GSS PTDT 1000 Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PTDT 1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTDT 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GSS PTDT 1000

Summary of Contents for GSS PTDT 1000

  • Page 1 PTDT 1000...
  • Page 2 o n t e n t s 1 Safety regulations and notes ................ 4 2 General information ..................5 Packing contents ................5 Meaning of the symbols used ............5 Technical data ................5 Description ...................6 Input signal path "INROUTE" .............7 Menu setting "A+ASI = 1 B+ASI = 2" ........7 Menu setting "A+B+ASI = 1 ASI = 2"...
  • Page 3 Channel / frequency setting .............23 Output settings ...............24 Output channel ..............24 Output frequency ..............24 Modulator ................24 Output levels of the channel strips ..........25 Input channel .................26 Hierarchical modulation ............27 Station filter ................27 Menu setting "A+B+ASI = 1 ASI = 2" ........28 Menu setting "A+ASI = 1 B+ASI = 2"...
  • Page 4 a f e t y r e g u l a t i o n s a n d n o t e s • Assembly, installation and servicing should be carried out by authorised electricians. • Switch off the operating voltage of the system before beginning with assem- bly or service work or pull out the mains plug.
  • Page 5 2.1 P aC k i n g C o n t e n t s 1 Cassette PTDT 1000 2 RF cables 1 Brief assembly instructions 1 Measuring log 2.2 m...
  • Page 6 Output impedance: ................. 75 Ω ASI interfaces Standard: ..............DIN EN 50083-9 Format: ..............MPEG ISO IEC 13818-1 User data rate: ..............2 … 90 Mbit/s Level (input / output): ............. 800 mV ± 10% Return loss (input):..........> 17 dB (5 … 270 MHz) Connections DVB-T inputs: ...............2 IEC sockets RF loop-through outputs: ............2 IEC sockets...
  • Page 7 "inroute" n P u t s i g n a l Pat h "a+asi = 1 b+asi = 2" e n u s e t t i n g The transport streams of the receiving stage "TS A" and of the ASI input "TS ASI" generate the transport stream 1. The transport streams of the receiv- ing stage "TS B"...
  • Page 8 "outroute" u t P u t s i g n a l Pat h "asi => asi" e n u s e t t i n g Transport stream 1 is made available via modulator "A", transport stream 2 via modulator "B" and the transport stream from the ASI input "TS ASI" via the ASI output.
  • Page 9 e n e r a l The cassette is equipped with two channel strips ("A" and "B"). The channel strips consist of the DVB-T tuners, the digital signal preparation units and the output converter. The channel strips are indicated in the head-end station dis- play with "Bx …A"...
  • Page 10 2.6 h tPs t h e m o d u l e wo r ks After decoding COFDM-modulated signals, the demodulated data streams and the data stream fed via the ASI socket can be accessed via the integrated TPS module. These data streams, also called transport streams, contain several stations in all their components (video, audio, data and service information), which can be changed using the TPS module.
  • Page 11 s s e m b l y 3.1 i n s ta l l i n g t h e C a s s e t t e – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way.
  • Page 12 3.2 emC r e g u l at i o n s To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in a head-end station which is installed in a 19" cabinet, make sure the connections leading in and out for the 19" cabinet are made using cable terminals. The attenuation of shielding of the connection lines for ASI and antenna must meet the requirements for "Class A". CLASS • Insert the required number of cable terminals in the openings provided in the head-end station or in the 19" cabinet. —>...
  • Page 13 3.3 o v e rv i e w t h e C a s s e t t e D-SUB socket "RS 232" Slot for CA module ASI output ASI input without function Loop-through output of RF input "A" Status LED of RF input "A" RF input "A"...
  • Page 14 3.5 r Ca e t r o f i t t i n g m o d u l e The cassette is equipped with a common interface. It allows you to connect a CA module for various scrambling systems and service providers. Scrambled stations can only be descrambled with a CA module suitable for the scram- bling system and the corresponding smart card.
  • Page 15 C o n t r o l P a n e l g l a n C e 4.1 m e n u i t e m s Programme the cassette using the buttons on the control unit of the head-end station.
  • Page 16 r o g r a m m i n g 5.1 P r e Pa r at i o n • Test the software versions of the head-end station and the cassette and up- date them if necessary. The current software versions can be found on the website "www.mygss.eu". •...
  • Page 17 5.3 P ro g r a m m i n g Pro C e d u r e Bedienhinweise Operating Hints BE–Remote V 45 Ein / On "blättert" Menüs vorwärts. scrolls forward through the menu. please wait … "blättert" Menüs rückwärts. scrolls backward through the menu.
  • Page 18 -3 dB 0 … -10 dB INROUTE: A+ASI=1 A+ASI=2 LINE: B ▶ Bx 4A INPUT Bx 4A INPUT -64 … +64 C60 (786.0) ◀ Bx 4A INPUT Priority: high high / low abhängig von Einstellung INROUTE / dependent on setting INROUTE Programme entfernen / hinzufügen Bx 4A PROGRAM...

