2.2 Quick check

When the main menu shows: Press and hold down the
number 0 for two seconds to access the Quick check
function.
Quick check is a display mode where you can quickly
receive information about the software, loop system,
sensors and battery. Press YES to switch between the
different display modes. Press Arrow back to exit the
quick check function.
The software display mode presents:
• Ver:
The version of the mower program consisting of
both the edition (02.50) and program type
(220 AC).
• B:
Control box version
• Date:
Date of issue
• Time:
Time of issue
The loop system display mode presents:
• Loop signal value
Af = The strength of the A-signal measured via
the front loop sensor on the mower. The value
should lie between approximately 70 and 320 to
ensure good functionality. The closer to the loop
the mower is, the higher the value. When the
Automower is directly over the loop the value is 0
and when the mower is outside of the loop the
value is negative.
When the Automower is in the test position, see
page 39, the value for the F-signal should be
above 300 and for the N-signal the value should
be above 100.
To ensure the functionality of the guide wire, the
Guide signal value should be (-) 250 – 320 next
to the guide wire. The guide wire is named G1 for
220 AC and the guide wires are named G1 and
G2 for 230 ACX and Solar Hybrid.
• Quality:
The loop signals can only be interpreted if the
Quality value is 100 %. When the value is 99 % or
lower, the loop system does not function correctly
and with that, the displayed values for the signals
will not be correct.
• Restarts:
Within 5 – 10 seconds after the function starts, the
restart value stabilises. When the value continues
to change this indicates that the system is affected
by interference or is defective.
24 - English
2. SPECIAL MENU FUNCTIONS
Ver: 02.50 B:36
220 AC
Date: Jan 10 2007
Time: 14:09:25
Af: 250
F: 320
Quality:
Restarts:
220 AC
Af: 250
G1: -250
F: 320
Quality:
Restarts:
230 ACX/Solar Hybrid
G1: -250
N: 110
100%
0
G2: 280
N: 110
100%
0
