- Page 1 Head-End DVB-T Converter to IP DVB-T to SPTS PTIS 1000 CLASS Phone: +49 (0) 911 / 703 8877 Grundig SAT Systems GmbH Fax: +49 (0) 911 / 703 9210 Beuthener Strasse 43 E-mail: info@gss.de D-90471 Nuremberg Internet: http://www.gss.de...
-
Page 2: Table Of Contents
Setting the forward error correction .............25 Setting the transmission channel ..............25 Copying the settings to all IP addresses ............25 Setting IP addresses for services ..............26 Allocating IP addresses to services manually ..........26 Allocating IP addresses to services automatically ...........26 - 2 - PTIS 1000... - Page 3 Displaying the output data rate ..............29 Factory reset .....................29 Saving settings ..................30 5.2.1 Operation with a CA module ............31 Setting the PID monitoring ..............31 Configuring the CA module ..............31 Descrambling services ..............33 6 Final procedures .....................34 - 3 - PTIS 1000...
-
Page 4: Safety Regulations And Notes
European Council from January 27, 2003 which addresses old electronic and electrical devices, such devices must be disposed of at a designated collection facility. At the end of its service life, please take your device to one of these public collection facilities for proper disposal. - 4 - PTIS 1000... -
Page 5: General Information
General information Packing contents 1 Cassette PTIS 1000 2 HF cables 1 CD (assembly instructions) 1 Brief assembly instructions 1 Measuring log Meaning of the symbols used Important note —> General note • Performing works Technical specifications The devices meet the following EU directives: 2006/95/EC, 2004/108/EC The product fulfils the guidelines and standards for CE labelling. - Page 6 ASI input: ................1 BNC socket ASI output: ................. 1 BNC socket Connection strip (10-pin): ....for supply voltages and control circuits RS 232 socket: ........serial interface for software update Common Interface: ....... 1 (several services can be descrambled). - 6 - PTIS 1000...
-
Page 7: Description
The cassette is programmed using the head-end station control unit. Two LEDs in the channel strips provide an indication with their colour whether an HF signal is present or not. In a menu, the transmission of DVB service in- formation (EIT, TDT and SDT) or teletext (TXT) can be individually activated or deactivated. EIT (Event Information Table): For each service, event information is transmitted (such as starting time, dura- tion, scrambling etc.) - 7 - PTIS 1000... -
Page 8: Software Query
You can find the current operating software for the control unit and the cassette, the software "BE-Flash" and the current assembly instructions on the website "www.gss.de". The cassette is designed for use in the following head-end stations: PSU 12, PSU 8, PGT 8 and PST 19-1. -
Page 9: Assembly
19" cabinet are made using cable terminals. The attenuation of shielding of the connection lines for ASI and antenna must meet the requirements for "Class A". CLASS - 9 - PTIS 1000... -
Page 10: Overview Of The Cassette
Status LED of the LAN interface (yellow LED – data transfer) LAN socket Status LED of the LAN interface (green LED – network connection) ASI input ASI output Type label Slot for a CA module D-SUB socket "RS 232" MAC address - 10 - PTIS 1000... -
Page 11: Connecting The Cassette
PC or a notebook and the "BE-Flash" software to update the software of the cassette. You can find the "BE-Flash" software and the current operating software of the cassette at the website "www.gss.de". • Use a "one-to-one cable" to connect the cassette’s RS 232 interface and the PC according to the wiring scheme below. -
Page 12: Retrofitting A Ca Module
(top) of the CA module. • Insert the CA module into the guide rails of the CA slot with the top side of the CA module facing the top side of the cassette. • Push the CA module without canting into the guide rails of the CA slot and contact it to the common interface. - 12 - PTIS 1000... -
Page 13: The Control Panel At A Glance
The key pad on the head-end station is used to scroll through the menus: scrolls forward through the menus. select parameters in the menus. set values, initiate actions. selects sub-menus. scrolls backward through the menus. saves all entries. - 13 - PTIS 1000... -
Page 14: Programming
Tuner B C5…C12, C21…C69 Tuner B / -64…+64 page 16 Bx 4A INPUT Priority: high high / low - 14 - PTIS 1000 Kanalzug “Tuner A” ohne CA-Modul, Kanalzug “Tuner A” mit CA-Modul Kanalzug “Tuner B” / Channel strip “Tuner A“ with... - Page 15 TXT / txt, SDT / sdt EIT TDT TXT SDT (ON / off) copy Bx 4 DATARATE 72.956 Mbps page 14 Werkeinstellwerte Bx 4A FACTORY Bx 4A FACTORY aufrufen ▶ invoke factory defaults Defaults => STORE => M - 15 - PTIS 1000...