  • Page 19: Table Of Contents

    QPSK…QAM64 8MHz QAM64 5…8MHz positiv / negativ positive / negative Bx 4A COFDM-MODE ◀ ▶ C1/2 … C7/8 C7/8 G1/32 2 … 8k G1/4 … G 1/32 Bx 4A COFDM TPS ◀ ▶ 0x0000 … 0xFFFF CELL 0x0000 on / off Bx 4A STUFFING 34363...
  • Page 20 5.4 P r o g r a m m i n g t h e C a s s e t t e —> Pressing the button for longer than 2 seconds cancels the programming procedure. This takes you back to the programme item "Selecting the cassette"...
  • Page 21 • Press the button. —> The "Input signal path" – "INROUTE" menu is activated. n P u t s i g n a l Pat h In this menu you define the signal path of the input transport streams. Menu setting "A+ASI = 1 B+ASI = 2" (page 7). Menu setting "A+B+ASI = 1 ASI = 2"...
  • Page 22 asi t r a n s f e r r at e In this menu you set the output transfer rate for the ASI component connected. For this setting please take the required information from the documentation (technical data) of the ASI component to be connected. Bx 4 ASI RATE 108000 KBits...
  • Page 23 —> Setting "burst" The data packets of the user data are spaced out evenly in the trans- port stream. • Press the button. —> The "Channel strip" – "LINE" menu is activated. h a n n e l s t r i P Bx 4 LINE Line A <=...
  • Page 24 • Use to select channel setting "Channel" or frequency setting "Freq.". • Press the button. —> The "Output channel" or "Output frequency" – "OUTPUT" menu is activated. u t P u t s e t t i n gs u t P u t C h a n n e l In this menu you set the output channel of the channel strip (C5 …...
  • Page 25 • In the case the modulator is switched "off" use the to switch it "on". • Press the button. —> The "Output levels of the channel strips" – "LEVEL" menu is activated. u t P u t l e v e l s t h e C h a n n e l s t r i P s...
  • Page 26 n P u t C h a n n e l If three dots " … " appear in the second line of the display, the cassette is in the "station search" mode. Please wait until the process has finished. Once the receiver has synchronised to the input signal, "OK"...

  • Page 27: Bx 4A

    i e r a rC h i C a l m o d u l at i o n In order to attain with less field strength a greater range for broadcasters, with DVB-T so-called "hierarchical modulation" can be used. In this process, several data streams are modulated onto a DVB-T data stream using "Quad- rature Amplitude Modulation"...

  • Page 28: Bx 4A

    "a+b+asi = 1 asi = 2" e n u s e t t i n g Channel strip "A" Bx 4A PROGRAM Bx 4A TV 01/10 Filter Das Erste AUDIO AUDIO Bx 4B TV 02/19 SWF3 AUDIO AUDIO 01/10 ..—>...

  • Page 29: "Bx 4A

    —> All stations from the channel strip will be read, and then displayed with name and station type. —> If no station is found, the following error message will appear in the display: "FILTER no Service". In this case, check the configuration of the antenna system and head-end station, as well as the previously adjusted settings for the cassette and the components connected to the ASI input.
  • Page 30 —> To return to the previous station filter press the button. • To save changes and to activate the station filters press the button. —> The display shows "PROGRAM Filter on". —> If stations are activated the corresponding PIDs (audio, video, text) are inserted into the data stream and the PAT and SDT tables are updated.
  • Page 31 • Press the button. —> The "Output signal" – "COFDM-MODE" menu is activated when the channel strips "A" without a CA module installed and "B" are pro- grammed. Please take note of the tables below before setting the COFDM parameters. —>...
  • Page 32 If the bandwidth is decreased by 1 MHz the transmittable data rate is de- creased by approx. Net data rate [kbit/s] at a bandwidth of 7 MHz Guard interval Modulation Code rate 4354 4838 5123 5278 5806 6451 6830 7037 QPSK 6532 7257 7684 7917 7257 8064 8538 8797 7620 8467 8965 9237...
  • Page 33 Transmission parameters for DVB-T at a bandwidth of 8 MHz Transmission mode Symbol duration T [µs] Carrier space ∆ f [kHz] 4.4643 2.232 1.116 2048 4096 8192 carrier theoretical 1705 3410 6817 carrier real Used bandwidth [MHz] 7.61 7.61 7.61 Total symbol duration 280 262 238 231 560 504 476 462 1120 1008 952 924 [µs] Guard interval T [µs]...

