GSS PHDQ 6100 CI TPS Assembly Instructions Manual

Hdtv satellite conversion (dvb-s2 – qam)

Advertisement

Quick Links

GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
HDTV Digital QAM
PHDQ 6100 CI TPS
Phone:
+49 (0) 911 / 703 8877
Fax:
+49 (0) 911 / 703 9210
E-mail:
info@gss.de
Internet:
http://www.gss.de
CLASS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHDQ 6100 CI TPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GSS PHDQ 6100 CI TPS

  • Page 1 HDTV Digital QAM PHDQ 6100 CI TPS CLASS Phone: +49 (0) 911 / 703 8877 Fax: +49 (0) 911 / 703 9210 Grundig SAT Systems GmbH E-mail: info@gss.de Beuthener Strasse 43 Internet: http://www.gss.de D-90471 Nuremberg...
  • Page 2 Output levels of the channel strips ............24 Selecting the Tuner (only channel strip B) ..........24 LNB oscillator frequency ..............25 Input symbol rate ................25 DVB mode ..................25 Input frequency ................26 - 2 - PHDQ 6100 CI TPS...
  • Page 3 Operation with a CA module ............. 36 PID monitoring ................36 Configuring the CA module ............36 Descrambling services ..............38 6 Final procedures ....................39 7 Channel and frequency tables ................40 - 3 - PHDQ 6100 CI TPS...
  • Page 4 At the end of its service life, please take your device to one of these public collection facilities for proper disposal. - 4 - PHDQ 6100 CI TPS...
  • Page 5 C o n t e n t s 1 Cassette PHDQ 6100 CI TPS 2 HF cables 1 Brief assembly instructions...
  • Page 6 You can find the current operating software for the control unit and the cassette, the software "BE-Flash" and the current assembly instructions on the website "www.gss.de". The cassette is designed for use in head-end stations of the profi line. - 6 - PHDQ 6100 CI TPS...
  • Page 7: Software Query

    The TPS module can adjust the "Network Information Table" (NIT) to accommodate the new station data. The "NIT" contains data which is required by the set-top box for the automatic search feature. - 7 - PHDQ 6100 CI TPS...
  • Page 8 Reception from a transponder with a very low symbol rate (SCPC station) The extremely low data rate means that the output symbol rate is very low. If there are reception problems with different digital receivers, set output symbol rate to a higher value. Defined symbol rates Some cable operators specify a fixed symbol rate (e.g. 6,900 kSymb/s). - 8 - PHDQ 6100 CI TPS...
  • Page 9 Eutelsat 13° East Türksat 42° East Eutelsat 7° East TVP 1 Nile TV Viva TVP 2 ESC 1 Nile News Gala TVP 3 3 MHz 4 MHz 64 QAM 64 QAM 2.5 Ms/s 3.3 Ms/s - 9 - PHDQ 6100 CI TPS...
  • Page 10: Assembly

    • Insert the cassette in this slot and push it into the housing. • Align the cassette and apply slight pressure to connect it to the connections of the board and the HF bus bar. • Fasten the cassette with the screws 0° ACHTUNG! MESSAUSGANG Vor dem Cassettenwechsel unbedingt Netzstecker ziehen! CAUTION! Before changing cassettes remove mains plug! - 10 - PHDQ 6100 CI TPS...
  • Page 11: Emc Regulations

    Tighten the nuts of the cable terminals until the teeth on the lock washers put un- der have penetrated the exterior coating and a good connection is made between the housing / 19" cabinet and cable terminals. - 11 - PHDQ 6100 CI TPS...
  • Page 12: Cassette Overview

    • Plug the SAT input cables into the SAT input sockets "SAT input A" (chan- nel strip "A") and "SAT input B" (channel strip "B"). • Connect the head-end station to the mains power supply. - 12 - PHDQ 6100 CI TPS...
  • Page 13 (top) of the CA module • Insert the CA module into the slot with the top side of the CA module facing the RS-232 socket of the cassette. • Push the CA module without canting into the guide rails of the CA slot and contact it to the common interface. - 13 - PHDQ 6100 CI TPS...
  • Page 14: The Control Panel At A Glance