-
Page 16: Channel Strip "Tuner A" With Ca Module
..0 – nicht entschlüsseln no descrambling ◀ ▶ *) Die angezeigte Information ist nächster Service abhängig vom verwendeten next service CA-Modul. The information displayed is dependent on the CA module used. page 14 - 16 - PTIS 1000... -
Page 17: Programming The Cassette
—> The display shows e.g. the menu "Box 4 DVBT-SPTS": "Box 4" stands for slot 4 "DVBT-SPTS" type of cassette "V 12" software version of the cassette • Press the button. —> The "Setting the Ethernet parameters" – "ETHERNET" menu is activated. - 17 - PTIS 1000... -
Page 18: Setting The Ethernet Parameters
IP address displayed to be set and use to set the IP address wished. • Press the button. —> The "Setting the address range" – "IP-MASK" menu is activated. - 18 - PTIS 1000... -
Page 19: Setting The Address Range
The UDP port setting is required if the cassette needs to be reached externally to make the setting, such as from another input frequency. This setting is in- tended for future functions and can be skipped for this cassette. Bx 4 UDP-PORT 60000 - 19 - PTIS 1000... -
Page 20: Selecting The Input Transport Stream
—> The menu "Allocating IP addresses" – "IP-OUT 1" is activated (page 23). Input transport stream selected: "Tuner A" or "Tuner B" • Press the button. —> The menu "Setting the input channel" – "INPUT" is activated. - 20 - PTIS 1000... -
Page 21: Setting The Input Channel
LED indicator Indication Green Signal available Status LED No signal Channel strip "A" Status LED Channel strip "B" • Press the button. —> The menu "Setting the hierarchical modulation" – "INPUT Priority:" is activated. - 21 - PTIS 1000... -
Page 22: Setting The Hierarchical Modulation
"Setting the PID monitoring" – "CA" menu is activated (page 31). • Set channel strip "Tuner B" in the same way as channel strip "Tuner A". • Press the button. —> The "Allocating the IP addresses" – "IP-OUT 1" menu is activated. - 22 - PTIS 1000... -
Page 23: Allocating The Ip Addresses
• Press the buttons to switch off ("off") or ("on") the output IP address and the service referred. —> In the second line of the "IP-OUT …" menu "off" is displayed instead of the service referred. - 23 - PTIS 1000... -
Page 24: Copying The Settings To All Ip Addresses
"Selecting the transmission protocol" and "Setting the port number" can be copied to all IP addresses. —> The display shows "copy" for a short time. • Press the button. —> The "Defining the quantity of data packets", "Setting the forward error correction" and "Setting the transmission channel" – "PKTS / FEC" menu is activated. - 24 - PTIS 1000... -
Page 25: Defining The Quantity Of Data Packets
Copying the settings to all IP addresses • Pressing the button the settings "Quantity of the data packets", Forward error correction" and "Transmission channel" can be copied to all IP addresses. —> The display shows "copy" for a short time. - 25 - PTIS 1000... -
Page 26: Setting Ip Addresses For Services
IP address wished. Allocating IP addresses to services automatically • Pressing the button the first 16 of the present services are occupied with IP addresses in ascending order, starting from the IP address set. —> The display shows "auto" for a short time. • Press the button. —> The "Allocating services manually" menu is activated. - 26 - PTIS 1000... -
Page 27: Allocating Services Manually
If the service selected is already allocated to an IP address, in the first line of the display an exclamation mark " ! " appears beside the type of the service. IP 1 TV ! 001/016 Das Erste - 27 - PTIS 1000... -
Page 28: Selecting The Sound Options Of The Service
• Using the buttons activate ("EIT", "TDT", "TXT", "SDT") or deactivate ("eit", "tdt", "txt", "sdt") the transmission option wished. —> Activated options are shown with capital letters, deactivated with small letters. - 28 - PTIS 1000... -
Page 29: Displaying The Output Data Rate
Defaults => STORE => M • Press the button. —> The factory defaults are invoked ("FACTORY STORE"). —> By pressing the button, you will be returned to the menu item "Setting the Ethernet parameters" without invoking the factory defaults (page 18). - 29 - PTIS 1000... -
Page 30: Saving Settings
—> The settings are saved. —> You will be returned to the "Selecting the cassette" menu item (page 17). —> By pressing the button, you will be returned to the menu item "Setting the Ethernet parameters" "ETHERNET" without saving the pro- grammed data (page 18). - 30 - PTIS 1000... -
Page 31: 5.2.1 Operation With A Ca Module
Bx 4A Menu <= => Edit Bx 4A 01/03 MENU Bx 4A TV Bx 4A TV 04/09 04/09 Information *) ..- 31 - PTIS 1000... - Page 32 CA module and are returned to the "Configuring the CA module" – "CA" menu. • Press the button. —> The "Descrambling services" – "Edit" menu is activated. - 32 - PTIS 1000...
-
Page 33: Descrambling Services
—> The filter is activated. The display shows the "Configuring the CA mod- ule" – "CA" menu. Bx 4A Menu <= => Edit • Press the button. —> The "Selecting the input data stream" – "INPUT" menu is activated (page 20). - 33 - PTIS 1000... -
Page 34: Final Procedures
After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable bolted connections using an appropriate open- ended spanner. • Mount the front cover (see assembly instructions of the head-end station). - 34 - PTIS 1000... - Page 35 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © GSS GmbH V12/28012010...