  • Page 34: Bx 4A Cofdm-Mode

    u t P u t s i g n a l In this menu, you can set the bandwidth, the carrier modulation and the spectral position of the output signal. Bx 4A COFDM-MODE 8MHz QAM64 a n dw i dt h t h e o u t P u t s i g n a l...

  • Page 35: G1/32

    r a n s m i s s i o n Pa r a m e t e rs In this menu you can set the transmission modes, the code rate and the guard interval. Bx 4A COFDM-MODE C7/8 G1/32 r a n s m i s s i o n m o d e In this menu item you set the quantity of carriers:...

  • Page 36: Cofdm Tps

    • Press the button. —> The "Transmitter identification" – "COFDM TPS" menu is activated. r a n s m i t t e r i d e n t i f i C at i o n At terrestrial transmission an identification is referred to each COFDM modu- lated transmitter.

  • Page 37: Bx 4A Stuffing 34363

    u t P u t data r at e This menu shows the output data rate defined using the COFDM settings and the current output data rate. Bx 4A STUFFING 34363 (32502) Number 1 Number 2 34363 (= "Number 1"): Maximum gross output data rate (32502) (= "Number 2"): The current measured gross output data rate.

  • Page 38: Bx 4A Failure

    u b s t i t u t e s i g n a l t h e C a s e i n C o r r e C t i n P u t s i g n a l You use this menu to set whether a COFDM signal filled with "Null Packets", a COFDM signal filled with null packets and self-made tables "Tables"...

  • Page 39: Bx 4A Nit

    • Press the button. —> The "Network Information Table" – "NIT" menu is activated. (nit) e t wo r k n f o r m at i o n a b l e Bx 4A => Make • To switch NIT on/off ("on"/"off") press the buttons.

  • Page 40: Cat-Id

    e t wo r k o P e r ato r i d e n t i f i C at i o n In this menu, you can change the network/operator identification (CAT-ID – Conditional Access Table - Identification), for example of the visAvision trans- ponder (Eutelsat 8°...

  • Page 41: Bx 4A Drop

    Pid e l e t i n g In this menu a PID of the transport stream can be deleted. Bx 4A DROP PID 0x0000 • Use the buttons to place the cursor under the respective digit of the hexadecimal number of the PID to be deleted ("0x0000") and set the hexa- decimal number using •...

  • Page 42: Bx 4A Factory Bx 4A Factory

    aC to ry r es e t In this menu you can reset all settings to the factory defaults. Bx 4A FACTORY Bx 4A FACTORY Defaults => STORE => M • Press the button. —> The factory defaults are invoked ("FACTORY STORE"). —>...
  • Page 43 Ca P e r at i o n w i t h m o d u l e In order for this function of the CA module to be possible, stations capable of being descrambled by the CA module you are using and your smart card must be selected in the "Station filter"...
  • Page 44 • Press the button to activate the menu of the CA module. —> The display shows e.g.: Bx 4A 01/03 MENU Information Meaning of the indicators: "Bx 4A" Slot 4, channel strip "A" "01/03" The first of three menu items is activated. "MENU" The menu of the CA module is activated. For the explanation of further details please use the operating instructions of the CA module used.
  • Page 45 —> The display shows e.g.: Bx 4A TV X 04/09 ..Meaning of the indicators in the example: "Bx 4A" Slot 4, channel strip "A" "TV" TV channel type "X" The currently selected station is to descramble. "04/09" The 4th of 9 stations read is being displayed. ".." Station name Further possible terms displayed: "RA"...
  • Page 46 i n a l Pro C e d u res After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable connections using an appropriate open-ended spanner. • Measure the output levels of the other cassettes and tune them to a uniform output level using the appropriate level controls or software dependent on the head-end station used.
  • Page 47 h a n n e l a n d f r e q u e n C y t a b l e s Advice for a frequency grid (8 MHz) in the band I/III 42.00 82.00 146.00 186.00 226.00 266.00 50.00 114.00...
  • Page 48 GSS Grundig SAT Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 703 8877 • Fax: +49 (0) 911 / 703 9210 www.gss.de/en • info@gss.de CLASS CLASS Service: Phone: +49 (0) 911/703 2221; Fax: +49 (0) 911/703 2326; service@gss.de Alterations reserved.
