Pump start up

How to start up the pump and navigate to the Run Screen
Step 1: Turn on pump
Dynamic Medium
= Power on the pump
The CrossFlow start up screen will appear and a progess bar
will indicate that the pump is starting up.
2
Refer to the instructions for use for important safety and user advice. Do not operate the device without first reading and understanding the Instructions for Use.
Dynamic Medium
Doctor 1
XF2
STOP
Doctor 1
Step 2: Insert cassettes
XF2
STOP
Wait for "insert cassette" screen to appear, then align the colored side of the cassette
facing out toward its matching colored button. Green checkmarks will indicate that
the cassette(s) have been properly inserted. Once the Inflow Cassette is inserted, the
pump will advance to the User Profile Selection Screen.
= Inflow cassette (blue)
Dynamic Medium
Doctor 1
XF2
STOP
= Outflow cassette (red)