    The key pad on the head-end station is used to scroll through the menus and menu items one at a time: scrolls forward through the menus. select parameters in the menus. set values, initiate actions. selects sub-menus. scrolls backward through the menus. saves all entries - 14 - PHDQ 6100 CI TPS...
  • Page 15: Programming

    In order to prevent interference within the head-end station and the cable sys- tem, the output level of the cassette must be lowered by 10 dB compared to analogue cassettes at 64 QAM, and by 4 dB compared to analogue cassettes at 256 QAM. • Measure the output levels of the other cassettes and tune them to a uniform output level using the appropriate level controls or software dependent on the head-end station used. Please regard the assembly instructions of the respective head-end station. - 15 - PHDQ 6100 CI TPS...
  • Page 16: Programming Procedure

    ◀ ▶ ◀ ▶ 27500 DVB-S DVB-S / DVB-S 2 ◀ ▶ 4A/B FREQ 4A/B 11835 -1.8 CN 12 12.0 dB (+ 9.6) OK Anzeige: Signalqualität - 16 - PHDQ 6100 CI TPS Display: Signal quality Programme entfernen / hinzufügen...
  • Page 17 Null Packets … Single Carrier ◀ ▶ 4A/B TS/ONID ◀ ▶ 0x0001,0100 off / on 4A/B ▶ => Make on / off Make 4A/B DROP ◀ ▶ ◀ ▶ PID 0x0000 on / off - 17 - PHDQ 6100 CI TPS...
  • Page 18 ◀ ▶ ◀ ▶ 0x0000 –> 0000 on / off Page 16 auf Werkseinstellung 4A/B FACTORY 4A/B FACTORY zurücksetzen und speichern ▶ reset to factory defaults Defaults => STORE => M and store - 18 - PHDQ 6100 CI TPS...
  • Page 19: Programming The Cassette

    Böx 4 TWIN-SAT Box 4 DVBS2-TPS Box 5 ……… C5-12,S3-24 C5-12,S3-24 V 19 – – – ……… ……… • Select the cassette you want to program (e.g. Box 4) by repeatedly pressing the button if necessary. - 19 - PHDQ 6100 CI TPS...
  • Page 20: Selecting The Channel Strip

    "DVBS2-TPS" Type of cassette "858" Frequency set —> Button selects channel strip "A". —> Button selects the following cassette. • Press the button. —> The "Channel / frequency setting" – "OUTPUT" menu is activated. - 20 - PHDQ 6100 CI TPS...
  • Page 21: Selecplex

    "Channel" or frequency setting "Freq.". • Press the button. —> The "Output channel" or "Output frequency" – "OUTPUT" menu is activated. —> If frequency setting is selected continue on page 22 with "Output fre- quency". - 21 - PHDQ 6100 CI TPS...
  • Page 22: Output Channel

    —> The switched off modulator is indicated by " " in the display. • If the modulator is switched "off" use the to switch it "on". • Press the button. —> The "Output levels of the channel strips" – "LEVEL" menu is activated. - 22 - PHDQ 6100 CI TPS...
  • Page 23: Output Levels Of The Channel Strips

    • Press the button. Selection Tuner A: —> The "Station filter" – "PROGRAM" menu is activated (page 27). —> Observe the "Transport stream / ORGNET-ID" – "TS/ONID" (page 31). - 23 - PHDQ 6100 CI TPS...
  • Page 24: Lnb Oscillator Frequency

    Internet. The cassette recognizes the transmitted DVB mode and switches over between the normal QPSK mode (DVB-S) and the DVB-S2 mode. Receiving stations with DVB-S2 mode, we suggest to preset the DVB mode to shorten the time for searching stations. Bx 4A SYMBOL 27500 DVB-S - 24 - PHDQ 6100 CI TPS...
  • Page 25: Input Frequency

    • Press to set the input frequency. • Set the frequency offset shown in the display to less than 1 MHz by varying the input frequency using the buttons. • Press the button. —> The "Signal to noise ratio" – "C/N" menu is activated. - 25 - PHDQ 6100 CI TPS...
  • Page 26: Signal To Noise Ratio

    Signal quality is poor Yellow No signal The channel strip (modulator) is switched off • Press the button to return to the main menu. • Press the button. —> The "Station filter" – "PROGRAM" menu is activated. - 26 - PHDQ 6100 CI TPS...
  • Page 27: Station Filter

