 15: Programming The Cassette
Programming the cassette —> Pressing the button for longer than 2 seconds cancels the pro- gramming procedure. This takes you back to the program item "Selecting the cassette" from any menu. Any entries that have not been saved are reset to the previous settings. —>... -
Page 16: Selecting The Output Signal Path
Selecting the output signal path In this menu you define the signal path of the output transport streams. Menu setting "ASI => ASI" (page 7). Menu setting "1 => ASI ASI => MA" (page 7). Menu setting "2 => ASI ASI => MB" (page 7). Bx 4 OUTROUTE ASI=>ASI... -
Page 17: Setting The Asi Options
Setting the ASI options In this menu you define the size of the data packets, their polarity and the type of transmission. For this setting please take the required information from the documentation (technical data) of the ASI component to be connected. Bx 4 ASI OPTION 188 pos. cont. • Press the buttons to set the size of the data packets ("188" or "204" bits). • If the polarity of the data to be transmitted has to be changed, press the buttons to place the cursor under "pos."... -
Page 18: Selecting Channel / Frequency Setting
• Press the button. —> The "Selecting channel / frequency setting" – "OUTPUT" menu is acti- vated. Selecting channel / frequency setting In this menu, you can choose the channel or frequen c y setting for the adjust- ment of the HF output. The channel setting covers the range of channels S21 … C69, the frequency setting covers the range from 42.0 MHz to 860.0 MHz. The QAM signal is normally transmitted with a bandwidth of 8 MHz. This means that you can only use the channel centre frequency of the existing channel raster in the range of channels S21 …... -
Page 19: Setting The Output Channel
Setting the output channel In this menu you set the output channel of the channel strip. Additionally the modulator of the channel strip can be switched off or on. Bx 4A OUTPUT • Use the buttons to set the output channel. Setting the output frequency In this menu you set the output frequency of the channel strip (42.0 … 860.0 MHz). -
Page 20: Adjusting The Output Levels Of The Channel Strips
Adjusting the output levels of the channel strips This menu item is used to set the output levels of the modulators of the channel strips "A" and "B" to the same value. Bx 4A LEVEL -3 dB • Measure and note down the output level of the channel strip. • By repeatedly pressing the button scroll back to the "Selecting the channel strip"... -
Page 21: Setting The Input Symbol Rate
Setting the input symbol rate Setting the DVB mode The symbol rates of the satellite transponders can be found in the current chan- nel table of the satellite operator, in various satellite magazines and in the Internet. The cassette recognizes the transmitted DVB mode and switches over between the normal QPSK mode (DVB-S) and the DVB-S2 mode. Receiving stations with DVB-S2 mode, we suggest to preset the DVB mode to shorten the time for searching stations. -
Page 22: Testing The Signal To Noise Ratio
• Use to position the cursor under the digits of the frequency display to be set. • Press to set the input frequency. • Set the frequency offset shown in the display (e.g. "– 1.8") to less than 1 MHz by varying the input frequency using the buttons. -
Page 23: Setting The Psi
Setting the PSI Setting "OFF": For the PSI switched off (factory default "OFF") the transport streams of the receiv- ing stages "A" or "B" pass the TPS module without any alterations (no multiplex- ing). Setting "MIX": The PIDs fed via the ASI socket and selected using the software PSW 1000 are inserted into the transport streams of the receiving stages. Setting "MIX+TABLES": In addition to the functions of the "MIX"... -
Page 24: Setting The Qam Modulation
Setting the QAM modulation Inverting the user signal In this menu, you can set the QAM modulation and invert the user signal. For exceptional cases and "older" digital cable receivers, the spectral position of the user signal can be inverted. Bx 4A 256-QAM normal Setting the QAM modulation to set the QAM modulation ("4" … "256"). • Use —> For higher QAM modulation, the output symbol rate is lowered. —> An output QAM modulation of > 64 QAM places a large burden on the cable network. Due to noise, delay and frequency response problems, reception of the converted output signal can be impeded. - Page 25 input signal therefore must be built in such a way so that the output symbol rate set ("Number 1") is not exceeded. The symbol rates of the transport streams built by the cassette can be measured at the setting "OUTROUTE ASI=>ASI" and be displayed in the respective channel strip. • Use the buttons to place the cursor under the number to be changed ("Number 1") and set the symbol rate with the buttons...
-
Page 26: Setting A Substitute Signal
Setting a substitute signal You use this menu to set whether a QAM signal filled with "Null Packets", a QAM signal filled with null packets and self-made tables "Tables" or a "Single Carrier" signal should be provided as an output signal whenever an incorrect input signal occurs. -
Page 27: Saving Settings
Saving settings • Press the button. —> Return to "Selecting the cassette" (page 15). —> The settings are saved. —> If functions of the TPS module are activated, their status is shown in the second line of the display: "M" – Multiplex is activated (MIX). " i " – PSI is activated. —> By pressing the button, you will be returned to the menu item "Selecting the channel strip"... -
Page 28: Channel And Frequency Tables
Channel and frequency tables Advice for a frequency raster (8 MHz) in the Band I/III 42.00 82.00 146.00 186.00 226.00 266.00 50.00 114.00 154.00 194.00 234.00 274.00 58.00 122.00 162.00 202.00 242.00 282.00 66.00 130.00 170.00 210.00 250.00 290.00 74.00 138.00 178.00 218.00 258.00 298.00 CCIR – Hyperband (Frequency raster 8 MHz) S 21 306.00 S 26 346.00 S 30 378.00 S 34 410.00 S 38 442.00... - Page 29 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © GSS GmbH V12/19022010...