    TV or test receiver is darkened. " – " The currently selected service is switched off. " * " A star means that the service selected is encoded. To enable the service, the CA module and the appropri- ate smart card of the provider are required. - 27 - PHDQ 6100 CI TPS...
  • Page 28 "A" without a CA module installed and "B" are pro- grammed. Programming the channel strip "A" with a CA module installed the "PID monitoring" – "CA" menu is activated (see page 35). - 28 - PHDQ 6100 CI TPS...
  • Page 29: Qam Modulation

    Number 1 Number 2 SR=6900 (= "Number 1"): Active output symbol rate (6325) (= "Number 2"): The current measured output symbol rate. —> If the station filter is activated, this value is lower than the value of the "Number 1". The value fluctuates, since the data rates of indi- vidual stations are dynamically modified by the broadcasters. - 29 - PHDQ 6100 CI TPS...
  • Page 30: Substitute Signal In The Case Of An Incorrect Input Signal

    Self-made tables are transmitted furthermore. Bx 4A FAILURE Single Carrier • Use the buttons to set the output signal required. • Press the button. —> The "Transport stream ID and the ORGNET-ID" – "TS/ONID" menu is activated. - 30 - PHDQ 6100 CI TPS...
  • Page 31 "off" and switch "on" the trans- mitter identification using the buttons. —> By pressing the button you return to the hexadecimal number setting. • Press the button. —> The "Network Information Table" – "NIT" menu is activated. - 31 - PHDQ 6100 CI TPS...
  • Page 32: Deleting A Pid

    When the cable NIT of the cassette is switched on again ("on") by pressing the button, the previously generated NIT is added again. If you have changed parameters in the meantime, you must first select "Make" to generate a new, up-to-date NIT. • Press the button. —> The "Deleting a PID" – "DROP" menu is activated. - 32 - PHDQ 6100 CI TPS...
  • Page 33: Renaming A Pid

    PID ("–> 0000"). • Set the hexadecimal number using • Use the button to set the cursor to "off" and rename the PID using the buttons ("on"). • Press the button. —> The "Factory reset" – "FACTORY Defaults" menu is activated. - 33 - PHDQ 6100 CI TPS...
  • Page 34: Factory Reset

    The station filter is switched on " " NIT activated —> By pressing the button, you will be returned to the menu without item "Selecting the channel strip" saving the programmed data (page 20). —> If necessary set channel strip " ". - 34 - PHDQ 6100 CI TPS...
  • Page 35: Pid Monitoring

    Bx 4A Menu <= => Edit —> By pressing the button you can skip the "Configuring the CA module" – "CA" menu and activate the "QAM modulation" – "QAM" menu (page 29). - 35 - PHDQ 6100 CI TPS...
  • Page 36 CA module and are returned to the "Configuring the CA module" – "CA" menu. • Press the button. —> The "Descrambling services" – "Edit" menu is activated. - 36 - PHDQ 6100 CI TPS...
  • Page 37: Descrambling Services

    —> The filter is activated. The display shows the "Configuring the CA module" – "CA" menu. Bx 4A Menu <= => Edit • Press the button. —> The "QAM modulation" – "QAM" menu is activated (page 27). - 37 - PHDQ 6100 CI TPS...
  • Page 38: Final Procedures

    Please regard the assembly instructions of the respective head-end station. —> In order to prevent interference within the head-end station and the cable system, the output levels of the analogue cassettes must be set higher by 8 dB compared to digital cassettes. • Mount the front cover (see assembly instructions of the head-end station). - 38 - PHDQ 6100 CI TPS...
  • Page 39: Channel And Frequency Tables

    C 58 770.00 C 68 850.00 C 29 538.00 C 39 618.00 C 49 698.00 C 59 778.00 C 69 858.00 C 30 546.00 C 40 626.00 C 50 706.00 C 60 786.00 - 39 - PHDQ 6100 CI TPS...
  • Page 40 Declaration of CE conformity - 40 - PHDQ 6100 CI TPS...
  • Page 41: Technical Data

    Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © GSS GmbH V19/10022011...
